1.5 Manual Contents Description

This manual contains the following information:
•
Chapter 1 — Introduction
Provides manual information and Analog Devices contact information.
•
Chapter 2 — Getting Started
Provides software and hardware installation procedures, PC system requirements, and basic
board information.
•
Chapter 3 — Using EZ-KIT Lite Software
Provides information on the EZ-KIT Lite system from a software perspective, and details the
monitor program, EMAFE, and codec.
•
Chapter 4 — Demonstration Programs
Provides information on VisualDSP++ debugger operation with the ADSP-21065L EZ-KIT
Lite, benchmarking utilities, and demonstration programs.
•
Chapter 5 — Working With EZ-KIT Lite Hardware
Provides information on the Hardware aspects of the evaluation system.
•
Chapter 6 — Expansion Connectors
Provides information on EMAFE expansion and descriptions of connector interface signals.
•
Chapter 7 — Reference
Provides information on settings menu commands and demo menu commands.
•
Appendix A — Restrictions & CPLD Code Listing
Provides information on board restrictions you may encounter when using your EZ-KIT
Lite, and the files used on the programmable device(s) on the EZ-KIT Lite board.
•
Appendix B — Bill of Materials
Provides a list of components used in the manufacture of the EZ-KIT Lite board.
Appendix C — Schematics
Provides a resource to allow EZ-KIT Lite board level debugging or to use as a reference
design.
