5.5.2 EPROM Size Selection Jumpers

The EZ-KIT Lite supports 128K x 8, 256K x 8, 512K x 8, and 1M x 8 EPROMs, each of
which is selectable through jumpers JP4 and JP5. The EPROM socket is originally
populated with a 256K x 8 EPROM. If a different EPROM is used, JP4 and JP5 should
be adjusted to accommodate the different size. Table 5-4 shows the pins that the jumpers
for JP4 and JP5 should be connected to.
JP5
3.3Vcc
3.3Vcc
A19
A19

5.5.3 Processor ID Jumpers

During typical operation of the EZ-KIT Lite board, there is only a single DSP in the
system. Jumpers JP7 and JP8 should be checked to guarantee that the board is
configured as a single processor system. In the case where a second processor is
attached to the board through the expansion connectors, these jumpers should be changed
to configure the EZ-KIT Lites' ADSP-21065L processor as processor 1 or processor 2 in
the multiprocessor system. The debug monitor will not properly boot from the EPROM
if the IDs are not configured for a single processor. System configuration options are
shown in Table 5-5.
JP7
GND
GND
Other
Other
www.BDTIC.com/ADI
Table 5-4 EPROM Size Selection
JP4 Description
3.3Vcc 128K x 8, 256K x 8 (factory default)
A18 512K x 8
3.3Vcc Not Used
A18 1M x 8

Table 5-5 Processor Selection

JP8 Description
GND Single Processor (factory default)
Other Processor 1
GND Processor 2
Other INVALID
