AK-CC55 Multi Coil

Connectivity

The diagram outlines the connectivity options presented by AK-CC55 for the design of system functionality.
Figure 2: Connectivity
AK-CC55 Compact
KoolProg

Data communication

The controller has built-in MODBUS data communication. If there is a requirement for a different form of data
communication, a Lon RS 485 module can be inserted in the controller.
The connection must then be to the module.
Figure 3: Mounting of communication module
© Danfoss | Climate Solutions | 2022.08
System Manager
AK-CC55 Multi Coil
AK-CC55 Single Coil UI
Case Controller
AKA 245: LON units
only and max 250
controller parameters
Bluetooth AK-CC55 Connect
AK-UI55 Bluetooth
AK-UI55 Set
Smart Device
(iOS or Android)
AK-UI55 Info
Remote Display Service App
BC365022028193en-000201 | 7
