AK-CC55 Multi Coil

Injection control

Table 30: Injection control → Injection control A
Function Description
Control state A Readout of the actual control state of the controller
Thermostat air Thermostat temperature
temp. A
S4 Air OFF evap. A Actual sensor value
EEV opening A Actual status of output function
Pe Evap. pressure Actual sensor signal
Te Evap. temp. Temperature converted from pressure
S2 Gas outlet A Actual sensor value
Superheat A Readout of actual superheat at the outlet of the evap-
orator
Superheat reference Readout of the actual superheat reference
A
Min. superheat limit Min. value for the superheat reference
Max. superheat limit Max. value for the superheat reference
MOP temperature MOP temperature. The valve opening degree is re-
duced until the evaporating temperature reaches the
set MOP limit. If no MOP function is required, select
the highest value that corresponds to OFF
AKV Period time Period time for the pulse width modulation
Min superheat liq- Min. value for the superheat reference during adap-
uid ctrl tive liquid control
Max superheat liq- Max. value for the superheat reference during adap-
uid ctrl. tive liquid control
Table 31: Injection control → Injection control B
Function Description
Control state B Readout of the actual control state of the controller
Thermostat air Thermostat temperature
temp. B
S4 Air OFF evap. B Actual sensor value
EEV opening B Actual status of output function
Pe Evap. pressure Actual sensor signal
Te Evap. temp. Temperature converted from pressure
S2 Gas outlet B Actual sensor value
Superheat B Readout of actual superheat at the outlet of the evap-
orator
Superheat reference Readout of the actual superheat reference
B
© Danfoss | Climate Solutions | 2022.08
Values
0=Normal ctrl., 1=Hold after defrost, 4=Drip off,
10=Main switch OFF, 11=Thermostat cutout, 12=Frost
protection S4, 13=Not_used, 14=Defrost, 15=Fan de-
lay, 16=Forced closing, 17=Door open, 18=Melt peri-
od, 19=Modulating temp. control, 20=Emergency
control, 23=Adaptive superheat control, 24=Start in-
jection, 25=Manual control, 26=No refrigerant selec-
ted, 29=Case cleaning, 30=Forced cooling, 31=Door
open, 32=Power-up delay, 33=Air heating, 45=Shut
down controller, 48=Adaptive liquid control
Values
0=Normal ctrl., 1=Hold after defrost, 4=Drip off,
10=Main switch OFF, 11=Thermostat cutout, 12=Frost
protection S4, 13=Not_used, 14=Defrost, 15=Fan de-
lay, 16=Forced closing, 17=Door open, 18=Melt peri-
od, 19=Modulating temp. control, 20=Emergency
control, 23=Adaptive superheat control, 24=Start in-
jection, 25=Manual control, 26=No refrigerant selec-
ted, 29=Case cleaning, 30=Forced cooling, 31=Door
open, 32=Power-up delay, 33=Air heating, 45=Shut
down controller, 48=Adaptive liquid control
Code Short name
u00 u00 Ctrl. state
u17 u17 Ther. air
u16 u16 S4 air temp.
u23 u23 EEV OD %
u25 u25 EvapPress Pe
u26 u26 EvapTemp Te
u20 u20 S2 temp.
u21 u21 Superheat
u22 u22 SuperheatRef
n10 n10 Min SH
n09 n09 Max SH
n11 n11 MOP temp.
n13 n13 AKV Period
P87 P87 SH Min Liq.
P86 P86 SH Max Liq.
Code Short name
U74 U74 Ctrl.State B
U77 U77 Ther. Air B
U76 U76 S4 temp B
U82 U82 EEV OD % B
u25 u25 EvapPress Pe
u26 u26 EvapTemp Te
U79 U79 S2 temp. B
U80 U80 Superheat B
U81 U81 SH Ref B
