Part 2.4: QSPI Flash

The FPGA core board ACU3EG is equipped with one 256MBit Quad-SPI
FLASH chip to form an 8-bit bandwidth data bus, the flash model is
MT25QU256ABA1EW9, which uses the 1.8V CMOS voltage standard. Due to
the non-volatile nature of QSPI FLASH, it can be used as a boot device for the
system to store the boot image of the system. These images mainly include
FPGA bit files, ARM application code, and other user data files. The specific
models and related parameters of QSPI FLASH are shown in Table 2-4-1.
Position
U5
QSPI FLASH is connected to the GPIO port of the BANK500 in the PS
section of the ZYNQ chip. In the system design, the GPIO port functions of
these PS ports need to be configured as the QSPI FLASH interface. Figure
2-4-1 shows the QSPI Flash in the schematic.
