AK-CC55 Multi Coil
Function Values
Control state B 0=Normal ctrl., 1=Hold after defrost,
4=Drip off, 10=Main switch OFF,
11=Thermostat cutout, 12=Frost pro-
tection S4, 13=Not_used, 14=Defrost,
15=Fan delay, 16=Forced closing,
17=Door open, 18=Melt period,
19=Modulating temp. control,
20=Emergency control, 23=Adaptive
superheat control, 24=Start injection,
25=Manual control, 26=No refrigerant
selected, 29=Case cleaning, 30=Forced
cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down
controller, 48=Adaptive liquid control
Defrost time B
S4 Air OFF evap. B
Thermostat air temp. B
Thermostat run time B
S2 Gas outlet B
Superheat B
Superheat reference B
EEV opening B
Control state C 0=Normal ctrl., 1=Hold after defrost,
4=Drip off, 10=Main switch OFF,
11=Thermostat cutout, 12=Frost pro-
tection S4, 13=Not_used, 14=Defrost,
15=Fan delay, 16=Forced closing,
17=Door open, 18=Melt period,
19=Modulating temp. control,
20=Emergency control, 23=Adaptive
superheat control, 24=Start injection,
25=Manual control, 26=No refrigerant
selected, 29=Case cleaning, 30=Forced
cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down
controller, 48=Adaptive liquid control
Defrost time C
S4 Air OFF evap. C
Thermostat air temp. C
Thermostat run time C
S2 Gas outlet C
Superheat C
Superheat reference C
EEV opening C
Alarm air temp. C
Defrost sensor tempera-
ture B
Defrost sensor tempera-
ture C
Dehumidifier 0=OFF, 1=ON
© Danfoss | Climate Solutions | 2022.08
R-W Code 1 2 3
0-X U74 * *
0-X U75 * *
0-X U76 * *
0-X U77 * *
0-X U78 * *
0-X U79 * *
0-X U80 * *
0-X U81 * *
0-X U82 * *
0-X U83 *
0-X U84 *
0-X U85 *
0-X U86 *
0-X U87 *
0-X U88 *
0-X U89 *
0-X U90 *
0-X U91 *
0-X U92 *
0-X U93 * *
0-X U94 *
0-X U96
4 5 Min. value Max. value Fact. value
* * 0 48
* * 0 min 900 min
* * -200.0 °C 200.0 °C
* * -200.0 °C 200.0 °C
* * 0 min 999 min
* * -200.0 °C 200.0 °C
* * -200.0 °C 200.0 °C
* * -200.0 °C 200.0 °C
* * 0 % 100 %
0 48
0 min 900 min
-200.0 °C 200.0 °C
-200.0 °C 200.0 °C
0 min 999 min
-200.0 °C 200.0 °C
-200.0 °C 200.0 °C
-200.0 °C 200.0 °C
0 % 100 %
-200.0 °C 200.0 °C
* * -200.0 °C 200.0 °C
-200.0 °C 200.0 °C
* 0 1
BC365022028193en-000201 | 39
0
0 min
0.0 °C
0.0 °C
0 min
0.0 °C
0.0 °C
0.0 °C
0%
0
0 min
0.0 °C
0.0 °C
0 min
0.0 °C
0.0 °C
0.0 °C
0%
0.0 °C
0.0 °C
0.0 °C
0
