The configuration parameters are different under Source mode and Load mode,
please select the mode at first.
The procedures to operate the configuration menu are as follows.
1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
the configuration menu.
The VFD shows configuration menu items and each menu item is marked
with a number. The user can use up and down keys or knob to scroll pages
to view the other menu items.
2. Press [Enter] to select the desired menu item.
Enter the parameter setting interface of this menu item.
3. After finishing the menu setting, press [Enter] key to save the setting.
Press [Esc] key to return to the previous menu level.
The descriptions of configuration menu of the power supply are listed in the ta-
ble below.
Config Configuration menu of the power supply
Mode
V-Rise Time/I-Rise Time
= 0.001s
V-Fall Time/I-Fall Time =
0.001s
Copyright © Itech Electronic Co., Ltd.
CC/CV priority mode setting
Constant voltage loop priority mode
CV
Speed= High/Low
Constant current loop priority mode
CC
Speed= High/Low
Displays the voltage or current rise time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Rise Time will
be displayed here.
Displays the voltage or current fall time
setting according to the selected priority
Quick Reference
Loop response
speed setting:
high speed /
low speed
Loop response
speed setting:
high speed /
low speed
