1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
2. Use the knob or press the Up/Down key to select 3.Road-Vehicles = Off
3. Press the Left/Right key to select LV123, and press [Enter] to confirm.
4. Press the Left/Right key to select Curve→Edit→unlimited→HV_1, and press
5. Set start voltage = 50V, start time = 0.1S, end time = 0.1S and count = 1.
6. Set Save To File = 1, and press [Enter] to confirm.
7. Select Open→Recall File in the main interface of LV123. Set to 1, and press
8. Select RUN in the main interface of LV123, and press [Enter] to confirm.
9. Press [On/Off] on the front panel to turn on the output.
10. According to the selected trigger method (same as the trigger method of the
4.6.3.6 LV124
The built-in curves LV124 can meet general requirements, test conditions and
tests of electrical and electronic components in motor vehicles up to 3.5 t. Re-
lated parameters are as below:
LV124
ter the function menu.
and press [Enter].
[Enter] to confirm.
[Enter] to confirm.
At this time, the information of the recalled waveform is displayed in the low-
er right corner of the VFD screen: R1/HV_1/00001, which is represented as
the interval type of the waveform, the type of the regulation, and how many
times the waveform has been executed cyclically.
LIST function), for example, press [Shift]+[On/Off](Trigger) to trigger the
output of the waveform.
LV124 waveform protocol
E-02
E-04
E-05
E-07
Copyright © Itech Electronic Co., Ltd.
Transient overvoltage test waveform
Jump start test waveform
Load dump test waveform
Slow decrease and increase of the supply
voltage test waveform
Ubmax Start voltage
Ubmin Holding voltage
Power Supply Function
