Edit List Program
The following takes CC mode as an example to introduce the operation of edit-
ing two test steps.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
2. Select 1. LIST: Off and press [Enter].
3. Press the Left/Right key to select Edit and press [Enter] to enter the editing
4. Select CC and press [Enter] to confirm.
5. Set the total number of steps in the List program and press [Enter] to
6. Set the current, slope and time width of step 1 in turn, and press [Enter] to
7. Set the parameters of step 2 in the same method.
8. Set the number of list repetitions Repeat, and press [Enter] to confirm.
Trig Out
Save to
group
ter the function menu.
interface.
confirm.
confirm.
Copyright © Itech Electronic Co., Ltd.
Last
After the List program finishes run-
ning, the input is kept as the setting
in the last step, and the working
mode remains as the setting in the
List file.
Normal
After the List program finishes run-
ning, the working mode and input
return to the settings before the
List running.
Function switch that triggers the signal output. It
is applicable to the scenario of synchronously
controlling multiple units, that is, by connecting
the outer loop interfaces TX and RX of the fiber to
realize List synchronization triggering between
multiple units.
None
Turn off (default)
Tout
Turn on
Save the edited List program.
Load Function
158
