Minimum high level input
voltage
Typical high level output
voltage
Typical low level output
voltage
Level rise slope
Level fall slope
Pins Introduction
The appearance of the terminals are shown below.
Pin
1
2
3
The maximum sink current of each pin is 100mA, and the maximum output
current is 1mA.
Description
Corresponds to the function set in the
System→Digital Port→IO–1. Ps-
Clear, Not-Invert menu item. For pa-
rameter introduction, see
1. Ps-Clear, Not-Invert.
Corresponds to the function set in the
System→Digital Port→IO–2. Ps,
Not-Invert menu item. For parameter
introduction, see 6.11.2 IO–2. Ps,
Not-Invert.
Corresponds to the function set in the
System→Digital Port→IO–3. Off-
Copyright © Itech Electronic Co., Ltd.
1.6V
5V
0V
10us
2us
Properties
(Default
function)
Pulse signal
6.11.1 IO–
Level signal
Level signal
Basic Operation
Properties
(General I/O
function)
Level or PWM
signal
Level or PWM
signal
Level or PWM
signal
