AK-CC55 Multi Coil

AK-CC55 Multi Coil
AK-CC55 Multi Coil – Controlling up to 3 AKV valves.
An application mode setting will configure inputs and outputs for the desired use. There are five applications to
choose from.
Standard enclosure. Typically used for display cases
where the controller is mounted in a tray.
The standard enclosure can be expanded with one or
two external displays.

External display

There are three versions available with different functions:
• AK-UI55 Info: Temperature display.
• AK-UI55 Set: Temperature display with control buttons on the front.
• AK-UI55 Bluetooth: Temperature display with Bluetooth communication, for use with AK-CC55 Connect Mobile
app.
Figure 4: AK-UI55 Info
© Danfoss | Climate Solutions | 2022.08
Figure 5: AK-UI55 Set Figure 6: AK-UI55 Bluetooth
