ITech IT6000B Series User Manual page 31

– IT-E167: Interface card that includes RS-232 communication interface,
external analog and other functions.
The accessory has a total of 10 pins, and the details of each pin are as
follows:
Pins Description
1 RS-232 TXD pin for transmitting data.
2 RS-232 RXD pin for receiving data.
3 RS-232 DGND pin for grounding.
4 Ground terminal, that is, the negative terminal of pin 5 to pin
10.
5 Voltage monitoring terminal. It can output a voltage of 0 to
10V to monitor the output voltage from 0 to full scale.
6 Current monitoring terminal.
(In Source mode) It can output a voltage of –10V to 10V to
monitor the output current from negative full scale to positive
full scale.
(In Load mode) It can output a voltage of 0 to 10V to monitor
the output current from 0 to full scale input current.
7 Reference voltage (10V) test terminal. The accuracy is
0.03%. You can use a multimeter to measure this pin. When
the output voltage of the pin is in the range of 10±0.03%*10, it
indicates that the accessory is functioning normally. Other-
wise, the function is abnormal and cannot be used.
8 / 9 / Terminals for external analog function. For details, see
10 Source Analogue Function (Ext-Program) (Optional)
loadAnalogue Function (Ext-Program)
•
Fiber optic modules and cables
Copyright © Itech Electronic Co., Ltd.
Quick Reference
6.12
and 6.13
(Optional).
19
