AK-UI55 display menu (SW ver. 1.9x)

R-W If the operation is protected by one or more passwords, reading and setting the parameter will be limited to:
R or W
R This setting can be seen with password no. _ or higher (3 is the highest level).
W This setting can be performed with password no. _ or higher (3 is the highest level).
* The asterisk indicates in which application from 1-5 the parameter is applicable.

Thermostat

Table 14: Thermostat
Function Values
Cut-out 1
Differential 1
Max. cut-out limit
Min. cut-out limit
Temperature unit 0=Celsius, 1=Fahrenheit
S4 Air OFF evap. A - Adjustment
S5 Evaporator A - Adjustment
Main switch -1=Manual, 0=Stop, 1=Start
Night offset
1=ON/OFF, 2=Modulating,
Thermostat mode
3=ON/OFF Common
Melt interval
Melt period
S2 Gas outlet A - Adjustment
Cut-out 2
Air heater neutral zone
Air heater start delay
0=None, 1=Vegetables, 2=Dairy,
Food type 3=Meat and fish, 4=Frozen food,
5=Ice cream
Differential 2
1=Ther. air A, 2=Average all,
Thermostat sensor
3=Maximum all
(1) (1)
In order to change this parameter the regulation must be stopped via the parameter r12 Main switch = OFF. In order to change this parameter the regulation must be stopped via the parameter r12 Main switch = OFF.

Alarm settings

Table 15: Alarm settings
Function Values
Alarm delay A
Door open alarm delay
Alarm delay pulldown A
High alarm limit 1
Low alarm limit 1
High alarm limit 2
Low alarm limit 2
Alarm delay DI 1
Alarm delay DI 2
