How to Use
Take ISO21780 TEST-01 as an example to introduce how to use this function.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
2. Use the knob or press the Up/Down key to select 3.Road-Vehicles = Off
3. Use the knob or Left / Right key to select ISO21780, and press [Enter].
4. Use the knob or Left / Right key to select TEST-01, and press [Enter].
5. Press [On/Off] on the front panel to turn on the output.
6. According to the selected trigger method (same as the trigger method of the

4.6.4 Solar Photovoltaic Curve Simulation Function (SAS)

The IT6000B series power system provides the maximum power point tracking
(MPPT) mechanism built-in, and it is very important to test the efficiency of this
MPPT. The PV array/module/cell is a device that converts from light energy to
electric energy. It is made by a simple semiconductor PN junction that the major
output characteristic is that there's only one maximum power point (MPP) at cer-
tain sunlight intensity. The PV inverter is designed to track this point to harvest
enter the function menu.
and press [Enter].
At this time, the lower right corner of the VFD screen displays the
information of the recalled waveform: ISO21780–T01.
LIST function), for example, press [Shift]+[On/Off](Trigger) to trigger the
output of the waveform.
