When connecting the DUT (battery/capacitor), do not short-circuit
the battery/capacitor.
•
It is recommended that for battery testing, a fuse must be con-
nected in series between the power supply and the battery to pre-
vent short circuits caused by any problems.
•
When connecting the DUT (including but not limited to battery/ca-
pacitor), it is recommended that you purchase the IT-E165A anti-re-
verse connection and anti-spark module to prevent the battery/
capacitor reverse connection that may cause damage to the instru-
ment and spark during the battery/capacitor wiring; When there is
no external auxiliary equipment connected to prevent reverse con-
nection and anti-spark function, please pay attention to the safety
of the wiring, and be careful not to reverse the battery/capacitor
connection, reverse connection will cause damage to the instru-
ment, even if it is not powered on.
•
Before performing the battery test, you need to connect the Sense
cables to both ends of the battery. If the Sense cables are not con-
nected, the instrument cannot detect the Sense voltage and prompt
"Wait Power Link", which will prevent the battery test from
continuing.
BATTERY Battery charging/discharging test function
Run
Edit
Copyright © Itech Electronic Co., Ltd.
Indicates that the battery test mode is entered and
waits to trigger the running of the currently edited bat-
tery test file.
Edit the battery charging/discharging test file.
Charge /
Discharge
Power Supply Function
Set the test mode:
•
Charge: Battery charging
•
Discharge: Battery
discharging
According to the test require-
ments, choose one to set.
Set the voltage
Charge /
value for charging
Discharge
or discharging
V
