AK-CC55 Multi Coil

Applications

The chapter outlines application examples:
• 1-3: Control of one, two and three evaporators
• 4: Control of high temperature cold rooms with two evaporators
• 5: Control of low temperature cold rooms with two evaporators
An application setting will configure inputs and outputs so that the controller's operation interface is reflecting the
selected application.
Figure 25: Standard display case, upright or normal, with
one evaporator
S₄
S₅

AK-CC55 connections and application options

Upper and lower connection labels are laid out as shown in figure:
Figure 27: Electrical connections AK-CC55 Multi Coil
40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 60 61 70 71
s
5V
AI2 AI3 AI4
AI1
115 – 230 V AC
AKV
L N
1 2 3 7 8 9
(1) See Table 8
* Max. 0.5 A - No overload protection!
AK-CC55 Multi Coil is optimised for control of one to three expansion valve + different combinations of light, rail
heat and alarm relays. It has 7 Digital Outputs (DO), known as DO1 – DO7, one Analogue Output (AO), known as
AO1, 6 Analogue Inputs (AI), known as AI1 – AI6, an input that can be used as either DI1 (Digital Input) or AI7 (Sensor
Input), and 2 Digital Inputs, known as DI2 - DI3.
Table 7: The controller covers the following five applications:
Application 1-3 Control of one, two and three evaporators.
Application 4 Control of high temperature cold rooms with two evaporators.
Application 5 Control of low temperature cold rooms with two evaporators.
© Danfoss | Climate Solutions | 2022.08
S₅
S₂
AI5 AI6 DI1/ DI2 AO1
(1)
AI7 (1) PWM
DO2 DO3 DO4
10 11 12 13 14 15 16 17
Figure 26: Cold room configuration with door, light and
heat control function
S
(S )
5
S₄ 4
(S4) Hint: On cold rooms the S4 sensor can be placed
at the air inlet of the evaporator.
83 84 85
B - A +
MODBUS
DO5 DO6 DO7
DI3
115 – 230 V AC
18 19 20 21 22 23 24 30 31
S
4
