This instrument (in Source mode) supports battery discharge test in constant
current and constant power modes. If the user wants to discharge in constant
current mode, enter the Config menu, select the CC priority, set Vl to 0, set
Vh to the rated voltage value of the instrument, set P- to the rated power val-
ue of the instrument, and then set the Battery menu according to the test re-
quirements. If the user wants to discharge in constant power mode, set P- to
the specified value, and set Discharge V and Discharge I to the rated volt-
age and current value of the instrument.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].
The interface is displayed as follows:
FUNCTION BATTERY
Run Edit
3. Press the Left/Right key to select Edit and press [Enter].
4. Press the Left/Right key to select Charge or Discharge and press [Enter].
5. Set the charging voltage (Charge V) or discharging voltage (Discharge V),
charging current (Charge I) or discharging current (Discharge I) and the
other parameters, and then press [Enter] to confirm.
Copyright © Itech Electronic Co., Ltd.
Cut Off Voltage
Cut Off Current
Cut Off Capacity
Power Supply Function
according to the
selected test
mode.
Set the current val-
ue for charging or
Charge /
discharging ac-
Discharge I
cording to the se-
lected test mode.
Set the charging
Charge / or discharging
Discharge time according to
Time the selected test
mode.
Battery test cut-off voltage
Battery test cut-off current
Battery test cut-off capacity
