Page 1 297-1001-330 DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up Standard 11.04 June 1998...
Page 3 DMS-100 Family Switch Performance Monitoring System Application Guide Publication number: 297-1001-330 Product release: BASE09 and up Document release: Standard 11.04 Date: June 1998 1989, 1990, 1991, 1992, 1993, 1995, 1996, 1997, 1998 Northern Telecom All rights reserved Printed in the United States of America NORTHERN TELECOM CONFIDENTIAL: The information contained in this document is the property of Northern Telecom.
Page 5 Publication history June 1998 BASE09 Standard 11.04 Technical review changes based on ProStar 80807. February 1998 BASE09 Standard 11.03 Added indices AOPSPERF, APUFLT, ARUDAAV, ARUFLT, DAMSGFLT, VSNFLT, and VSNLKFLT to the Operator Position Performance (OPPOSPF) aggregate index. Revised the diagnostics description for basic index C7TRKCFL: references to ISUP105, ISUP106, and ISUP107 logs changed to C7UP105, C7UP106, and C7107 logs.
Page 6 iv Publication history Revisions associated with PRS BY38912 and PRS BY43417 November 1995 BCS36 Standard 10.03 Added information on CONF60VF using the sum of CF6P measurement CF6OVFL. December 1993 BCS36 Standard 10.02 Added a note about the SPMS R95 and R80 values September 1993 BCS36 Preliminary 10.01 updated aggregate indices XPMPERF, LMPERF, and LCMPERF...
Page 7 Publication history v expanded the list of terms to include definitions October 1991 BCS33 Standard 09.01 modified startup procedures to include detailed information included the procedure to assign the OMRS report to table LOGCLASS included the explanation of the fields in table LOGCLASS added the procedure for defining the printer in order to print an automatic SPMS report documented the aggregate index SMNMPF and the following basic...
Page 9: Table Of Contents
Contents About this document When to use this document xv How to check the version and issue of this document xv What precautionary messages mean xv How commands, parameters, and responses are represented xvii Input prompt (>) xvii Commands and fixed parameters xvii Variables xvii Responses xvii What is the switch performance monitoring system?
Page 10 viii Contents How the indices are presented 5-1 Aggregate index SERVICE 5-3 Aggregate index MTCESERV 5-4 Basic index OUTSIGFL 5-5 Aggregate index MTCACCS 5-6 Basic index CCRESET 5-7 Basic index ORGLNOUT 5-8 Basic index ORGPMBLK 5-9 Aggregate index INSIGFL 5-10 Basic index TINSIGFL 5-11 Basic index LINSIGFL 5-12 Basic index MISCFL 5-13...
Page 11 Contents ix Basic index CCNOSYNC 6-8 Aggregate index CMCPERF 6-9 Basic index CMCERR 6-10 Basic index CMCFLT 6-11 Basic index CMCUSOUT 6-12 Basic index CMCUMOUT 6-13 Aggregate index IOCPERF 6-14 Basic index IOCERR 6-15 Basic index IOCFLT 6-16 Basic index IOCUSOUT 6-17 Basic index IOCUMOUT 6-18 Aggregate index EIOCPERF 6-19 Basic index EIOCERR 6-20...
Page 12 x Contents Basic index APNOSYNC for SuperNode CONTROL components 6-60 Aggregate index SOSPMPF 6-61 Basic index SOSPMERR 6-62 Basic index SOSPMFLT 6-63 Basic index SOSPMMOU 6-64 Basic index SOSPMSOU 6-65 Aggregate index TMPERF 6-66 Basic index TMERR 6-67 Basic index TMFLT 6-68 Basic index TMUSOUT 6-69 Basic index TMUMOUT 6-70 Aggregate index DCMPERF 6-71...
Page 13 Contents xi Basic index CMCLKSOU 6-113 Basic index CMCLKMUO 6-114 Aggregate index IOCLNKPF 6-115 Basic index IOCLNKER 6-116 Basic index IOCLKSUO 6-117 Basic index IOCLKMUO 6-118 Aggregate index MSLNKPF for SuperNode LINKPERF components 6-119 Basic index MSLNKERR for SuperNode LINKPERF components 6-120 Basic index MSLNKFLT for SuperNode LINKPERF components 6-121 Basic index MSLNKSUO for SuperNode LINKPERF components 6-122 Basic index MSLNKMUO for SuperNode LINKPERF components 6-123...
Page 14 xii Contents Aggregate index CONSOLPF 6-167 Basic index CSLERR 6-168 Basic index CSLSOUT 6-169 Basic index CSLMOUT 6-170 Aggregate index SRVCCTPF 6-171 Aggregate index CONFPERF 6-172 Basic index CNF3PERF 6-173 Basic index CNF6PERF 6-174 Basic index ANNSTNPF 6-175 Basic index ESUPPERF 6-176 Basic index RCVRPERF 6-177 Basic index SPECSVPF 6-178 Aggregate index OPPOSPF 6-179...
Page 15 Contents xiii Basic index CARRMOUT 6-217 Aggregate index C7RTPERF 6-218 Aggregate index C7ROUTE 6-219 Basic index C7RTDEGR 6-220 Basic index C7RTOUT 6-221 Aggregate index C7RTSET 6-222 Basic index C7RTSTCO 6-223 Basic index C7RTSTOU 6-224 SPMS PROVRES index descriptions Where to find an index 7-1 How the indices are presented 7-1 Aggregate PROVRES 7-3 Aggregate index CPRES 7-4...
Page 16 xiv Contents How SPMS index values are calculated Basic indices 9-1 Aggregate indices 9-1 Calculating basic indices 9-1 Calculating aggregate indices 9-3 List of terms 10-1 297-1001-330 Standard 11.04 June 1998...
Page 17: About This Document
About this document When to use this document This document provides information and index descriptions for the switch performance monitoring system (SPMS). It is intended for use by operating companies with feature package NTX738AB. How to check the version and issue of this document The version and issue of the document are indicated by numbers, for example, 01.01.
Page 18 xvi About this document information or data. Danger, warning, and caution messages indicate possible risks. Examples of the precautionary messages follow. ATTENTION Information needed to perform a task ATTENTION If the unused DS-3 ports are not deprovisioned before a DS-1/VT Mapper is installed, the DS-1 traffic will not be carried through the DS-1/VT Mapper, even though the DS-1/VT Mapper is properly provisioned.
Page 19: How Commands, Parameters, And Responses Are Represented
About this document xvii How commands, parameters, and responses are represented Commands, parameters, and responses in this document conform to the following conventions. Input prompt (>) An input prompt (>) indicates that the information that follows is a command: >BSY Commands and fixed parameters Commands and fixed parameters that are entered at a MAP terminal are shown in uppercase letters:...
Page 21: What Is The Switch Performance Monitoring System
What is the switch performance monitoring system? The switch performance monitoring system (SPMS) is a series of index values that describe how well the switch is operating. Performance results are displayed in a report. Index values are computed from switch-generated operational measurements (OM) on a daily and customer-defined monthly basis.
Page 22 1-2 What is the switch performance monitoring system? SPMS provides a medium-term review comprising detailed as well as summary level index values. This makes deviations from desired results easy to trace back to their origin. SPMS produces performance indices covering all areas of switch operation. Each index is standardized so that an index result of 100 indicates perfect performance an index result of 95 indicates average performance as observed over a...
Page 23 What is the switch performance monitoring system? 1-3 In many cases, events and conditions flagged by SPMS will have already been acted upon, or may reflect the results of maintenance actions. It is important to keep a record of all maintenance actions affecting the operation of the switch, from parameter changes through card changes.
Page 25: Startup Procedures
Access table OFCENG by typing >TABLE OFCENG and pressing the Enter key. Note: If the system responds with a request for a password, contact your Nortel representative immediately. MAP response: TABLE: OFCENG Position on the required tuple by typing >POS SPMS_START_OF_MONTH and pressing the Enter key.
Page 26 2-2 Startup procedures automatically generated reports that are in table OMREPORT. The reports assigned to table OMREPORT are called OMRS reports. There are 24 provisionable reports in table OMEREPORT. Only 23 or fewer can be assigned by the operating company, the remaining are designated the report name *SPARE*.
Page 27 Startup procedures 2-3 Access the time tuple by typing >DEVDAY and pressing the Enter key. MAP response: WHEN: Enter the time of your choice, for example 8:30, by typing >8 C30 and pressing the Enter key. MAP response: CLASS:HOLDING Press the Enter key. MAP response: NAME:*SPARE* Enter the name of the report by typing...
Page 28: Assigning Omrs Report To Table Logclass
2-4 Startup procedures Assigning OMRS report to table LOGCLASS Follow the procedure below to assign the OMRS report to a log class in table LOGCLASS. Access table LOGCLASS by typing >TABLE LOGCLASS and pressing the Enter key. Add the report to table LOGCLASS by typing >ADD and pressing the Enter key.
Page 29: Explanation Of Table Logclass Fields
Startup procedures 2-5 MAP response: TUNITS: Type > 1 and press the Enter key. MAP response: SYSLOG: Type >N and press the Enter key. MAP response: TUPLE TO BE ADDED: OMRS231 15 ENTER Y TO CONFIRM, N TO REJECT OR E TO EDIT. Confirm the command by typing >Y and pressing the Enter key.
Page 30: Defining A Printer
2-6 Startup procedures SYSLOG identifies whether or not a log is a syslog. Defining a printer To print the log assigned to OMRS report, route the log to a printer. If the devices already exist in table LOGDEV, perform the following procedure. If the devices do not exist in the table LOGDEV, perform the procedure on page 2-8.
Page 31 Startup procedures 2-7 Identify the printer of choice and position on that device by typing >POS MAPPRT and pressing the Enter key. MAP response example: MAPPRT NONE (0-2, 4-7) Add the log assigned to the OMRS report to the printer of your choice by typing >CHA and pressing the Enter key.
Page 32 2-8 Startup procedures Press the Enter key. MAP response: TUPLE TO BE CHANGED: MAPPRT NONE (0-2, 4-7, 15) ENTER Y TO CONFIRM, N TO REJECT OR E TO EDIT. Confirm the command by typing >Y and pressing the Enter key. MAP response example: TUPLE CHANGED WRITTEN TO JOURNAL FILE AD JF NUMBER 1716...
Page 33 Startup procedures 2-9 Enter the printer by typing >MAPPRT and pressing the Enter key. MAP response: ALT: Enter the alternative device, if any, by typing >NONE and pressing the Enter key. MAP response: CLASSES: Enter the log class you assigned to the OMRS report by typing >’(15) and pressing the Enter key.
Page 34: The Setrep Subcommand
2-10 Startup procedures Type Y or N and press the Enter key. MAP response: TUPLE TO BE ADDED: MAPPRT NONE (0-2, 4-7, 15) ENTER Y TO CONFIRM, N TO REJECT OR E TO EDIT. Confirm the command by typing >Y and pressing the Enter key.
Page 35 Startup procedures 2-11 EXCEPTVAL indicates which indices to suppress and which to include in the trees selected by TREETOPS. This value must be divided by ten to arrive at the index value it represents (for example, 950 represents 95.0). When the DISPLAY subcommand is used, only those indices with values less than the exception value are displayed;...
Page 36: The Set Subcommand
2-12 Startup procedures Figure 2–1xxx Automatically generated SPMS report 89/07/12 <<*>> F04314_00 SITE NAME BCS29ZI RTM 041289 <<*>> 1989/12/08 15:24:30.825 FRI. 891207 89 DEC 89 NOV TO DATE TOTATT (K) 1298 SERVICE 88.4* 93.6 98.0 ..MTCESERV 81.4* 90.1 98.0 ..MTCACCS 44.5** 73.0** 98.9...
Page 37 Startup procedures 2-13 TREEDEPTH indicates how many levels should be included below the indicated TREETOPS indices. Level 0 includes the TREETOPS indices only, level 1 adds their child indices in the tree, level 2 adds the children of the children, and so on. The default value of TREEDEPTH is 10, which is sufficient to include all lower-level indices contributing to the selected TREETOPS indices.
Page 38 2-14 Startup procedures Use of the LONG parameter and the DISPLAY subcommand produces a report similar to the one in Figure 2-2. Figure 2–2xxx Long format of SPMS report SITE NAME 89/07/12 <<*>> F04314_00 BCS29ZI RTM 041289 <<*>> 1989/12/08 15:24:30.825 FRI. R_95 R_80 891207...
Page 39 Startup procedures 2-15 Figure 2–3xxx Short format of SPMS report 89/07/12 <<*>> F04314_00 SITE NAME 1989/12/08 15:24:30.825 FRI. 891207 89 DEC 89 NOV TO DATE TOTATT (K) 1298 SERVICE 88.4* 93.6 98.0 ..MTCESERV 81.4* 90.1 98.0 ..MTCACCS 44.5** 73.0** 98.9 ..CCRESET 0.0** 51.3**...
Page 40: The Display Subcommand
2-16 Startup procedures UNSATLEVEL is the upper limit of unsatisfactory performance for an index. Values below this number, but higher than UNACCLEVEL, are marked with an asterisk (*) in SPMS reports. This value must be divided by ten to arrive at the index value it represents (for example, 750 represents 75.0).
Page 41 Startup procedures 2-17 Type >DISPLAY and press the Enter key. After you enter the commands, SPMS displays every aggregate and basic index for the latest day, beginning with the SERVICE index, and provides a report similar to the one in Figure 2-4. Figure 2–4xxx Manually-generated SPMS report...
Page 42 2-18 Startup procedures Type >DISPLAY DATE 89 12 02 and press the Enter key. Indices are displayed in a stepped format that represents their hierarchical relationship. Basic indices always appear to the far right in a report. Exception reports are generated by the DISPLAY subcommand when EXCEPTVAL is set to less than its default values.
Page 43: The Describe Subcommand
Startup procedures 2-19 Figure 2–5xxx SPMS report produced with EXCETIVAL set less than default 89/07/12 <<*>> F04314_00 SITE NAME BCS29ZI RTM 041289 <<*>> 1989/12/08 15:24:30.825 FRI. PRINTING INDICES<90.0 FOR LAST 1 DAY(S). R_95 R_80 891207 89 DEC 89 NOV TO DATE TOTATT (K) 1298 44.5...
Page 44: The Exception Subcommand
2-20 Startup procedures SPMS responds with Basic Index Calls denied origination during a CC restart OM: CP INITDENY If you enter the following (two) indices: >DESCRIBE CCCTO PMDNY SPMS responds with CCCTO Basic index Call cutoffs because of CC cold restarts OMs: CP CINITC PMDNY Basic index...
Page 45: Totatt (K)
Startup procedures 2-21 Figure 2–6xxx SPMS response to EXCEPTION subcommand SITE NAME 89/07/12 <<*>> F04314_00 1989/12/08 15:24:30.825 FRI. PRINTING INDICES<90.0 FOR LAST 1 DAY(S). 89 DEC 891207 89 NOV TO DATE TOTATT (K) 1298 OFCPERF 86.4* 92.7 98.7 ..SERVICE 69.3** 84.1 99.5 ..MTCACCS...
Page 47: The Indexing Hierarchy
The indexing hierarchy SPMS generates approximately 300 indices, covering all aspects of switch operation. This is too much information to handle all at once. The indices are therefore arranged in a hierarchy, or “tree.” Indices at higher levels in the tree summarize the performance that is described in detail at lower levels.
Page 48: Spms Structure For Dms-100
3-2 The indexing hierarchy error counts, fault counts, or outage durations for the various switch components. The provisionable resources index (PROVRES) summarizes the performance of traffic provisionable resources for both hardware and software within the switch. Most of its basic indices track rates of overflow or blocking.
Page 49 The indexing hierarchy 3-3 Figure 3-2xxx Hierarchy of indices that relate to DMS-100 OFCPERF (Office Performance) SERVICE MTCEPERF MTCESERV PROVSERV CONTROL BILLPERF MTCACCS PROVACCS CCPERF METERPF CCRESET DTSR CCERRINT AMADEVFL ORGLNOUT PMDNY CCFLT ORGPMBLK MISCDNY CCNOSYNC TMPERF MISCBLK CMCPERF INSIGFL TMERR TINSIGFL CMCERR...
Page 50 3-4 The indexing hierarchy Figure 3-2xxx Hierarchy of indices that relate to DMS-100 OFCPERF (Office Performance) (Cont’d.) MTCEPERF (Cont’d.) PROVRES LINKPERF TERMNALS CPRES FTRQRES CMCLNKPF IODEV CCOCCUP FQAGOVFL CMCLNKER MTUPERF CCBOVFL FQ0WOVFL CMCLKSUO MTUERR CPMAXBSY FQ2WOVFL MTUFLT CPLOVFL CMCLKMOU FQ4WOVFL OUTBOVFL MTUSOUT FQ8WOVFL...
Page 51 The indexing hierarchy 3-5 Figure 3-2xxx Hierarchy of indices that relate to DMS-100 OFCPERF (Office Performance) (Cont’d.) PROVRES (Cont’d.) SRVCTRES CHANRES EXTBLKS ANNOVFL NETCHOVF FTREXT STNOVFL LPMCHAN PERMXOVF UTROVFL CCISIXOV ESUPOVFL TWCXOVFL SPSVOVFL MTXHOVFL CFWXOVFL CONFRES CSDDPXOV CONF3OVF ROTLPXOV CONF60VF CWTXOVFL IBNCQXOV RCVRES...
Page 52: Spms Structure For Supernode
3-6 The indexing hierarchy SPMS structure for SuperNode The following figure shows the hierarchy of indices that relate to SuperNode. The major differences between the SPMS structure for SuperNode and the SPMS structure for DMS-100 are the CONTROL and LINKPERF sections. 297-1001-330 Standard 11.04 June 1998...
Page 53 The indexing hierarchy 3-7 Figure 3-3xxx Hierarchy of indices that relate to SuperNode OFCPERF (Office Performance) SERVICE MTCEPERF MTCESERV PROVSERV CONTROL BILLPERF MTCACCS PROVACCS CMPERF NMPTOUT CCRESET DTSR CMERRINT NMJCTOUT ORGLNOUT PMDNY CMFLT ORGPMBLK MISCDNY CMNOSYNC INSIGFL MISCBLK MSPERF TMPERF TINSIGFL MSERR TMERR...
Page 54 3-8 The indexing hierarchy Figure 3-3xxx Hierarchy of indices that relate to SuperNode OFCPERF (Office Performance) (Cont’d.) MTCEPERF (Cont’d.) PROVRES LINKPERF TERMINALS CPRES FTRQRES MSLNKPF IODEV CCOCCUP FQAGOVFL MSLNKERR MTUPERF CCBOVFL FQ0WOVFL MSLNKFLT MTUERR CPMAXBSY FQ2WOVFL CPLOVFL MSLNKSUO MTUFLT FQ4WOVFL MSLNKMOU MTUSOUT OUTBOVFL...
Page 55 The indexing hierarchy 3-9 Figure 3-3xxx Hierarchy of indices that relate to SuperNode OFCPERF (Office Performance) (Cont’d.) PROVRES (Cont’d.) SRVCTRES CHANRES EXTBLKS ANNOVFL NETCHOVF FTREXT STNOVFL LPMCHAN PERMXOVF UTROVFL CCISIXOV ESUPOVFL TWXCXOVFL SPSVOVF MTXHOVFL CFWXOVFL CONFRES CSDDPXOV CONF3OVF ROTLPXOV CONF60VF CWTXOVFL IBNCQXOV RCVRES...
Page 56: Spms Structure For Enet
3-10 The indexing hierarchy SPMS structure for ENET The following figure shows the hierarchy of indices that relate to ENET. The major differences between the SPMS structure for ENET and the SPMS structure for SuperNode are the network module sections. 297-1001-330 Standard 11.04 June 1998...
Page 57 The indexing hierarchy 3-11 Figure 3-4xxx Hierarchy of indices that relate to ENET OFCPERF (Office Performance) SERVICE MTCEPERF MTCESERV PROVSERV BILLPERF CONTROL METERPF MTCACCS PROVACCS CMPERF AMADEVFL CCRESET DTSR CMERRINT ORGLNOUT PMDNY CMFLT ORGPMBLK MISCDNY CMNOSYNC INSIGFL MISCBLK MSPERF LMPERF TINSIGFL MSERR LMERR...
Page 58 3-12 The indexing hierarchy Figure 3-4xxx Hierarchy of indices that relate to ENET OFCPERF (Office Performance) (Cont’d.) MTCEPERF (Cont’d.) PROVRES TERMNALS LINKPERF CPRES FTRQRES IODEV MSLNKPF CCBOVFL FQAGOVFL MTUPERF MSLNKERR CPLOVFL FQ0WOVFL MTUERR MSLNKFLT OUTBOVFL FQ2WOVFL MTUFLT MULTBOVF MSLNKSUO FQ4WOVFL MTUSOUT WAKEOVFL MSLNKMOU...
Page 59 The indexing hierarchy 3-13 Figure 3-4xxx Hierarchy of indices that relate to ENET OFCPERF (Office Performance) (Cont’d.) PROVRES (Cont’d.) SRVCTRES CHANRES EXTBLKS ANNOVFL NETCHOVF FTREXT STNOVFL LPMCHAN PERMXOVF UTROVFL CCISIXOV ESUPOVFL TWXCXOVFL SPSVOVF MTXHOVFL CFWXOVFL CONFRES CSDDPXOV CONF3OVF ROTLPXOV CONF60VF CWTXOVFL IBNCQXOV RCVRES...
Page 60: Spms Structure For Dms-100G Switch
3-14 The indexing hierarchy SPMS structure for DMS-100G Switch The following figure shows the hierarchy of indices that relate to DMS-100G switch. 297-1001-330 Standard 11.04 June 1998...
Page 61 The indexing hierarchy 3-15 Figure 3-5xxx Hierarchy of indices that relate to DMS-100G Switch OFCPERF (Office Performance) SERVICE MTCEPERF MTCESERV PROVSERV CONTROL BILLPERF MTCACCS PROVACCS CMPERF NMPTOUT CCRESET DTSR CMERRINT NMJCTOUT ORGLNOUT PMDNY CMFLT ORGPMBLK MISCDNY CMNOSYNC INSIGFL MISCBLK MSPERF TMPERF TINSIGFL MSERR...
Page 62 3-16 The indexing hierarchy Figure 3-5xxx Hierarchy of indices that relate to DMS-100G Switch OFCPERF (Office Performance) (Cont’d.) MTCEPERF (Cont’d.) PROVRES LINKPERF TERMINALS CPRES FTRQRES MSLNKPF IODEV CCOCCUP FQAGOVFL MSLNKERR MTUPERF CCBOVFL FQ0WOVFL MSLNKFLT MTUERR CPMAXBSY FQ2WOVFL CPLOVFL MSLNKSUO MTUFLT FQ4WOVFL MSLNKMOU MTUSOUT...
Page 63 The indexing hierarchy 3-17 Figure 3-5xxx Hierarchy of indices that relate to DMS-100G Switch OFCPERF (Office Performance) (Cont’d.) PROVRES (Cont’d.) SRVCTRES CHANRES EXTBLKS ANNOVFL NETCHOVF FTREXT STNOVFL LPMCHAN PERMXOVF UTROVFL CCISIXOV ESUPOVFL TWXCXOVFL SPSVOVF MTXHOVFL CFWXOVFL CONFRES CSDDPXOV CONF3OVF ROTLPXOV CONF60VF CWTXOVFL IBNCQXOV...
Page 65: How To Interpret Spms Reports
How to interpret SPMS reports SPMS indices has been calibrated using OM data from a large number of switches under normal working conditions. Day-to-day fluctuations in the indices of a few percent is normal, and not a cause for concern. If large variations in values do occur, they should be immediately investigated.
Page 66: Daily And Report Month Results
How to interpret SPMS reports 4-2 with successive days (if applicable) printed in separate columns across the page. The two final results shown for each index are the report month averages for the current month to date and the previous complete month (these are the only results shown if 0 days are requested).
Page 67: Demand Reports
How to interpret SPMS reports 4-3 At 23:50 each evening, under normal circumstances, the following events take place: SPMS swaps accumulating registers so that OMs from midnight onwards are added into a new set (which has previously been initialized to zeros). The old set is available for further calculations. SPMS completes the work needed prior to index calculation by acquiring various equipment counts needed as normalization factors.
Page 68: Operation In Abnormal Circumstances
How to interpret SPMS reports 4-4 shows total call volume for each day and flags those days on which reload restarts or reboots caused loss of data. Operation in abnormal circumstances Warm and cold restarts during the day interfere to some extent with the OM transfer process.
Page 69: Date Changes
How to interpret SPMS reports 4-5 what is happening with the journal file subsystem, not on the time of the restart itself. At times other than the first calculation after a reboot or reload restart, no check of the status of the journal file is made. If the journal file subsystem is not operating on any particular day, that day’s results are vulnerable to loss if a reboot occurs.
Page 71: Spms Service Index Descriptions
SPMS SERVICE index descriptions The following chapter provides index descriptions for the SERVICE branch of SPMS. The service index (SERVICE) summarizes switch performance as seen by the users of the switch. The high-level SERVICE index has two main branches, the maintenance service index (MTCESERV) and the provisioning service (PROVSERV) index.
Page 72 5-2 SPMS SERVICE index descriptions definition diagnostics The information under these headings explains: the section below the SERVICE branch to which the index belongs the expansion of the index name the function and purpose of the index the steps required to locate the switch problem The following headings appear in each description of a basic index: section description...
Page 73: Aggregate Index Service
SPMS SERVICE index descriptions Aggregate index SERVICE Section The service (SERVICE) index is a top level office performance (OFCPERF) index. The service index derives data from the maintenance service (MTCESERV) and the provisional service (PROVSERV) indices. Description Service Definition The summary of switch performance from the caller’s viewpoint. This index monitors the rate of failure for call attempts at various stages of processing.
Page 74: Aggregate Index Mtceserv
SPMS SERVICE index descriptions Aggregate index MTCESERV Section MTCESERV Description Maintenance service SPMS SERVICE SPMS SERVICE index descriptions SPMS SERVICE index descriptions Definition The summary of the maintenance contribution to service, as experienced by the caller. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 75: Basic Index Outsigfl
SPMS SERVICE index descriptions Basic index OUTSIGFL Section MTCESERV Description Outgoing line failure Definition The proportion of outgoing calls not completed as a result of outpulsing failure. DMS-100G Switch does not contribute to or provide an equivalent of OM group OFZ, measurements INOUT and OUTROSF. Measurement list OUTSIGFL is based on OFZ OUTROSF (SOTS SOUTROSF in International offices).
Page 76: Aggregate Index Mtcaccs
SPMS SERVICE index descriptions Aggregate index MTCACCS Section MTCESERV Description Maintenance access Definition The summary of the maintenance contribution to the caller’s ability to gain access to the switch. It includes dial tone and start-to-dial signal. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 77: Basic Index Ccreset
SPMS SERVICE index descriptions Basic index CCRESET Section MTCESERV Description Central control reset Definition The number of calls denied access to the switch during central controller restarts, as a proportion of total calls offered to the switch. DMS-100G Switch does not contribute to or provide an equivalent of: OM group CP, measurement INITDENY OM group OFZ, measurements NIN, and NIN2 Measurement list...
Page 78: Basic Index Orglnout
SPMS SERVICE index descriptions Basic index ORGLNOUT Section MTCESERV Description Originating line outage Definition The estimated fraction of originating call attempts denied access to the switch because lines or the peripherals serving those lines are maintenance busy. Besides individual cases of line, PM, or network failure, ORGLNOUT captures the lag in PM restoration subsequent to reload restarts.
Page 79: Basic Index Orgpmblk
SPMS SERVICE index descriptions Basic index ORGPMBLK Section MTCESERV Description Originating PM block Definition The proportion of line originations rejected by the CC because no path is available through the PM links to the core network. The peripherals re-originate the calls as long as the callers stay off-hook. Measurement list The measurement used for ORGPMBLK is the sum over all tuples of LMD ORIGBLK.
Page 80: Aggregate Index Insigfl
5-10 5-10 SPMS SERVICE index descriptions 5-10 Aggregate index INSIGFL Section MTCESERV Description Incoming signal failure Definition The summary of the failure to receive digits properly. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 81: Basic Index Tinsigfl
5-11 SPMS SERVICE index descriptions 5-11 5-11 Basic index TINSIGFL Section MTCESERV Description Incoming signal failure for trunks Definition The proportion of incoming call attempts that fail during the digit reception stage. This index counts the following events: permanent signal and partial dial occurring on machine-dialed trunks, and defective incoming signaling on any trunk.
Page 82: Basic Index Linsigfl
5-12 5-12 SPMS SERVICE index descriptions 5-12 Basic index LINSIGFL Section MTCESERV Description Incoming signal failure for lines Definition The proportion of originating call attempts that fail during dial because of bad digits. DMS-100G Switch does not contribute to or provide an equivalent of OM group SYSPERF.
Page 83: Basic Index Miscfl
ORGABDN, and ORGLKT minus TRMTCU TCUORSS. Diagnostics Ensure that Nortel Field Technical Support is notified promptly when traps and call suicides occur. Save copies of log messages associated with restarts, traps and call suicides, plus log messages for the periods before and after these events.
Page 84: Aggregate Index Mtccmpl
5-14 5-14 SPMS SERVICE index descriptions 5-14 Aggregate index MTCCMPL Section MTCESERV Description Originating PM line blocked Definition The summary of maintenance contribution to the rate at which calls cannot be successfully completed through the switch once digits have been received.
Page 85: Aggergate Index Spchblk
5-15 SPMS SERVICE index descriptions 5-15 5-15 Aggergate index SPCHBLK Section MTCESERV Description Speech blockage Definition The summary of the rate at which calls fail as a result of no connection between the calling and called terminals. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 86: Basic Index Netblk
5-16 5-16 SPMS SERVICE index descriptions 5-16 Basic index NETBLK Section MTCESERV Description Network blockage Definition The proportion of calls that fail because they cannot be connected through the core network. DMS-100G Switch does not contribute to or provide an equivalent of OM group TRMTRS OM group OFZ, measurements INOUT, and INTRM Measurement list...
Page 87 SPMS SERVICE index descriptions 5-17 Basic index NETBLK Basic index NETBLK (end) (continued) Diagnostics for ENET Confirm the incidence of network blocking with the PROVRES index NETCHOVF. Determine if the network blocking has a maintenance-related cause by examining the MTCEPERF contributing to the MNLNKPF or ENETLKPF aggregate indices.
Page 88: Basic Index Trmpmblk
5-18 5-18 SPMS SERVICE index descriptions 5-18 Basic index TRMPMBLK Section MTCESERV Description Terminating peripheral module blockage Definition The proportion of calls that fail because of the lack of a path through the terminating PM links, or because the terminating PM is too busy to process the calls.
Page 89: Aggergate Index Linoutfl
5-19 SPMS SERVICE index descriptions 5-19 5-19 Aggergate index LINOUTFL Section MTCESERV Description Line outage failure Definition The summary of the extent to which calls fail to terminate on line because of maintenance conditions. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 90: Basic Index Tlinout
5-20 5-20 SPMS SERVICE index descriptions 5-20 Basic index TLINOUT Section MTCESERV Description Terminate line outage Definition The proportion of calls unable to terminate on the lines to which they were routed because these lines were in a maintenance busy state. Examples of these busy states are manual busy, LM busy, cutoff, seized, unloaded, and restricted idle.
Page 91: Basic Index Rngfl
5-21 SPMS SERVICE index descriptions 5-21 5-21 Basic index RNGFL Section MTCESERV Description Ringing failure Definition The proportion of terminating calls given treatment as a result of ringing failure. DMS-100G Switch does not contribute to or provide an equivalent of OM group LMD OM group OFZ, measurements INTRM Measurement list...
Page 92: Aggregate Index Cutoffs
5-22 5-22 SPMS SERVICE index discriptions 5-22 Aggregate index CUTOFFS Section MTCESERV Description Call cutoffs Definition The summary of the degree to which calls are cut off after they have been connected. Cutoffs occurring before this point are included in the events indexed by MISCFL.
Page 93: Aggergate Index Ctlcto
5-23 SPMS SERVICE index descriptions 5-23 5-23 Aggergate index CTLCTO Section MTCESERV Description Cold restart call cutoffs Definition The summary of cutoffs of connected calls because of cold restarts in central or peripheral controllers. Warm restarts do not affect connected calls and their effects are therefore not included in CTLCTO.
Page 94: Basic Index Cccto
5-24 5-24 SPMS SERVICE index descriptions 5-24 Basic index CCCTO Section MTCESERV Description Central control call cutoffs Definition The proportion of calls cut off because of a cold restart of the active central controller. DMS-100G Switch does not contribute to or provide an equivalent of OM group CP, measurment CINITC OM group OFZ, measurements INTRM and INOUT Measurement list...
Page 95: Basic Index Pmcto
5-25 SPMS SERVICE index descriptions 5-25 5-25 Basic index PMCTO Section MTCESERV Description Peripheral module call cutoffs Definition The proportion of calls cut off as a result of PM failure. DMS-100G Switch does not contribute to or provide an equivalent of OM group CP, measurment CINITC OM group OFZ, measurements INTRM, and INOUT OM group PMPTY, measurements PMTMBTCO and PMTSBTCO...
Page 96: Basic Index Integfl
5-26 5-26 SPMS SERVICE index descriptions 5-26 Basic index INTEGFL Section MTCESERV Description Integrity failure Definition The proportion of calls in ringing or talking state that are cut off because of a loss of cross-switch path integrity detected and reported by a PM. Index DMS-100G Switch does not contribute to or provide an equivalent of OM group SYSPERF OM group OFZ, measurements INOUT and INTRM...
Page 97: Aggregate Index C7Msupf
5-27 SPMS SERVICE index descriptions 5-27 5-27 Aggregate index C7MSUPF Section MTCESERV Description CCS7 messaging Definition The C7MSUPF index measures the performance of the message signal units (MSU). Information is provided on the MSU lost by the message transfer part (MTP) and MSU received by the signaling connection control part (SCCP) that could not be routed.
Page 98: Basic Index C7Msufl
5-28 5-28 SPMS SERVICE index descriptions 5-28 Basic index C7MSUFL Section MTCESERV Description CCS7 message signal units (MSU) failure Definition C7MSUFL monitors the number of MSUs lost and discarded by the message transfer part (MTP). DMS-100G Switch does not contribute to or provide an equivalent of OM group C7LINK2, measurement C7MSUTX, C7MSUTX2, C7MSURX, C7MSURX2, C7MSUSC, C7MSUSC1, C7MSUSC2, and C7MSUSC3...
Page 99: Basic Index C7Sccpmp
5-29 SPMS SERVICE index descriptions 5-29 5-29 Basic index C7SCCPMP Section MTCESERV Description CCS7 SCCP layer messaging Definition C7SCCPMP measures the number of messages received by the SCCP routing control (SCRC) that could not be routed. The messages received by the SCRC could arrive from the link through the message transfer part (MTP) or from a local subsystem through SCCP connectional control (SCLC).
Page 100: Aggregate Index Provserv
5-30 5-30 SPMS SERVICE index descriptions 5-30 Aggregate index PROVSERV Section PROVSERV Description Provisioning service Definition The summary of the contribution of traffic provisioning to service, as experienced by the caller. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 101: Aggregate Index Provaccs
5-31 SPMS SERVICE index descriptions 5-31 5-31 Aggregate index PROVACCS Section PROVSERV Description Provisioning access Definition The summary of the quality of subscriber access to the switch as it is influenced by traffic provisioning. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 102: Basic Index Dtsr
5-32 5-32 SPMS SERVICE index descriptions 5-32 Basic index DTSR Section PROVSERV Description Dial tone speed results Definition The proportion of calls originating at the switch that experience dial tone delay exceeding three seconds. Measurement list DTSR uses the dial tone speed results given in OM groups DTSR, SITE, and SITE2.
Page 103: Basic Index Pmdny
5-33 SPMS SERVICE index descriptions 5-33 5-33 Basic index PMDNY Section PROVSERV Description Central control reset Definition The proportion of line and XPM trunk originations not processed by peripherals because the peripherals are overloaded. It also includes the sum of incoming digitone, dial-pulse, multi-frequency, and other attempts (OM register DPATMPT, DTATMPT, MFATMPT, OTHATMPT) from OM group ISDD.
Page 104: Basic Index Miscdny
5-34 5-34 SPMS SERVICE index descriptions 5-34 Basic index MISCDNY Section PROVSERV Description Line and trunk originations denied Definition The number of line and trunk originations rejected by the CC prior to the granting of dial tone or start-to-dial signaling, as a proportion of total call attempts on the switch.
Page 105: Basic Index Miscblk
5-35 SPMS SERVICE index descriptions 5-35 5-35 Basic index MISCBLK Section PROVSERV Description Call blockage Definition MISCBLK indexes calls not served because of the lack of a software resource such as an extension block, or the lack of a service circuit or free operator position.
Page 106: Aggregate Index Trkprov
5-36 5-36 SPMS SERVICE index descriptions 5-36 Aggregate index TRKPROV Section PROVSERV Description Trunk provisioning Definition The summary of the extent of call blocking because of conditions in the trunking network. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 107: Basic Index Nwmblk
5-37 SPMS SERVICE index descriptions 5-37 5-37 Basic index NWMBLK Section PROVSERV Description Network management treatment Definition The proportion of outgoing calls given treatment as a result of network management controls. GSF does not contribute to or provide an equivalent of: OM group TRMTRS OM group OFZ, measurements INOUT and INOUT2 Measurement list...
Page 108: Basic Index Finalbsy
5-38 5-38 SPMS SERVICE index descriptions 5-38 Basic index FINALBSY Section PROVSERV Description Final trunk busy Definition The proportion of outgoing calls given treatment because no trunk is available in the final trunk group of their route list. DMS-100G Switch does not contribute to or provide an equivalent of OM group TRMTRS OM group OFZ, measurements INOUT and INOUT2 Measurement list...
Page 109: Aggregate Index Intfeatr
5-39 SPMS SERVICE index descriptions 5-39 5-39 Aggregate index INTFEATR Section PROVSERV Description International feature Definition The summary of International subscriber feature performance on the switch. The performance of other International features can be confirmed through EXTBLKS indices. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 110: Basic Index Iconfovf
5-40 5-40 SPMS SERVICE index descriptions 5-40 Basic index ICONFOVF Section PROVSERV Description International conference features Definition The ratio of the number of times a subscriber is unable to engage a three-port or six-port conference circuit because of a lack of system resource.
Page 111: Basic Index Icwtovfl
5-41 SPMS SERVICE index descriptions 5-41 5-41 Basic index ICWTOVFL Section PROVSERV Description International call waiting overflow Definition The number of times insufficient resources prevent calls from waiting on a subscriber’s line. Measurement list ICWTOVFL uses measurement CWTOVFL of OM group ICWT. Normalizer ICWTOVFL is normalized by the measurements CWTUSGE and CWTOVFL of OM group ICWT.
Page 112: Basic Index Ifdlovfl
5-42 5-42 SPMS SERVICE index descriptions 5-42 Basic index IFDLOVFL Section PROVSERV Description International fixed destination line Definition The number of times a subscriber cannot be routed to HTL or WLN destinations because of data corruption or software errors. Measurement list IFDLOVFL uses measurement HTLOVFL and WLNOVFL of OM group IFDL.
Page 113: Basic Index Iwucovfl
5-43 SPMS SERVICE index descriptions 5-43 5-43 Basic index IWUCOVFL Section PROVSERV Description International wakeup call overflow Definition The number of times a wakeup attempt could not be performed because of insufficient wakeup feature storage or call processing resources. Measurement list IWUCOVFL is calculated from two registers of the OM group IWUC (WUCOVFL, WUCNRSC).
Page 114: Basic Index C7Gtwerr
5-44 5-44 SPMS SERVICE index descriptions 5-44 Basic index C7GTWERR Section PROVSERV Description CCS7 STP gateway screening failures Definition C7GTWERR provides information on the number of message signal units (MSUs) that caused errors in the screening function. In this case, the MSUs that were to be blocked by the screening process went through to the LIU7 peripherals.
Page 115: Spms Mtceperf Index Descriptions
SPMS MTCEPERF index descriptions The following chapter provides index descriptions for the MTCEPERF branch of SPMS. The maintenance performance index (MTCEPERF) summarizes switch performance as it would be observed by those in direct contact with the switch. The high level MTCEPERF index has four main branches, the control index (CONTROL), bill performance index (BILLPERF), link performance index (LINKPERF), and terminals index (TERMNALS).
Page 116 6-2 SPMS MTCEPERF index descriptions description definition diagnostics The information under these headings explains: the section below the MTCEPERF branch to which the index belongs the expansion of the index name the function and purpose of the index the steps required to locate switch problem The following headings appear in each description of a basic index: section description...
Page 117: Aggregate Index Mtceperf
SPMS MTCEPERF index descriptions Aggregate index MTCEPERF Section The maintenance performance (MTCEPERF) index is a top level office performance (OFCPERF) index. The maintenance performance index derives data from the control (CONTROL), bill performance (BILLPERF), link performance (LINKPERF), and terminals (TERMNALS) indices. Description Maintenance performance Definition...
Page 118: Aggregate Index Control
SPMS MTCEPERF index descriptions Aggregate index Control Section CONTROL Description System control Definition The performance summary of the major components of system control: the central controllers (CC), the central message controller (CMC), the input/output device controller (IOC), the network module controllers (NMC), and the peripheral module controllers (PMC).
Page 119: Aggregate Index Ccperf
SPMS MTCEPERF index descriptions Aggregate index CCPERF Section CONTROL Description Central controller performance Definition The summary of the maintenance performance of central controllers (CCs), program and data store, and the CC-CMC data links. Diagnostics Diagnose error or fault conditions promptly at the CC and subtending levels of the MAP.
Page 120: Basic Index Ccerrint
SPMS MTCEPERF index descriptions Basic index CCERRINT Section CONTROL Description Central control error interrupts Definition The frequency of mismatch interrupts caused by problems in the CC, in a portion of program or data store, or on a CC-CMC data link. Measurement list CCERRINT uses measurement CPU MTCHINT.
Page 121: Basic Index Ccflt
SPMS MTCEPERF index descriptions Basic index CCFLT Section CONTROL Description Central control fault Definition The failure rate of CC, memory, and CC-CMC data port hardware. Measurement list CCFLT uses measurement CPU CPUFLT. Normalizer CCFLT is normalized per unit time. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 122: Basic Index Ccnosync
SPMS MTCEPERF index descriptions Basic index CCNOSYNC Section CONTROL Description Central controller not synchronized Definition The amount of time during which the Central Controllers (CCs) are running unsynchronized. Measurement list CCNOSYNC uses the sum of CPU MSYLOSSU and SSYLOSSU. Normalizer CCNOSYNC is normalized per unit time.
Page 123: Aggregate Index Cmcperf
SPMS MTCEPERF index descriptions Aggregate index CMCPERF Section CONTROL Description Central message controller performance Definition The summary of the maintenance performance of both the central message controller (CMC) and the system clocks attached to it. Diagnostics Diagnose promptly the error and fault conditions at the CMC and SYNCK levels of the MAP.
Page 124: Basic Index Cmcerr
6-10 6-10 SPMS MTCEPERF index descriptions 6-10 Basic index CMCERR Section CONTROL Description Central message controller errors Definition The per-call occurrence of transient and persistent faults in the central message controller (CMC) and system clock hardware. Measurement list CMCERR uses measurement CMC CMCERR, summed over both CMCs. Normalizer CMCERR is normalized by total call attempts on the switch.
Page 125: Basic Index Cmcflt
6-11 SPMS MTCEPERF index descriptions 6-11 6-11 Basic index CMCFLT Section CONTROL Description Central message controller faults Definition The unit failure rate of the CMC and system clock hardware. Measurement list CMCFLT uses measurement CMC CMCFLT, summed over both CMCs. Normalizer CMCFLT is normalized per unit per unit time.
Page 126: Basic Index Cmcusout
6-12 6-12 SPMS MTCEPERF index descriptions 6-12 Basic index CMCUSOUT Section CONTROL Description Central message controller unit system outage Definition The unavailability of CMCs and their associated system clocks as a result of system action. Measurement list CMCUSOUT uses the sum of CMC measurement CMCSBU totalled over both CMCs.
Page 127: Basic Index Cmcumout
6-13 SPMS MTCEPERF index descriptions 6-13 6-13 Basic index CMCUMOUT Section CONTROL Description Central message controller unit manual outage Definition The unit unavailability of CMCs and their associated system clocks as a result of manual action. Measurement list CMCUMOUT uses the sum of CMC measurement CMCSBU totalled over both CMCs.
Page 128: Aggregate Index Iocperf
6-14 6-14 SPMS MTCEPERF index descriptions 6-14 Aggregate index IOCPERF Section CONTROL Description Input/output controller performance Definition The summary of the maintenance performance of input/output controllers. Diagnostics Diagnose error and fault conditions at the IOC and relevant levels of the MAP.
Page 129: Basic Index Iocerr
6-15 SPMS MTCEPERF index descriptions 6-15 6-15 Basic index IOCERR Section CONTROL Description Input/output controller error Definition The frequency of transient and persistent malfunctions of input/output controllers. Measurement list IOCERR uses measurement IOC IOCERR. Normalizer IOCERR is normalized per working IOC per unit time. Diagnostics Verify OM group IOC (IOCERR).
Page 130: Basic Index Iocflt
6-16 6-16 SPMS MTCEPERF index descriptions 6-16 Basic index IOCFLT Section CONTROL Description Input/output controller fault Definition The unit failure rate of input/output controllers. Measurement list IOCFLT uses measurement IOC IOCFLT. Normalizer IOCFLT is normalized per working IOC per unit time. Diagnostics Verify OM group IOC (IOCFLT).
Page 131: Basic Index Iocusout
6-17 SPMS MTCEPERF index descriptions 6-17 6-17 Basic index IOCUSOUT Section CONTROL Description Input/output controller (IOC) unit system outage Definition The unit unavailability of IOCs. Measurement list IOCUSOUT uses the sum of IOC measurement IOCSBU. Normalizer IOCUOSUT is normalized per working IOC per unit time. Diagnostics Verify OM group IOC (IOCSBU).
Page 132: Basic Index Iocumout
6-18 6-18 SPMS MTCEPERF index descriptions 6-18 Basic index IOCUMOUT Section CONTROL Description Input/output controller (IOC) unit manual outage Definition The unit unavailability of IOCs. Measurement list IOCUMOUT uses the sum of IOC measurement IOCMBU. Normalizer IOCUMOUT is normalized per working IOC per unit time. Diagnostics Verify OM group IOC (IOCMBU) to ensure that these results agree with manual maintenance being performed.
Page 133: Aggregate Index Eiocperf
6-19 SPMS MTCEPER index descriptions 6-19 6-19 Aggregate index EIOCPERF Section CONTROL Description Enhanced input/output controller performance Definition The summary of the maintenance performance of enhanced input/output controller links. This index is based on OM group EIOC for switches with an EIOC.
Page 134: Basic Index Eiocerr
6-20 6-20 SPMS MTCEPERF index descriptions 6-20 Basic index EIOCERR Section CONTROL Description Enhanced input/output controller error Definition The frequency of transient and persistent malfunctions of EIOC Links. Measurement list EIOCERR is calculated from the value of OM register EIOCERR of OM group EIOC.
Page 135: Basic Index Eiocflt
6-21 SPMS MTCEPERF index descriptions 6-21 6-21 Basic index EIOCFLT Section CONTROL Description Enhanced input/output controller fault Definition The card failure rate of EIOC. Measurement list EIOCFLT is calculated from the value of OM register EIOCFLT of OM group EIOC. Normalizer EIOCFLT is normalized per working EIOC per unit time.
Page 136: Basic Index Eiocusou
6-22 6-22 SPMS MTCEPERF index descriptions 6-22 Basic index EIOCUSOU Section CONTROL Description Enhanced input/output controller (EIOC) system unit outage Definition The CARD unavailability of EIOC links. Measurement list EIOCUSOU uses the sum of EIOC measurement EIOCSBU. Normalizer EIOCUSOU is normalized per working EIOC per unit time. Diagnostics Verify OM group EIOC (EIOCSBU).
Page 137: Basic Index Eiocumou
6-23 SPMS MTCEPERF index descriptions 6-23 6-23 Basic index EIOCUMOU Section CONTROL Description Enhanced input/output controller (EIOC) manual unit outage Definition The CARD unavailability of EIOC links. Measurement list EIOCUMOU uses the sum of EIOC measurement EIOCMBU. Normalizer EIOCUMOU is normalized per working EIOC per unit time. Diagnostics Verify OM group EIOC (EIOCMBU) and ensure that these results agree with manual maintenance being performed.
Page 138: Aggregate Index Nmcperf
6-24 6-24 SPMS MTCEPERF index descriptions 6-24 Aggregate index NMCPERF Section CONTROL Description Network message controller performance Definition The summary of the maintenance performance of network module controllers. Diagnostics Diagnose network module controller error and fault conditions at the NET level of the MAP.
Page 139: Basic Index Nmcerr
6-25 SPMS MTCEPERF index descriptions 6-25 6-25 Basic index NMCERR Section CONTROL Description Network message controller error Definition The per-call occurrence of transient and persistent malfunctions of network module controllers. Measurement list NMCERR uses measurement NMC NMCERR. Normalizer NMCERR is normalized by total call attempts on the switch. Diagnostics Verify OM group NMC (NMCERR).
Page 140: Basic Index Nmcflt
6-26 6-26 SPMS MTCEPERF index descriptions 6-26 Basic index NMCFLT Section CONTROL Description Network message controller fault Definition The unit failure rate of network module controllers. Measurement list NMCFLT uses measurement NMC NMCFLT. Normalizer NMCFLT is normalized per working NM controller per unit time. The number of working NM controllers is equal to the number of working NMs doubled (two planes per NM).
Page 141: Basic Index Nmcusout
6-27 SPMS MTCEPERF index descriptions 6-27 6-27 Basic index NMCUSOUT Section CONTROL Description Network message controller unit system outage Definition The unit system unavailability of network module controllers. Measurement list NMCUSOUT uses the sum of NMC measurement NMSBU. Normalizer NMCUSOUT is normalized per working NM controller per unit time. Diagnostics Verify OM group NMC (NMSBU).
Page 142: Basic Index Nmcumout
6-28 6-28 SPMS MTCEPERF index descriptions 6-28 Basic index NMCUMOUT Section CONTROL Description Network message controller unit manual outage Definition The unit unavailability of network module controllers. Measurement list NMCUMOUT uses the sum of NMC measurement NMMBU. Normalizer NMCUMOUT is normalized per working NM controller per unit time. Diagnostics Verify OM group NMC (NMMBU) and ensure that these results agree with manual maintenance being performed.
Page 143 6-29 SPMS MTCEPERF index descriptions 6-29 6-29 Aggregate index CMPERF for SuperNode CONTROL components Section CONTROL Description Computing module performance Definition The summary of the maintenance performance of SuperNode computing modules (CM) program and data store. Diagnostics Diagnose error for fault conditions promptly at the CM and relevant levels of the MAP.
Page 144: Basic Index Cmerrint For Supernode Control Components
6-30 6-30 SPMS MTCEPERF index descriptions 6-30 Basic index CMERRINT for SuperNode CONTROL components Section CONTROL Description Computing module error interrupts Definition The frequency of mismatch interrupts that result from problems in the CM or in a portion of program or data store. Measurement list CMERRINT uses the sum of CM measurements CMTRMISM and CMDPSYNC.
Page 145 6-31 SPMS MTCEPERF index descriptions 6-31 6-31 Basic index CMFLT for SuperNode CONTROL components Section CONTROL Description Computing module fault Definition The failure rate of the computing module and the associated memory hardware. Measurement list CMFLT uses the sum of CM measurements CMCPUFLT, CMMEMFLT, CMSSCFLT, CMMCSBSY, CMRMEMFL, CMRCPUFL, and CMRLNKFL.
Page 146: Basic Index Cmnosync For Supernode Control Components
6-32 6-32 SPMS MTCEPERF index descriptions 6-32 Basic index CMNOSYNC for SuperNode CONTROL components Section CONTROL Description Computing module not synchronized Definition The time intervals during which the CMs are running unsynchronized. Measurement list CMNOSYNC uses the sum of CM measurements CMMSMPXU and CMSSMPXU.
Page 147 6-33 SPMS MTCEPERF index descriptions 6-33 6-33 Aggregate index MSPERF for SuperNode CONTROL components Section CONTROL Description Message switch performance Definition The summary of the maintenance performance of the message switch (MS) node resources. Diagnostics Diagnose error and fault conditions promptly at the MS level of the MAP. Look for detailed information in MS subsystem logs.
Page 148: Basic Index Mserr For Supernode Conrol Components
6-34 6-34 SPMS MTCEPERF index descriptions 6-34 Basic index MSERR for SuperNode CONROL components Section CONTROL Description Message switch error Definition The per-call occurrence of transient and persistent faults in MS node resource hardware. Measurement list MSERR uses measurement MS MSERR, summed over both message switches.
Page 149 6-35 SPMS MTCEPERF index descriptions 6-35 6-35 Basic index MSFLT for SuperNode CONTROL components Section CONTROL Description Message switch fault Definition The unit failure rate of MS node resource hardware. Measurement list MSFLT uses measurement MS MSFLT, summed over both message switches.
Page 150: Basic Index Msusout For Network Index Components
6-36 6-36 SPMS MTCEPERF index descriptions 6-36 Basic index MSUSOUT for NETWORK INDEX components Section CONTROL Description Message switch (MS) unit system outage Definition The unit unavailability of MS nodes as a result of system action. Measurement list MSUSOUT uses the sum of MS measurement MSSBU totalled over both message switches.
Page 151 6-37 SPMS MTCEPERF index descriptions 6-37 6-37 Basic index MSUMOUT for SuperNode CONTROL components Section CONTROL Description Message switch unit manual outage Definition The unit unavailability of MS nodes as a result of manual action. Measurement list MSUMOUT uses the sum of MS measurements MSMBU totalled over both message switches.
Page 152: Aggregate Index Mscdperf For Supernode Control Components
6-38 6-38 SPMS MTCEPERF index discriptions 6-38 Aggregate index MSCDPERF for SuperNode CONTROL components Section CONTROL Description Message switch card performance Definition The summary of the maintenance performance of the message switch (MS) interface card resources. Diagnostics Diagnose error and fault conditions promptly at the MS level of the MAP. Look for detailed information in MS subsystem logs.
Page 153 6-39 SPMS MTCEPERF index descriptions 6-39 6-39 Basic index MSCDERR for SuperNode CONTROL components Section CONTROL Description Message switch and error Definition The per-call occurrence of transient and persistent faults in MS interface cards. Measurement list MSCDERR uses measurement MS MSCDERR, summed over both message switches.
Page 154: Basic Index Mscdflt For Supernode Control Components
6-40 6-40 SPMS MTCEPERF index descriptions 6-40 Basic index MSCDFLT for SuperNode CONTROL components Section CONTROL Description Message switch card fault Definition The unit failure rate of MS interface cards. Measurement list MSCDFLT uses measurement MS MSCDFLT, summed over both message switches.
Page 155 6-41 SPMS MTCEPERF index descriptions 6-41 6-41 Basic index MSCDSOUT for SuperNode CONTROL components Section CONTROL Description Message switch card unit system outage Definition The unit system unavailability of MS interface cards. Measurement list MSCDSOUT uses the sum of MS measurement MSCDSBU totalled over both message switches.
Page 156: Basic Index Mscdmout For Supernode Control Components
6-42 6-42 SPMS MTCEPERF index descriptions 6-42 Basic index MSCDMOUT for SuperNode CONTROL components Section CONTROL Description Message switch card unit manual outage Definition The unit unavailability of MS interface cards. Measurement list MSCDMOUT uses the sum of MS measurement MSCDMBU totalled over both message switches.
Page 157: Aggregate Index Enetperf For Enet Control Components
6-43 SPMS MTCEPERF index descriptions 6-43 6-43 Aggregate index ENETPERF for ENET CONTROL components Section CONTROL Description Enhanced network (ENET) system performance Definition ENETPERF provides a summary of the performance of the ENET system cards. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 158: Basic Index Eneterr For Enet Control Components
6-44 6-44 SPMS MTCEPERF index descriptions 6-44 Basic index ENETERR for ENET CONTROL components Section CONTROL Description Enhanced network (ENET) system errors Definition ENETERR monitors the number of errors detected in the ENET system cards. Measurement list ENETERR uses operational measurement ENERR of OM group ENETSYS. Normalizer ENETERR is normalized by the total call attempts made on the switch per day.
Page 159: Basic Index Enetsout
6-45 SPMS MTCEPERF index descriptions 6-45 6-45 Basic index ENETFLT for ENET CONTROL components Section CONTROL Description Enhanced network (ENET) system faults Definition ENETFLT monitors the number of times a system card cannot recover from an error. Measurement list ENETFLT uses operational measurement ENFLT of OM group ENETSYS. Normalizer ENETFLT is normalized by the total call attempts made on the switch per day.
Page 160 6-46 6-46 6-46 6-46 SPMS MTCEPERF index descriptions SPMS MTCEPERF index descriptions 6-46 6-46 Basic index ENETSOUT Basic index ENTSOUT for ENET CONTROL components Section CONTROL Description Enhanced network (ENET) system-busy shelves. Definition ENETSOUT monitors system-busy ENET shelves. Measurement list ENETSOUT uses operational measurement ENSBU of OM group ENETSYS.
Page 161 6-47 SPMS MTCEPERF index descriptions 6-47 6-47 Basic index ENETMOUT for ENET CONTROL components Section CONTROL Description Enhanced network (ENET) manual-busy shelves Definition ENETMOUT monitors manual-busy ENET shelves. Measurement list ENETMOUT uses operational measurement ENMBU of OM group ENETSYS. Normalizer ENETMOUT is normalized per working shelf per unit time.
Page 162: Aggregate Index Pmperf
6-48 6-48 SPMS MTCEPERF index descriptions 6-48 Aggregate index PMPERF Section CONTROL Description Peripheral module performance Definition The summary of the software and hardware performance of all peripheral modules (PM) in the switch. To keep a small number of units of one PM type from having a disproportionate effect on total office results, the aggregate index PMTOTPF is the only one contributing to PMPERF and its parents.
Page 163: Aggregate Index Pmtotpf
6-49 SPMS MTCEPERF index descriptions 6-49 6-49 Aggregate index PMTOTPF Section CONTROL Description Peripheral module total performance Definition The summary of unit software and hardware performance of peripheral modules. Every PM unit in the switch is given the same weight. Diagnostics Check the PM OM group for PMs with high error, fault, or outage measurements.
Page 164: Basic Index Pmtoterr
6-50 6-50 SPMS MTCEPERF index descriptions 6-50 Basic index PMTOTERR Section CONTROL Description Peripheral module total errors Definition The average per-call frequency of software and hardware malfunctions. Both transient or persistent malfunctions are reported by peripherals attached to the switch. DMS-100G Switch does not contribute to or provide an equivalent of: OM group PMTYP, measurement PMTERR OM group OFZ, measurements NIN, and NIN2...
Page 165: Basic Index Pmtotflt
6-51 SPMS MTCEPERF index descriptions 6-51 6-51 Basic index PMTOTFLT Section CONTROL Description Peripheral module total faults Definition The average unit failure rate of peripherals of the switch. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP measurement PMTFLT Measurement list PMTOTFLT uses measurement PMTYP PMTFLT divided by all peripheral...
Page 166: Basic Index Pmtousou
6-52 6-52 SPMS MTCEPERF index descriptions 6-52 Basic index PMTOUSOU Section CONTROL Description Peripheral module total units system outage Definition The average unit unavailability of peripherals of the switch, as a result of system actions. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTUSBU Measurement list PMTOUSOU uses PMTYP measurement PMTUSBU, totalled over all...
Page 167: Basic Index Pmtoumou
6-53 SPMS MTCEPERF index descriptions 6-53 6-53 Basic index PMTOUMOU Section CONTROL Description Peripheral module total units manual outage Definition The average unit unavailability of peripherals of the switch, as a result of manual actions. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTUSBU Measurement list PMTOMUOU uses PMTYP measurement PMTUMBU, totalled over all...
Page 168 6-54 6-54 SPMS MTCEPERF index descroptions 6-54 Basic index NDTOERR Basic index NDTOERR (continued) (continued) Section NDPERF Description Node maintenance type errors Definition NDTOERR is the error rate for each equipped node per time unit for in-service and out-of-service nodes. Measurement NDTOERR uses measurement NMTCTYPE NDTERR.
Page 169 6-55 SPMS MTCEPERF index descroptions 6-55 6-55 Basic index NDTOFLT Basic index NDTOFLT (continued) (continued) Section NDPERF Description Node maintenance faults. Definition A measurement of faults that persist after system diagnostics have been executed. The index is the equipped node fault rate per time unit. Measurement NDTOFLT uses measurement NMTCTYPE NDTFLT.
Page 170 6-56 6-56 SPMS MTCEPERF index descroptions 6-56 Basic index NDTOOUT Basic index NDTOOUT (continued) (continued) Section NDPERF Description Total node outage. Definition Total equipped node outage (manual busy and system busy) on a node-by-node basis per time unit. Measurement NDTOOUT uses measurements NMTCUNIT NDUMBU and NDUSBU. Normalizer NDTOOUT is normalized per time unit.
Page 171 6-57 SPMS MTCEPERF index descriptions 6-57 6-57 Aggregate index APMPF for SuperNode CONTROL components Section CONTROL Description Application processor performance Definition SMNMPF provides a summary of the maintenance performance of the application processor (AP). Diagnostics Diagnose error for fault reporting on the relevant level of the MAP (PM node level and PM plane level).
Page 172: Basic Index Aptoerr For Supernode Control Components
6-58 6-58 SPMS MTCEPERF index descriptions 6-58 Basic index APTOERR for SuperNode CONTROL components Section CONTROL Description Errors in the application processor Definition The frequency of mismatch interrupts due to software or hardware problems in the application processor. Measurement list SMTOERR uses the sum of the operational measurements APTRMISM and APSDROP in group APSYS.
Page 173 6-59 SPMS MTCEPERF index descriptions 6-59 6-59 Basic index APTOFLT for SuperNode CONTROL components Section CONTROL Description Failure rate in the application processor. Definition Monitors the failure rate of the hardware in the application processor. Measurement list SMTOFLT uses the sum of the operational measurements APCPUFLT, APMEMFLT and APPRTFLT in the group APSYS.
Page 174: Basic Index Apnosync For Supernode Control Components
6-60 6-60 SPMS MTCEPERF index descriptions 6-60 Basic index APNOSYNC for SuperNode CONTROL components Section CONTROL Description Unsynchronized application processors Definition Monitors the amount of time during which the application processors run in an unsynchronized mode. Measurement list SMNOSYNC uses the sum of the operational measurements APMSMPXU and APSSMPXU in group APSYS.
Page 175: Aggregate Index Sospmpf
6-61 SPMS MTCEPERF index descriptions 6-61 6-61 Aggregate index SOSPMPF Section CONTROL Description SOS-based peripheral module (PM) performance Definition SOSPMPF provides a summary of the performance of the SOS-related peripheral types. The peripheral types monitored are the link interface unit for CCS7 (LIU7) and the link interface module (LIM).
Page 176: Basic Index Sospmerr
6-62 6-62 SPMS MTCEPERF index descriptions 6-62 Basic index SOSPMERR Section CONTROL Description SOS-based peripheral module errors Definition SOSPMERR monitors the per-call occurrence of hardware and software errors, transient or persistent, reported from the peripheral module (PM) types listed in the SOSPMPF index. Measurement list SOSPMERR uses measurements PMTERR of OM group PMTYP, and PM1ERR of OM group PM1 summed over all PM types covered in...
Page 177: Basic Index Sospmflt
6-63 SPMS MTCEPERF index descriptions 6-63 6-63 Basic index SOSPMFLT Section CONTROL Description SOS-based peripheral module faults Definition SOSPMFLT monitors the failure rate of the peripheral module (PM) types listed in the SOSPMPF index, specifically the link interface unit for CCS7 (LIU7) and the link interface module (LIM).
Page 178: Basic Index Sospmmou
6-64 6-64 SPMS MTCEPERF index descriptions 6-64 Basic index SOSPMMOU Section CONTROL Description SOS-based peripheral module manual outage Definition SOSPMMOU monitors the manual availability of the peripheral module (PM) types listed in the SOSPMMOU index. Measurement list SOSPMMOU uses measurements PMTUMBU of OM group PMTYP, and PM1MBU of OM group PM1 summed over all PM types covered in the SOSPMPF index.
Page 179: Basic Index Sospmsou
6-65 SPMS MTCEPERF index descriptions 6-65 6-65 Basic index SOSPMSOU Section CONTROL Description SOS-based peripheral module system outage Definition SOSPMSOU monitors the system availability of the peripheral module (PM) types listed in the SOSPMMOU index. Measurement list SOSPMSOU uses measurements PMTUSBU of OM group PMTYP, and PM1SBU of OM group PM1 summed over all PM types covered in the SOSPMPF index.
Page 180: Aggregate Index Tmperf
6-66 6-66 SPMS MTCEPERF index descriptions 6-66 Aggregate index TMPERF Section CONTROL Description Trunk module performance Definition The summary of the performance of TM-related peripheral types. These include trunk modules 2, 4, and 8, trunk module (8-wire circuit), TMA, package trunk module, maintenance trunk module, remote maintenance module, service trunk module, remote service module, MTMA, test access network, and office alarm unit.
Page 181: Basic Index Tmerr
6-67 SPMS MTCEPERF index descriptions 6-67 6-67 Basic index TMERR Section CONTROL Description Trunk module error Definition The per-call occurrence of hardware and software errors, transient or persistent, reported from PM types covered by the TMPERF indices respectively. Measurement list TMERR uses OM measurement PMTYP PMTERR summed over all PM types covered by the index in question.
Page 182: Basic Index Tmflt
6-68 6-68 SPMS MTCEPERF index descriptions 6-68 Basic index TMFLT Section CONTROL Description Trunk module fault Definition The failure rate of PM types covered by the TMPERF indices. Measurement list TMFLT uses measurement PMTYP PMTFLT summed over all PM types covered by the index in question.
Page 183: Basic Index Tmusout
6-69 SPMS MTCEPERF index descriptions 6-69 6-69 Basic index TMUSOUT Section CONTROL Description Trunk module (TM) unit system outage Definition The unavailability of PM types covered by the TMPERF indices, as a result of system actions. Measurement list TMUSOUT uses PMTYP measurement PMTUSBU summed over all PM types covered by the index in question.
Page 184: Basic Index Tmumout
6-70 6-70 SPMS MTCEPERF index descriptions 6-70 Basic index TMUMOUT Section CONTROL Description Trunk module (TM) unit manual outage Definition The unavailability of PM types covered by the TMPERF indices, as a result of manual actions. Measurement list TMUMOUT uses PMTYP measurement PMTUMBU summed over all PM types covered by the index in question.
Page 185: Aggregate Index Dcmperf
6-71 SPMS MTCEPERF index descriptions 6-71 6-71 Aggregate index DCMPERF Section CONTROL Description Digital carrier module performance Definition The summary of the performance of DCM-related peripheral types. These include digital carrier module, digital carrier module 250, DCMT, and digital echo suppressor. Diagnostics To isolate the problem, look at the OM group PM.
Page 186: Basic Index Dcmerr
6-72 6-72 SPMS MTCEPERF index descriptions 6-72 Basic index DCMERR Section CONTROL Description Digital carrier module error Definition The per-call occurrence of hardware and software errors, transient or persistent, reported from PM types covered by the DCMPERF indices. Measurement list DCMERR uses measurement PMTYP PMTERR summed over all PM types covered by the index in question.
Page 187: Basic Index Dcmflt
6-73 SPMS MTCEPERF index descriptions 6-73 6-73 Basic index DCMFLT Section CONTROL Description Digital carrier module fault Definition The unit failure rate of PM types covered by the DCMPERF indices. Measurement list DCMFLT uses measurement PMTYP PMTFLT summed over all PM types covered by the index in question.
Page 188: Basic Index Dcmusout
6-74 6-74 SPMS MTCEPERF index descriptions 6-74 Basic index DCMUSOUT Section CONTROL Description Digital carrier module (DCM) unit system outage Definition The unavailability of PM types covered by the DCMPERF indices, as a result of system actions. Measurement list DCMUSOUT uses PMTYP measurement PMTUSBU summed over all PM types covered by the index in question.
Page 189: Basic Index Dcmumout
6-75 SPMS MTCEPERF index descriptions 6-75 6-75 Basic index DCMUMOUT Section CONTROL Description Digital carrier module (DCM) unit manual outage Definintion The unavailability of PM types covered by the DCMPERF indices, as a result of manual actions. Measurement list DCMUMOUT uses PMTYP measurement PMTUMBU summed over all PM types covered by the index in question.
Page 190: Aggregate Index Xpmperf
6-76 6-76 SPMS MTCEPERF index descriptions 6-76 Aggregate index XPMPERF Section CONTROL Description XMS-based peripheral module performance Definition The summary of the performance of XMS-based dual unit peripheral modules. The peripheral types are DTC, LTC, IDTC, DTCI, RCC, ARCC, PRCC, SRCC, RCCI, RCC2, RCO2, IAC, ILTC, ADTC, PDTC, LGC, ALGC ILGC, PLGC, SMR, SMS, SMSR, SMU, CSC, MSB6, MSB7, IAC, DTCI, TMS, SMA, and ICP.
Page 191: Basic Index Xpmerr
6-77 SPMS MTCEPERF index descriptions 6-77 6-77 Basic index XPMERR Section CONTROL Description XMS-based peripheral module errors Definition The per-call occurrence of hardware and software errors, transient or persistent, reported from PM types listed under XPMPERF. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTERR Measurement list XPMERR uses measurement PMTYP PMTERR summed over all PM types...
Page 192: Basic Index Xpmflt
6-78 6-78 SPMS MTCEPERF index descriptions 6-78 Basic index XPMFLT Section CONTROL Description XMS-based peripheral module faults Definition The unit failure rate of the peripheral module types listed in XPMPERF. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTFLT Measurement list XPMFLT uses measurement PMTYP PMTFLT summed over all PM types...
Page 193: Basic Index Xpmusout
6-79 SPMS MTCEPERF index description 6-79 6-79 Basic index XPMUSOUT Section CONTROL Description XMS-based peripheral module unit system outage Definition The unavailability of PM types covered by the XPMPERF indices, as a result of system actions. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTUSBU Measurement list XPMUSOUT uses PMTYP measurement PMTUSBU summed over all PM...
Page 194: Basic Index Xpmumout
6-80 6-80 SPMS MTCEPERF index description 6-80 Basic index XPMUMOUT Section CONTROL Description XMS-based peripheral module unit manual outage Definition The unavailability of PM types covered by the XPMPERF indices, as a result of manual actions. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTUMBU Measurement list XPMUMOUT uses PMTYP measurement PMTUMBU summed over all...
Page 195: Aggregate Index Lmperf
6-81 SPMS MTCEPERF index descriptions 6-81 6-81 Aggregate index LMPERF Section CONTROL Description Line module performance Definition The summary of the performance of single-unit line controlling peripheral types. The peripheral types are as follows: line modules, remote concentrator terminal, remote carrier urban, remote concentrator SLC-96, and integrated digital terminals.
Page 196: Basic Index Lmerr
6-82 6-82 SPMS MTCEPERF index descriptions 6-82 Basic index LMERR Section CONTROL Description Line module error Definition The per-call occurrence of hardware and software errors, transient or persistent, reported from PM types covered by the LMPERF indices. Measurement list LMERR uses measurements PMTYP PMTRGERR and PMTERR summed over all PM types covered in the LMPERF section.
Page 197: Basic Index Lmflt
6-83 SPMS MTCEPERF index descriptions 6-83 6-83 Basic index LMFLT Section CONTROL Description Line module faults Definition The unit failure rate of PM types covered by LMPERF. Measurement list LMFLT is equal to the sum of PMTYP PMTRGFLT and PMTFL over the appropriate PM types.
Page 198: Basic Index Lmusout
6-84 6-84 SPMS MTCEPERF index descriptions 6-84 Basic index LMUSOUT Section CONTROL Description Line module (LM) unit system outage Definition The unavailability of PM types covered by the LMPERF indices, as a result of system actions. Measurement list LMUSOUT uses PMTYP measurement PMTUSBU summed over all PM types covered by the index in question.
Page 199: Basic Index Lmumout
6-85 SPMS MTCEPERF index descriptions 6-85 6-85 Basic index LMUMOUT Section CONTROL Description Line concentrating module unit manual outage Definition The unavailability of PM types covered by the LMPERF indices, as a result of manual actions. Measurement list LMUMOUT uses PMTYP measurement PMTUMBU summed over all PM types covered by each index in question.
Page 200: Aggregate Index Lcmperf
6-86 6-86 SPMS MTCEPERF index descriptions 6-86 Aggregate index LCMPERF Section CONTROL Description Line concentrating module performance Definition The summary of the performance of dual-unit line controllers. These include line concentrating modules (LCM), international line concentrating modules (ILCM), enhanced line concentrating modules (ELCM), Austrian line concentrating modules (ALCM), and emergency stand-alone (ESA).
Page 201: Basic Index Lcmerr
6-87 SPMS MTCEPERF index descriptions 6-87 6-87 Basic index LCMERR Section CONTROL Description Line concentrating module errors Definition The per-call occurrence of hardware and software errors, transient or persistent, reported from PM types covered by the LCMPERF indices. DMS-100G Switch does not contribute to or provide an equivalent of OM group LMD, measurements NORIGATT and NTRMATT Measurement list LCMERR is the sum of PMTYP PMTRGERR and PMTYP PMTERR over...
Page 202: Basic Index Lcmflt
6-88 6-88 SPMS MTCEPERF index descriptions 6-88 Basic index LCMFLT Section CONTROL Description Line concentrating module fault Definition The failure rate of peripheral modules covered by LCMPERF. Measurement list LCMFLT uses measurements PMTYP PMTRGFLT and PMTFLT over respective PM types. Normalizer LCMFLT is normalized per working unit per unit time, where the working units are the PM types covered by the respective indices.
Page 203: Basic Index Lcmusout
6-89 SPMS MTCEPERF index descriptions 6-89 6-89 Basic index LCMUSOUT Section CONTROL Description Line concentrating module unit system outage Definition The unavailability of PM types covered by the LCMPERF indices, as a result of system actions. Measurement list LCMUSOUT uses PMTYP measurement PMTUSBU summed over all PM types covered by each index in question.
Page 204: Basic Index Lcmumout
6-90 6-90 SPMS MTCEPERF index descriptions 6-90 Basic index LCMUMOUT Section CONTROL Description Line concentrating module unit manual outage Definition The unavailability of PM types covered by the LCMPERF indices, as a result of manual actions. Measurement list LCMUMOUT uses PMTYP measurement PMTUMBU summed over all PM types covered by each index in question.
Page 205: Aggregate Index Swinteg
Diagnostics To ensure that relevant data can be retrieved from the switch before it is overwritten, promptly report any problems indexed by SWINTEG to Nortel Field Technical Support. Provide Nortel Technical Support with the associated log messages plus all logs for the hours preceding and following the error events.
Page 206: Aggregate Index Pmswintg
PM122, PM124, PM125, PM126, PM179, PM180, PM185, and PM300 logs. Check the PMs concerned from the PM level of the MAP. If you cannot correct the error, report the condition promptly to Nortel Technical Support. Be sure to keep copies of the applicable log messages.
Page 207: Basic Index Pmswerr
From the OM group PM and PM log reports PM122, PM124, PM125, PM126, and PM180, identify the PMs responsible for poor values. If the error condition cannot be corrected, report the condition promptly to Nortel Technical Support, making sure to keep copies of the applicable log messages.
Page 208: Basic Index Pmtrap
PM185, and PM300. Check the PMs concerned from the PM level of the MAP. If the error condition cannot be corrected, report the condition promptly to Nortel Technical Support, making sure to keep copies of the applicable log messages. 297-1001-330 Standard 11.04 June 1998...
Page 209 6-95 SPMS MTCEPERF index descriptions 6-95 6-95 Aggregate index NDSWINT Aggregate index NDSWINT (continued) (continued) Section PMASWINTG Description Node software integrity Definition The summary of none software performance Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 210 6-96 6-96 SPMS MTCEPERF index descroptions 6-96 Basic index NDSWERR Basic index NDSWERR (continued) (continued) Section NDSWINT Description Node software error messages. Definition NDSWERR is the rate at which software error messages occur on each node. Measurement NDSWERR uses the measurement NMTCTYPE NDTSWERR. Normalizer NDSWERR is the normalized per node per time unit.
Page 211 6-97 SPMS MTCEPERF index descroptions 6-97 6-97 Basic index NDTRAP Basic index NDTRAP (continued) (continued) Section NDSWINT Description Node traps Definition The per node rate of rate of maintenance error traps. Measurement NDTRAP uses measurement NMTCTYPE NDTTRAP. Normalizer NDTRAP is normalized per node per unit time. Diagnostics Check the OM group NMTCTYPE.
Page 212: Aggregate Index Ccswintg
6-98 6-98 SPMS MTCEPERF index descriptions 6-98 Aggregate index CCSWINTG Section CONTROL Description Central controller software integrity Definition The summary of the rate of occurrence of CC-related software errors. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 213: Basic Index Ccswerr
CCSWERR is normalized per total call attempt on the switch. Diagnostics Ensure that Nortel Technical Support is aware of the content of the SWER logs indexed by CCSWERR, particularly PMSWERCT, PM122, PM124, PM126, PM180, PMTRAPCT, PM125, PM179, PM185, and PM300. Be prepared to supply copies of these log reports on request.
Page 214: Aggregate Index Traps
CONTROL Description Central controller traps Definition The summary of the rate of occurrence of CC traps within the switch. Diagnostics If traps occur and the cause cannot be identified locally, notify Nortel Technical Support promptly. 297-1001-330 Standard 11.04 June 1998...
Page 215: Basic Index Noncptrp
Verify OM groups CPR (TRAPINT) and CP (CPTRAP). Measurement NONCPTRP equals TRAPINT minus CPTRAP. Check logs CC103, SWERR, TRAP, and CC104. Notify Nortel Technical Support promptly if traps occur and the cause cannot be identified. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 216: Basic Index Cptraps
CPTRAPS is normalized per total call attempt on the switch. Diagnostics Same as SWERRS. Notify Nortel Technical Support promptly if traps occur and the cause cannot be identified locally. Be ready to produce copies of traps and trapinfo output as required. Check group CP for volume of trap.
Page 217: Basic Index Cpuicds
6-103 SPMS MTCEPERF index descriptions 6-103 6-103 Basic index CPUICDS Section CONTROL Description Call processing suicides Definition The per-attempt occurrence of call processing suicides. These occur when call processing has encountered severe error conditions, as a result of software errors, software or hardware problems in peripherals, or datafill errors.
Page 218: Aggregate Index Ccint
Diagnostics To determine the cause of the CC restart and prevent recurrences, obtain help from Nortel Technical Support. Notify higher-level or manufacturer technical support groups immediately about any unexpected CC restarts. Save log messages and operational measurements from the period in question for technical examination.
Page 219: Basic Index Ccwinit
Normalizer CCWINIT is normalized per unit time. Diagnostics To determine the cause of the warm restarts, contact Nortel Technical Support. Verify OM group CPU (SYSCINIT) or for SuperNode, group CM (CMSCINIT, CMMCINIT). Check logs CC107, INIT, and SWCT103. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 220: Basic Index Cccinit
CCCINIT is normalized per unit time. Diagnostics To determine the cause of the CC restart and prevent recurrences, contact Nortel Technical Support. Notify higher-level manufacturer technical support groups immediately of any unfavorable results. Check logs CC107 and INIT. 297-1001-330 Standard 11.04 June 1998...
Page 221: Aggregate Index Billperf
6-107 SPMS MTCEPERF index descriptions 6-107 6-107 Aggregate index BILLPERF Section BILLPERF Description Billing performance Definition The summary of billing performance on the switch. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 222: Basic Index Meterpf
6-108 6-108 SPMS MTCEPERF index descriptions 6-108 Basic index METERPF Section BILLPERF Description Metering performance Definition The summary of the error performance during central control (CC) metering. Measurement list METERERR uses the sum of measurements DTCALLP, DTXPM, DTFEAT, TIMEST0, DURERR, COUNTERR, MTRBKERR, MTRAUDER, RECYCFND, RECYCCLR, THQOVFL, THQERR, and TODXPMFL of OM group MTRPERF.
Page 223: Basic Index Amadevfl
6-109 SPMS MTCEPERF index descriptions 6-109 6-109 Basic index AMADEVFL Section BILLPERF Description Automatic message accounting device failure Definition The number of Automatic Message Accounting (AMA) calls that could not be recorded. It is based on the AMAFREE and AMAROUTE fields of OM group AMA.
Page 224: Aggregate Index Linkperf
6-110 6-110 SPMS MTCEPERF index descriptions 6-110 Aggregate index LINKPERF Section LINKPERF Description Link performance Definition The summary of the maintenance performance of connecting path within the switch. This includes the CMC/MS, IOC, network module, and peripheral module P-side links, plus the speech paths through the network modules. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 225: Aggregate Index Cmclnkpf
6-111 SPMS MTCEPERF index descriptions 6-111 6-111 Aggregate index CMCLNKPF Section LINKPERF Description Central message controller link performance Definition The summary of the maintenance performance of links between CMCs and network modules or IOCs. Diagnostics Further information is available from CMC subsystem logs. Diagnose CMC P-side port problems at the CMC level of the MAP.
Page 226: Basic Index Cmclnker
6-112 6-112 SPMS MTCEPERF index descriptions 6-112 Basic index CMCLNKER Section LINKPERF Description Central message controller link error Definition The per-call occurrence of errors on links between the CMCs and NMs or IOCs. Measurement list CMCLNKER uses measurement CMC CMCLERR, summed over both CMCs.
Page 227: Basic Index Cmclksou
6-113 SPMS MTCEPERF index descriptions 6-113 6-113 Basic index CMCLKSOU Section LINKPERF Description Central message controller (CMC) link system unit outage Definition The unavailability of links between the CMCs and the NMs and IOCs, as a result of system action. Measurement list CMCLKSUO uses the sum of CMC measurement CMCLKSBU.
Page 228: Basic Index Cmclkmuo
6-114 6-114 SPMS MTCEPERF index descriptions 6-114 Basic index CMCLKMUO Section LINKPERF Description Central message controller (CMC) link manual unit outage Definition The unavailability of links between the CMCs and the NMs and IOCs, as a result of manual actions. Measurement list CMCLKMUO uses the sum of CMC measurement CMCLKMBU.
Page 229: Aggregate Index Ioclnkpf
6-115 SPMS MTCEPERF index descriptions 6-115 6-115 Aggregate index IOCLNKPF Section LINKPERF Description Controller link performance Definition The summary of the maintenance performance of the links between IOCs and I/O devices or device controllers. Diagnostics Further information is available from IOD subsystem logs. Diagnose IOC P-side port problems at the IOD and lower levels of the MAP.
Page 230: Basic Index Ioclnker
6-116 6-116 SPMS MTCEPERF index descriptions 6-116 Basic index IOCLNKER Section LINKPERF Description Input/output controller link error Definition The rate of occurrence of errors on links between the IOCs and I/O devices or device controllers. Measurement list IOCLNKER uses measurement IOC IOCLKERR. Normalizer IOCLNKER is normalized per working IOC P-side link per unit time.
Page 231: Basic Index Ioclksuo
6-117 SPMS MTCEPERF index descriptions 6-117 6-117 Basic index IOCLKSUO Section LINKPERF Description Input/output controller (IOC) link system unit outage Definition The unavailability of links between the IOCs and I/O devices or device controllers. Measurement list IOCLKSUO uses the sum of IOC measurement IOCLKSBU. Normalizer IOCLKSUO is normalized per working P-side IOC link per unit time.
Page 232: Basic Index Ioclkmuo
6-118 6-118 SPMS MTCEPERF index descriptions 6-118 Basic index IOCLKMUO Section LINKPERF Description Input/output controller (IOC) link manual unit outage Definition The unavailability of links between the IOCs and I/O devices or device controllers. Measurement list IOCLKMUO uses the sum of IOC measurement IOCLKMBU. Normalizer IOCLKMUO is normalized per working P-side IOC link per unit time.
Page 233 6-119 SPMS MTCPERF index descriptions 6-119 6-119 Aggregate index MSLNKPF for SuperNode LINKPERF components Section LINKPERF Description Message switch link performance Definition The summary of the maintenance performance of message switch (MS) P-side links. Note that these links include the links to the computing modules (CM).
Page 234: Basic Index Mslnkerr For Supernode Linkperf Components
6-120 6-120 SPMS MTCEPERF index descriptions 6-120 Basic index MSLNKERR for SuperNode LINKPERF components Section LINKPERF Description Message switch link error Definition The per-call occurrence of errors on message switch P-side links. Measurement list MSLNKERR uses measurement MS MSPTERR, summed over both message switches.
Page 235 6-121 SPMS MTCEPERF index descriptions 6-121 6-121 Basic index MSLNKFLT for SuperNode LINKPERF components Section LINKPERF Description Message link switch fault Definition The unit failure rate of message switch P-side links. Measurement list MSLNKFLT uses measurement MS MSPTFLT, summed over both message switches.
Page 236: Basic Index Mslnksuo For Supernode Linkperf Components
6-122 6-122 SPMS MTCEPERF index descriptions 6-122 Basic index MSLNKSUO for SuperNode LINKPERF components Section LINKPERF Description Message switch (MS) link unit system outage Definition The unit unavailability of message switch P-side links, as a result of system actions. Measurement list MSLNKSUO uses measurement MS MSPTSBU summed over both message switches.
Page 237 6-123 SPMS MTCEPERF index descriptions 6-123 6-123 Basic index MSLNKMUO for SuperNode LINKPERF components Section LINKPERF Description Message switch (MS) link unit manual outage Definition The unit unavailability of message switch P-side links, as a result of manual actions. Measurement list MSLNKMUO uses measurement MS MSPTMBU summed over both message switches.
Page 238: Aggregate Index Nmlnkpf
6-124 6-124 SPMS MTCEPERF index descriptions 6-124 Aggregate index NMLNKPF Section LINKPERF Description Network module link performance Definition The summary of the maintenance performance of speech paths within network modules, and of speech and message links between network modules and peripherals. Diagnostics Check the indices shown in the equation above to get more information on the nature of the network problems.
Page 239: Aggregate Index Nmmsglpf
6-125 SPMS MTCEPERF index descriptions 6-125 6-125 Aggregate index NMMSGLPF Section LINKPERF Description Network module message link performance Definition The summary of the error and fault performance of the messaging links between the individual planes of the network modules and the peripherals attached to them.
Page 240: Basic Index Nmmsgler
6-126 6-126 SPMS MTCEPERF index descriptions 6-126 Basic index NMMSGLER Section LINKPERF Description Network module message link error Definition The per-call rate of occurrence of errors on the message links between network modules and peripherals. Measurement list NMMSGLER uses measurement NMC NMMSGER. Normalizer NMMSGLER is normalized per total call attempt on the office.
Page 241: Basic Index Nmmsglfl
6-127 SPMS MTCEPERF index descriptions 6-127 6-127 Basic index NMMSGLFL Section LINKPERF Description Network module message link fault Definition The failure rate per working link of the message links between network modules and peripherals. Measurement list NMMSGLFL uses measurement NMC NMMSGFL. Normalizer NMMSGLFL is normalized per working message link per unit time.
Page 242 6-128 6-128 SPMS MTCEPERF index descriptions 6-128 Aggregate index NMSPCHPF Aggregate index NMSPCHPF (continued) Section LINKPERF Description Network module speech performance Definition The error and fault performance of speech paths through the network. Measurement list None Normalizer None Diagnostics Review network integrity performance using the NETINTEG analysis tool at the NET level of the MAP.
Page 243: Basic Index Nmspcher
6-129 SPMS MTCEPERF index descriptions 6-129 6-129 Basic index NMSPCHER Section LINKPERF Description Network module speech error Definition The rate of occurrence of errors on speech paths through the network, per CCS of traffic carried. Measurement list NMSPCHER uses measurement NMC NMSPCHER. Normalizer NMSPCHER is normalized by the sum over all network modules of network traffic registers TS TS0 through TS7.
Page 244: Basic Index Nmspchfl
6-130 6-130 SPMS MTCEPERF index descriptions 6-130 Basic index NMSPCHFL Section LINKPERF Description Network module speech fault Definition The rate at which path hard faults are detected in speech path per network module plane. Measurement list NMSPCHFL uses measurement NMC NMSPCHFL. Normalizer NMSPCHFL is normalized per network module plane per unit time.
Page 245: Basic Index Nmptsout
6-131 SPMS MTCEPERF index descriptions 6-131 6-131 Basic index NMPTSOUT Section LINKPERF Description Network module port system outage Definition The unit unavailability of network module peripheral facing ports. Each port carries 30 speech channels plus a potential message link. Measurement list NMPTSOUT uses the sum of NMC measurement NMPTSBU.
Page 246: Basic Index Nmptmout
6-132 6-132 SPMS MTCEPERF index descriptions 6-132 Basic index NMPTMOUT Section LINKPERF Description Network module port manual outage Definition The unit unavailability of network module peripheral facing ports. Such a port carries 30 speech channels plus a potential message link. Measurement list NMPTMOUT uses the sum of NMC measurement NMPTMBU.
Page 247: Basic Index Nmjctsou
6-133 SPMS MTCEPERF index descriptions 6-133 6-133 Basic index NMJCTSOU Section LINKPERF Description Network module junctor system outage Definition The unavailability of network module junctor facing ports. Each port carries 31 speech channels. Measurement list NMJCTSOU uses the sum of NMC measurement NMJRSBU. Normalizer NMJCTSOU is normalized per network module port per unit time.
Page 248: Basic Index Nmjctmou
6-134 6-134 SPMS MTCEPERF index descriptions 6-134 Basic index NMJCTMOU Section LINKPERF Description Network module junctor manual outage Definition The unavailability of network module junctor facing ports. Each port carries 31 speech channels. Measurement list NMJCTMOU uses the sum of NMC measurement NMJRMBU. Normalizer NMJCTMOU is normalized per network module port per unit time.
Page 249: Aggregate Index Enlkperf For Enet Linkperf Components
6-135 SPMS MTCEPERF index descriptions 6-135 6-135 Aggregate index ENLKPERF for ENET LINKPERF components Section LINKPERF Description Enhanced network (ENET) link performance Definition ENLKPERF provides a summary of the performance of the ENET matrix cards and P-side links. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 250: Basic Index Enlkerr For Enet Linkperf Components
6-136 6-136 SPMS MTCEPERF index descriptions 6-136 Basic index ENLKERR for ENET LINKPERF components Section LINKPERF Description ENET link errors Definition ENLKERR monitors the number of errors occurring in the link components of the ENET. This includes the P-side links as well as the matrix card components (that is, crosspoint cards and paddle boards).
Page 251 6-137 SPMS MTCEPERF index descriptions 6-137 6-137 Basic index ENLKFLT for ENET LINKPERF components Section LINKPERF Description ENET link faults Definition ENLKFLT monitors the number of hard faults occurring in the link components of the ENET. Measurement list ENLKFLT uses the sum of operational measurements ENCDFLT and ENPBFLT of OM group ENETMAT, and ENLKFLT of OM group ENETPLNK.
Page 252: Basic Index Enlksout For Enet Linkperf Components
6-138 6-138 SPMS MTCEPERF index descriptions 6-138 Basic index ENLKSOUT for ENET LINKPERF components Section LINKPERF Description Enhanced network (ENET) system-busy link components Definition ENLKSOUT monitors system-busy link components in the ENET. Measurement list ENLKSOUT uses the sum of operational measurements ENSBCDU and ENSBPBU of OM group ENETMAT, and ENSBLKU of OM group ENETPLNK.
Page 253 6-139 SPMS MTCEPERF index descriptions 6-139 6-139 Basic index ENLKMOUT for ENET LINKPERF components Section LINKPERF Description Enhanced network (ENET) manual-busy link components Definition ENLKMOUT monitors manual-busy link components in the ENET. Measurement list ENLKMOUT uses the sum of operational measurements ENMBCDU and ENMBPBU of OM group ENETMAT, and ENMBLKU of OM group ENETPLNK.
Page 254: Basic Index Enlkinac For Enet Linkperf Components
6-140 6-140 SPMS MTCEPERF index descriptions 6-140 Basic index ENLKINAC for ENET LINKPERF components Section LINKPERF Description Enhanced network (ENET) inaccessible paths Definition ENLKINAC monitors the number of inaccessible paths between P-side links due to out of service components in the ENET. Measurement list ENLKINAC uses the sum of operational measurements ENPARULO and ENPARUHI of OM group ENETSYS.
Page 255: Basic Index Enlkisol For Enet Linkperf
6-141 SPMS MTCEPERF index descriptions 6-141 6-141 Basic index ENLKISOL for ENET LINKPERF Section LINKPERF Description Enhanced network (ENET) isolated peripherals Definition ENLKISOL monitors the number of PMs isolated because-of-out of service components in the ENET. Measurement list ENLKISOL uses the sum of operational measurements ENISOU of OM group ENETSYS, ENCDISOU and ENPBISOU of OM group ENETMAT, and ENLKISOU of OM group ENETPLNK.
Page 256: Aggregate Index Pmlnkpf
6-142 6-142 SPMS MTCEPERF index descriptions 6-142 Aggregate index PMLNKPF Section LINKPERF Description Peripheral module link performance Definition The summary of the maintenance performance of digital links to remote PMs. Diagnostics Determine which carrier system is causing unfavorable results by reviewing the results in OM group DS1CARR (PCMCARR in International offices).
Page 257: Basic Index Pmlnkerr
6-143 SPMS MTCEPERF index descriptions 6-143 6-143 Basic index PMLNKERR Section LINKPERF Description Peripheral module link error Definition The error rate on digital carrier links to remote PMs. Measurement list PMLNKERR uses the sum of DS1CARR measurements DS1BER, DS1LOF, and DS1SLP. In International offices, PMLNKERR uses the sum of PCMCARR measurements LLFAERR, LLMAERR, RFAIERR, RMAIERR, AISERR, BERERR, SLIPERR, SIGLERR, CRC4ERR, AISI6ERR, LLCMAERR, and CREERR.
Page 258: Basic Index Pmlnkflt
6-144 6-144 SPMS MTCEPERF index descriptions 6-144 Basic index PMLNKFLT Section LINKPERF Description Peripheral module link fault Definition The failure rate on digital carrier links to remote PMs. Measurement list PMLNKFLT uses the sum of DS1CARR measurements DS1AIS, DS1LCGA and DS1RCGA. In International offices, PMLNKFLT uses the sum of PCMCARR measurements LLFAFLT, LLMAFLT, RFAIFLT, RMAIFLT, AISFLT, BERFLT, SLIPFLT, SIGLFLT, CRC4FLT, AISI6FLT, LLCMAFLT, and CREFLT.
Page 259: Basic Index Pmlksuou
6-145 SPMS MTCEPERF index descriptions 6-145 6-145 Basic index PMLKSUOU Section LINKPERF Description Peripheral module (PM) link system unit outage Definition The unit unavailability of digital carrier links to remote PMs. Measurement list PMLKSUOU uses the sum of DS1CARR measurement DS1SBU. In International offices, this index uses the sum of PCMCARR measurement CARRSYSB.
Page 260: Basic Index Pmlkmuou
6-146 6-146 SPMS MTCEPERF index descriptions 6-146 Basic index PMLKMUOU Section LINKPERF Description Peripheral module (PM) link manual unit outage Definition The unit unavailability of digital carrier links to remote PMs. Measurement list PMLKMUOU uses the sum of DS1CARR measurement DS1MBU. In International offices, this index uses the sum of PCMCARR measurement CARRMANB.
Page 261 6-147 SPMS MTCEPERF index descroptions 6-147 6-147 Basic index NDLKERR Basic index NDLKERR (continued) (continued) Section NDLNKPF Description Node link error Definition Index NDLKERR is the total link error rate for the node maintenance message channel and the physical link channel. Measurement NDLKERR uses measurements NMTCLINK NDMCHERR and NDPLIERR...
Page 262 6-148 6-148 SPMS MTCEPERF index descroptions 6-148 Basic index NDLKFLT Basic index NDLKFLT Basic index NDLKFLT (continued) (end) (continued) Section NDLNKPF Description Node link fault Definition Index NDLKFLT is the total node-link fault rate for the message and physical link channels A measurement of faults that persist after system diagnostics have been executed.
Page 263 6-149 SPMS MTCEPERF index descroptions 6-149 6-149 Basic index NDLKOUT Basic index NDLKOUT (continued) (continued) Section NDLKPF Description Node link outage Definition NDLKOUT indicates the total number of message channels and physical links that are system or manually busy. Measurement NDLKOUT is the sum of measurements NMTCLINK NDMCHMBP, NDMCHSBP, NDPLKSBP, and NDPLKMBP.
Page 264: Aggregate Index C7Lnkpf
6-150 6-150 SPMS MTCEPERF index descriptions 6-150 Aggregate index C7LNKPF Section LINKPERF Description CCS7 link performance Definition C7LNKPF provides information on the availability and failure of the links and the availablity of the linkset. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 265: Aggregate Index C7Link
6-151 SPMS MTCEPERF index descriptions 6-151 6-151 Aggregate index C7LINK Section LINKPERF Description CCS7 link Definition C7LINK provides information on the availability and failure of the links. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 266: Basic Index C7Lnksfl
6-152 6-152 SPMS MTCEPERF index descriptions 6-152 Basic index C7LNKSFL Section LINKPERF Description CCS7 link synchronization failure Definition C7LNKSFL monitors the failure rate of the CCS7 link due to one or more of the following reasons: abnormal forward indicator bit Rx (FIBR) backward sequence number Rx (BSNR) excessive delay of acknowledgement from the signaling terminal (ST) excessive duration of congestion (remote congestion timeout)
Page 267: Basic Index C7Lnkout
6-153 SPMS MTCEPERF index descriptions 6-153 6-153 Basic index C7LNKOUT Section LINKPERF Description CCS7 link outage Definition C7LNKOUT monitors the availability of CCS7 links. The system busy and manual busy link states are considered unavailable. Measurement list C7LNKOUT uses measurement C7LKUNAU of OM group C7LINK1. Normalizer C7LNKOUT is normalized per working CCS7 link per unit time.
Page 268: Basic Index C7Lsout
6-154 6-154 SPMS MTCEPERF index descriptions 6-154 Basic index C7LSOUT Section LINKPERF Description CCS7 linkset outage Definition C7LSOUT provides information on the outage of the linkset. This index monitors the availability of the CCS7 linkset. System busy and manual busy are the link states considered unavailable.
Page 269: Aggregate Index Termnals
6-155 SPMS MTCEPERF index descriptions 6-155 6-155 Aggregate index TERMNALS Section TERMNALS Description Terminals Definition The summary of the performance of devices controlled by the IOC and the peripheral modules. These include tape, disk, and console units; service circuits of various kinds; operator positions, lines, trunks, and digital carrier facilities.
Page 270: Aggregate Index Iodev
6-156 6-156 SPMS MTCEPERF index descriptions 6-156 Aggregate index IODEV Section TERMNALS Description Input/output device Definition The summary of the maintenance performance of the various types of terminal equipment attached to the IOCs. Diagnostics To identify the source of unfavorable results, check the indices from which IODEV is derived.
Page 271: Aggregate Index Mtuperf
6-157 SPMS MTCEPERF index descriptions 6-157 6-157 Aggregate index MTUPERF Section TERMNALS Description Magnetic tape unit performance Definition The summary of the maintenance performance of magnetic tape devices. Diagnostics IOD subsystem logs may give more details. Diagnose magnetic tape troubles at the MTD level of the MAP. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 272: Basic Index Mtuerr
6-158 6-158 SPMS MTCEPERF index descriptions 6-158 Basic index MTUERR Section TERMNALS Description Magnetic tape unit error Definition The rate of occurrence of errors in magnetic tape unit operation. Measurement list MTUERR uses measurement MTU MTUERR. Normalizer MTUERR is normalized per working tape unit per unit time. Diagnostics Verify OM group MTU (MTUERR).
Page 273: Basic Index Mtuflt
6-159 SPMS MTCEPERF index descriptions 6-159 6-159 Basic index MTUFLT Section TERMNALS Description Magnetic tape unit fault Definition The rate of occurrence of persistent malfunctions of magnetic tape units. Measurement list MTUFLT uses measurement MTU MTUFLT. Normalizer MTUFLT is normalized per working tape unit per unit time. Diagnostics Verify OM group MTU (MTUFLT).
Page 274: Basic Index Mtusout
6-160 6-160 SPMS MTCEPERF index descriptions 6-160 Basic index MTUSOUT Section TERMNALS Description Magnetic tape unit system outage Definition The unavailability of magnetic tape units as a result of system actions. Measurement list MTUSOUT uses the sum of MTU measurement MTUSBU. Normalizer MTUSOUT is normalized per working tape unit per unit time.
Page 275: Basic Index Mtumout
6-161 SPMS MTCEPERF index descriptions 6-161 6-161 Basic index MTUMOUT Section TERMNALS Description Magnetic tape unit manual outage Definition The unavailability of magnetic tape units as a result of manual actions. Measurement list MTUMOUT uses the sum of MTU measurement MTUMBU. Normalizer MTUMOUT is normalized per working tape unit per unit time.
Page 276: Aggregate Index Dduperf
6-162 6-162 SPMS MTCEPERF index descriptions 6-162 Aggregate index DDUPERF Section TERMNALS Description Disk drive unit performance Definition The summary of the maintenance performance of disk units and their controllers. Diagnostics DDU subsystem logs may give more details. Diagnose disk unit and controller troubles at the DDU level of the MAP.
Page 277: Basic Index Dduerr
6-163 SPMS MTCEPERF index descriptions 6-163 6-163 Basic index DDUERR Section TERMNALS Description Disk drive unit error Definition The rate of occurrence of errors in disk drive unit operation. Measurement list DDUERR uses measurement DDU DDUERROR. Normalizer DDUERR is normalized per working disk drive unit per unit time. Diagnostics Verify OM group DDUERROR.
Page 278: Basic Index Dduflt
6-164 6-164 SPMS MTCEPERF index descriptions 6-164 Basic index DDUFLT Section TERMNALS Description Disk drive unit fault Definition The rate of occurrence of persistent disk drive unit malfunctions. Measurement list DDUFLT uses measurement DDU DDUFAULT. Normalizer DDUFLT is normalized per working disk drive unit per unit time. Diagnostics Verify OM group DDUFAULT.
Page 279: Basic Index Ddusout
6-165 SPMS MTCEPERF index descriptions 6-165 6-165 Basic index DDUSOUT Section TERMNALS Description Disk drive unit system outage Definition The unavailability of disk drive units because of system actions. Measurement list DDUSOUT uses the sum of DDU measurement DDUSBUSY. Normalizer DDUSOUT is normalized per working disk drive unit per unit time.
Page 280: Basic Index Ddumout
6-166 6-166 SPMS MTCEPERF index descriptions 6-166 Basic index DDUMOUT Section TERMNALS Description Disk drive unit manual outage Definition The unavailability of disk drive units because of manual actions. Measurement list DDUMOUT uses the sum of DDU measurement DDUMBUSY. Normalizer DDUMOUT is normalized per working disk drive unit per unit time.
Page 281: Aggregate Index Consolpf
6-167 SPMS MTCEPERF index descriptions 6-167 6-167 Aggregate index CONSOLPF Section TERMNALS Description Console performance Definition The summary of the maintenance performance of MAP positions, line printers, and similar console devices attached to the switch. Diagnostics IOD subsystem logs may give more details. Work with console devices at the CARD level of the MAP.
Page 282: Basic Index Cslerr
6-168 6-168 SPMS MTCEPERF index descriptions 6-168 Basic index CSLERR Section TERMNALS Description Console device errors Definition The rate of occurrence of errors in the operation of a console device. Measurement list CSLERR uses measurement CSL CSLERR. Normalizer CSLERR is normalized per working console device per unit time. Diagnostics Verify OM group CSL (CSLERR).
Page 283: Basic Index Cslsout
6-169 SPMS MTCEPERF index descriptions 6-169 6-169 Basic index CSLSOUT Section TERMNALS Description Console device system outage Definition The unit unavailability of console devices because of system actions. Measurement list CSLSOUT uses the sum of CSL measurement CSLSBU. Normalizer CSLSOUT is normalized per working console device per unit time. Diagnostics Verify OM group CS (CSLSBU).
Page 284: Basic Index Cslmout
6-170 6-170 SPMS MTCEPERF index descriptions 6-170 Basic index CSLMOUT Section TERMNALS Description Console device manual outage Definition The unit unavailability of console devices because of manual actions. Measurement list CSLMOUT uses the sum of CSL measurement CSLMBU. Normalizer CSLMOUT is normalized per working console device per unit time. Diagnostics Verify OM group CS (CSLMBU) and ensure that these results agree with manual maintenance being performed.
Page 285: Aggregate Index Srvcctpf
6-171 SPMS MTCEPERF index descriptions 6-171 6-171 Aggregate index SRVCCTPF Section TERMNALS Description Service circuit performance Definition The summary of the performance of the various classes of service circuit used in call processing. Diagnostics To isolate poor results, check the indices that make up SRVCCTPF. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 286: Aggregate Index Confperf
6-172 6-172 SPMS MTCEPERF index descriptions 6-172 Aggregate index CONFPERF Section TERMNALS Description Conference performance Definition The summary of the maintenance performance of three-port and six-port conference circuits. Diagnostics To isolate the source of poor results, check the indices that make up CONFPERF.
Page 287: Basic Index Cnf3Perf
6-173 SPMS MTCEPERF index descriptions 6-173 6-173 Basic index CNF3PERF Section TERMNALS Description Three-port conference performance Definition The CNF3PERF index measures the unavailability of three-port conference circuits regardless of cause. The SPMS indices have been calibrated to take into account Automatic Trunk Testing (ATT) and system audits. Measurement list CNF3PERF uses the sum of CF3P measurements CNFSBU, CNFMBU, CNFSBUT, and CNFMBUT.
Page 288: Basic Index Cnf6Perf
6-174 6-174 SPMS MTCEPERF index descriptions 6-174 Basic index CNF6PERF Section TERMNALS Description Six-port conference performance Definition The unavailability of six-port conference circuits. Measurement list CNF6PERF uses the sum of CF6P measurements CF6SBU and CF6MBU. Normalizer CNF6PERF is normalized per working conference circuit per unit time. Diagnostics Check OM group CF6P measurements CF6SBU and CF6MBU to determine if six-port conference circuits are manual busy or system busy.
Page 289: Basic Index Annstnpf
6-175 SPMS MTCEPERF index descriptions 6-175 6-175 Basic index ANNSTNPF Section TERMNALS Description Announcement and tone performance Definition The unavailability of announcements and special tones. Measurement list ANNSTNPF uses the sum of ANN measurements ANNSBU and ANNMBU summed over all announcement types, plus the sum of STN measurements STNSBU and STNMBU summed over all special tone types.
Page 290: Basic Index Esupperf
6-176 6-176 SPMS MTCEPERF index descriptions 6-176 Basic index ESUPPERF Section TERMNALS Description Echo suppressor performance Definition The unavailability of digital echo-suppressor circuits. DMS-100G Switch does not contribute to or provide an equivalent of OM group ESUP. Measurement list ESUPPERF uses the sum of ESUP measurements DESSBU and DESMBU. Normalizer ESUPPERF is normalized per working echo-suppressor circuit per unit time.
Page 291: Basic Index Rcvrperf
6-177 SPMS MTCEPERF index descriptions 6-177 6-177 Basic index RCVRPERF Section TERMNALS Description Receiver performance Definition The unavailability of receiver circuits. Measurement list RCVRPERF uses the sum of RCVR measurements RCVSBU and RCVMBU, totalled over all receiver kinds. Normalizer RCVRPERF is normalized per working receiver circuit per unit time. Diagnostics The indication is that one or several receivers are either system busy or manual busy.
Page 292: Basic Index Specsvpf
6-178 6-178 SPMS MTCEPERF index descriptions 6-178 Basic index SPECSVPF Section TERMNALS Description Special service performance Definition The unavailability of special service circuits. These include Digitone outpulsers, R2 inter-register signaling circuits, and service-observing circuits. DMS-100G Switch does not contribute to or provide an equivalent of OM group SVCT Measurement list SPECSVPF uses the sum of SVCT measurements SVCSBU and SVCMBU,...
Page 293: Aggregate Index Oppospf
6-179 SPMS MTCEPERF index descriptions 6-179 6-179 Aggregate index OPPOSPF Section TERMNALS Description Operator position performance Definition The summary of the maintenance performance of operator positions and associated data circuits. Diagnostics To isolate the location of poor results, check the indices that make up OPPOSPF.
Page 294: Aggregate Index Topsperf
6-180 6-180 SPMS MTCEPERF index descriptions 6-180 Aggregate index TOPSPERF Section TERMNALS Description Traffic operator position performance Definition The summary of the maintenance performance of TOPS positions and associated data circuits. Diagnostics To isolate the location of poor results, check the indices that make up TOPSPERF.
Page 295: Basic Index Tposflt
6-181 SPMS MTCEPERF index descriptions 6-181 6-181 Basic index TPOSFLT Section TERMNALS Description TOPS position fault Definition The failure rate of TOPS positions with their associated trunks and digital modems. Measurement list TPOSFLT uses the sum of TOPSMTCE measurements POSDF, POSTRKDF, and POSDMDF.
Page 296: Basic Index Tposout
6-182 6-182 SPMS MTCEPERF index descriptions 6-182 Basic index TPOSOUT Section TERMNALS Description TOPS position outage Definition The unavailability of TOPS positions. Measurement list TPOSOUT uses measurement TOPSUSE POSMTCE. Normalizer POSOUT is normalized per working position per unit time. Diagnostics TOPS positions were maintenance busy.
Page 297: Basic Index Virtcfl
6-183 SPMS MTCEPERF index descriptions 6-183 6-183 Basic index VIRTCFL Section TERMNALS Description Virtual circuit fault Definition The data transmission performance of the virtual circuits associated with TOPS operator centralization. Measurement list VIRTCFL uses measurement TOPSVC VCFL. Normalizer VIRTCFL is normalized per attempt to send a message on a virtual circuit. The number of attempts is given by the sum of TOPSVC measurements VCFL and VCNMSG.
Page 298: Basic Index Cposperf
6-184 6-184 SPMS MTCEPERF index descriptions 6-184 Basic index CPOSPERF Section TERMNALS Description Centralized automatic message accounting position performance Definition The unavailability of CAMA ONI/RONI positions in non-TOPS offices. Measurement list CPOSPERF uses the sum of ONI measurements ONISBU and ONIMBU. Normalizer CPOSPERF is normalized per working position per unit time.
Page 299: Aggregate Index Aossperf
6-185 SPMS MTCEPERF index descriptions 6-185 6-185 Aggregate index AOSSPERF Section TERMNALS Description Auxiliary operator services system (AOSS) performance Definition The summary of the maintenance performance of AOSS positions. Diagnostics Review procedures for monitoring and clearing AOSS position troubles. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 300: Basic Index Aosspflt
6-186 6-186 SPMS MTCEPERF index descriptions 6-186 Basic index AOSSPFLT Section TERMNALS Description Auxiliary operator services system (AOSS) position fault Definition The failure rate of AOSS positions. Measurement list AOSSPFLT uses measurement AOSS AOSSDF. Normalizer AOSSPFLT is normalized per working position per unit time. Diagnostics Verify OM group AOSS (AOSSDF).
Page 301: Basic Index Aosspout
6-187 SPMS MTCEPERF index descriptions 6-187 6-187 Basic index AOSSPOUT Section TERMNALS Description Auxiliary operator services system (AOSS) position outage Definition The unavailability of AOSS positions. Measurement list AOSSPOUT uses measurement AOSS AOSSOD. Normalizer AOSSPOUT is normalized per working position per unit time. Diagnostics Verify OM group AOSS (AOSSOD).
Page 302: Aggregate Index Attconpf
6-188 6-188 SPMS MTCEPERF index descriptions 6-188 Aggregate index ATTCONPF Section TERMNALS Description Attendant console performance Definition The summary of attendant console performance. Diagnostics Review procedures for monitoring and clearing attendant console troubles. 297-1001-330 Standard 11.04 June 1998...
Page 303: Basic Index Attcnerr
6-189 SPMS MTCEPERF index descriptions 6-189 6-189 Basic index ATTCNERR Section TERMNALS Description Attendant console errors Definition The per-call error rate of attendant consoles. Measurement list ATTCNERR uses measurements ACSYSTR ACDMFL, ACCF3PFL, and ACERR. Normalizer ATTCNERR is normalized per total call attempt. Diagnostics Check logs IBN101 and IBN104.
Page 304: Basic Index Attcnflt
6-190 6-190 SPMS MTCEPERF index descriptions 6-190 Basic index ATTCNFLT Section TERMNALS Description Attendant console fault Definition The failure rate of attendant consoles. Measurement list ATTCNFLT uses measurement ACSYSTR ACFLT. Normalizer ATTCNFLT is normalized per working attendant console per unit time. Diagnostics Check log IBN102.
Page 305: Aggregate Index Aopsperf
6-191 SPMS MTCEPERF index descriptions 6-191 6-191 Aggregate index AOPSPERF Section TERMNALS Description Automated operator system (AOPS) performance Definition The summary of the maintenance performance of certain automated operator feature components which make up AABS (automated alternate billing system), ADACC (automatic directory assistance call completion), and ADAS (automatic directory assistance services).
Page 306: Basic Index Vsnflt
6-192 6-192 SPMS MTCEPERF index descriptions 6-192 Basic index VSNFLT Section TERMNALS Description Voice service node fault Definition The failure rate of voice service node (VSN) applications such as AABS (automated alternate billing system) and ADAS (automatic directory assistance services). Measurement list VSNFLT is calculated from the accumulation of the sum of VSNCOM measurements VSNIDFL, VSNNOVL, VSNIVFL, VSNDABT, VSNVABA,...
Page 307: Basic Index Vsnlkflt
6-193 SPMS MTCEPERF index descriptions 6-193 6-193 Basic index VSNLKFLT Section TERMNALS Description Voice service node link fault Definition Monitors the performance of application messaging between the voice service node (VSN) and the DMS switch. It is used in applications such as AABS (automated alternate billing system) and ADAS (automatic directory assistance services).
Page 308: Basic Index Vpscflt
6-194 6-194 SPMS MTCEPERF index descriptions 6-194 Basic index VPSCFLT Section TERMNALS Description Voice processing service circuits fault Definition Monitors the performance of all voice processing platform (VPP) service circuits used in applications such as ADAS (automatic directory assistance services). Measurement list VPSCFLT is calculated from the accumulation of the sum of VPSC measurements VPSCMIS and VPSCFLT.
Page 309: Basic Index Apuflt
6-195 SPMS MTCEPERF index descriptions 6-195 6-195 Basic index APUFLT Section TERMNALS Description Application processing unit fault Definition Monitors the performance for advanced services which use APU-based call processing engines (CPE) in applications such as ADAS (automatic directory assistance services). Measurement list APUFLT is calculated from the accumulation of the sum of AASV measurements AASVFL and AASVSFL.
Page 310: Basic Index Damsgflt
6-196 6-196 SPMS MTCEPERF index descriptions 6-196 Basic Index DAMSGFLT Section TERMNALS Description Directory assistance message fault Definition Monitors the performance of the attempts to send messages from the DMS central control (CC) to the directory assistance system (DAS). Measurement list DAMSGFLT is calculated from the accumulation of the DALINK measurement MSGSNDFL.
Page 311: Basic Index Aruflt
6-197 SPMS MTCEPERF index descriptions 6-197 6-197 Basic index ARUFLT Section TERMNALS Description Audio response unit fault Definition Monitors the performance for all ARUs which provide service for applications such as ADACC (automatic directory assistance call completion). Measurement list ARUFLT is calculated from the accumulation of the sum of TOPSARU measurements DAARUAF and INTARUAF.
Page 312: Basic Index Arudaav
6-198 6-198 SPMS MTCEPERF index descriptions 6-198 Basic index ARUDAAV Section TERMNALS Description Audio response unit directory assistance availability Definition Monitors the ARU availability for directory assistance calls. Measurement list ARUDAAV is calculated from the accumulation of the measurements INTARUUN and DAARUUN in TOPSARU. Normalizer ARUDAAV is normalized by the sum of each attempt made to release a directory assistance call to an ARU announcement and each attempt made to...
Page 313: Aggregate Index Slmperf
6-199 SPMS MTCEPERF index descriptions 6-199 6-199 Aggregate index SLMPERF Section TERMNALS Description System load module (SLM) performance Definition The summary of the maintenance performance of system load modules. Diagnostics Check the SLMPERF basic indices SLMFAULT, SLMSOUT, and SLMMOUT for low values. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 314: Basic Index Slmfault
6-200 6-200 SPMS MTCEPERF index descriptions 6-200 Basic index SLMFAULT Section TERMNALS Description System load module (SLM) fault Definition The number of faults detected in the SLM card. Measurement list SLMFAULT uses measurement SLMFLT of OM group SLM. Normalizer SLMFAULT is normalized per working SLM unit per unit time. Diagnostics Check OM group SLM, register SLMFAULT.
Page 315: Basic Index Slmsout
6-201 SPMS MTCEPERF index descriptions 6-201 6-201 Basic index SLMSOUT Section TERMNALS Description System load module (SLM) system outage Definition The unavailability, caused by system action (system busy or C-side busy), of the primary SLM. Measurement list SLMSOUT uses measurement SLMSBSU of OM group SLM. Normalizer SLMSOUT is normalized per working SLM unit per unit time.
Page 316: Basic Index Slmmout
6-202 6-202 SPMS MTCEPERF index descriptions 6-202 Basic index SLMMOUT Section TERMNALS Description System load module (SLM) manual outage Definition The unavailability of the primary SLM, caused by manual action. Measurement list SLMMOUT uses measurement SLMMBSU of OM group SLM. Normalizer SLMMOUT is normalized per working SLM unit per unit time.
Page 317: Aggregate Index Lineperf
6-203 SPMS MTCEPERF index descriptions 6-203 6-203 Aggregate index LINEPERF Section TERMNALS Description Line performance Definition The summary of the maintenance performance of lines as individual circuits. Diagnostics Review line maintenance procedures to ensure early recognition of faults and minimal line outage. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 318: Basic Index Lineflt
6-204 6-204 SPMS MTCEPERF index descriptions 6-204 Basic index LINEFLT Section TERMNALS Description Line fault (subscriber loops) Definition The failure rate of subscriber loops. Measurement list LINEFLT uses measurement PMTYP PMTCCTOP, summed over LM, RCT, RCU, RCS, LCM, ESA, ISLM, ILCM, and ELM PM types. Normalizer LINEFLT is normalized per working line per unit time.
Page 319: Basic Index Lineout
6-205 SPMS MTCEPERF index descriptions 6-205 6-205 Basic index LINEOUT Section TERMNALS Description Line outage Definition The unavailability of individual line circuits. DMS-100G Switch does not contribute to or provide an equivalent of OM group SYSPERF Measurement list LINEOUT uses measurement SYSPERF LINCCTBU. This excludes outage in the LM-busy state;...
Page 320: Aggregate Index Trkperf
6-206 6-206 SPMS MTCEPERF index descriptions 6-206 Aggregate index TRKPERF Section TERMNALS Description Trunk performance Definition The summary of the maintenance performance of trunks. Diagnostics Check indices TMPERF, XPMPERF, DCMPERF, and CARRPERF to see if the outage was caused by PM or carrier facility failure. Such an outage is also counted in SYSPERF TKPCBU.
Page 321: Basic Index Trkflt
6-207 SPMS MTCEPERF index descriptions 6-207 6-207 Basic index TRKFLT Section TERMNALS Description Trunk fault Definition The failure rate of trunks outside plant. DMS-100G Switch does not contribute to or provide an equivalent of OM group PMTYP, measurement PMTCCTOP. Measurement list TRKFLT uses measurement PMTYP PMTCCTOP, summed over DTC, IDTC, LTC, RCC, ILTC, ADTC, PDTC, TM2, TM4, TM8, ATM, T8A, TMA, PTM, DCM, DCM250 and DCMT PM types.
Page 322: Basic Index Intrksou
6-208 6-208 SPMS MTCEPERF index descriptions 6-208 Basic index INTRKSOU Section TERMNALS Description Incoming trunk system outage Definition The average fraction of equivalent one-way incoming trunks is unable to give access to the switch because of an outage in the peripherals on which the trunks terminate, failures in the facilities carrying the trunks, or failures of individual trunks.
Page 323: Basic Index Intrkmou
6-209 SPMS MTCEPERF index descriptions 6-209 6-209 Basic index INTRKMOU Section TERMNALS Description Incoming trunk manual outage Definition The average fraction of equivalent one-way incoming trunks is unable to give access to the switch because of a manual outage. DMS-100G Switch does not contribute to or provide an equivalent of OM group TRK, measurement MBU Measurement list The measurement used for INTRKMOU is the sum of maintenance-busy...
Page 324: Basic Index Ogtrksou
6-210 6-210 SPMS MTCEPERF index descriptions 6-210 Basic index OGTRKSOU Section TERMNALS Description Outgoing trunk system outage Definition The average fraction of equivalent one-way outgoing trunks is unable to give access to the switch because of an outage in the peripherals on which the trunks terminate, failures in the facilities carrying the trunks, or failures of individual trunks.
Page 325: Basic Index Ogtrkmou
6-211 SPMS MTCEPERF index descriptions 6-211 6-211 Basic index OGTRKMOU Section TERMNALS Description Outgoing trunk manual outage Definition The average fraction of equivalent one-way outgoing trunks is unable to give access to the switch because of a manual outage. DMS-100G Switch does not contribute to or provide an equivalent of OM group TRK, measurement MBU Measurement list The measurement used for OGTRKMOU is the sum of maintenance-busy...
Page 326: Basic Index C7Trkcfl
6-212 6-212 SPMS MTCEPERF index descriptions 6-212 Basic index C7TRKCFL Section TERMNALS Description CCS7 ISUP trunk connection failure Definition C7TRKCFL monitors the failure to make ISDN user part (ISUP) end-to-end connections due to one or more of the following reasons: switching equipment connection circuit availability incomplete address...
Page 327: Aggregate Index Carrperf
6-213 SPMS MTCEPERF index descriptions 6-213 6-213 Aggregate index CARRPERF Section TERMNALS Description Carrier performance Definition The summary of the maintenance performance of digital trunk carrier facilities. Diagnostics Determine the carrier system causing unfavorable results by review of the results in OM group DS1CARR (PCMCARR in International offices). Check at the CARRIER level of the MAP to determine if the troubles are in the office or the outside plant.
Page 328: Basic Index Carrerr
6-214 6-214 SPMS MTCEPERF index descriptions 6-214 Basic index CARRERR Section TERMNALS Description Carrier error Definition The error rates on digital carriers connecting to other switches. These include trunk carriers and timing links. DMS-100G Switch does not contribute to or provide an equivalent of OM group DS1CARR Measurement list CARRERR uses the sum of DS1CARR measurements DS1BER, DS1LOF,...
Page 329: Basic Index Carrflt
6-215 SPMS MTCEPERF index descriptions 6-215 6-215 Basic index CARRFLT Section TERMNALS Description Carrier fault Definition The failure rates on digital carriers connecting to other switches. These include trunk carriers and timing links. DMS-100G Switch does not contribute to or provide an equivalent of OM group DS1CARR.
Page 330: Basic Index Carrsout
6-216 6-216 SPMS MTCEPERF index descriptions 6-216 Basic index CARRSOUT Section TERMNALS Description Carrier system outage Definition The unit unavailability of digital-trunk and timing-carrier links to other switches. DMS-100G Switch does not contribute to or provide an equivalent of OM group DS1CARR.
Page 331: Basic Index Carrmout
6-217 SPMS MTCEPERF index descriptions 6-217 6-217 Basic index CARRMOUT Section TERMNALS Description Carrier manual outage Definition The unit unavailability of digital trunk and timing carrier links to other switches. DMS-100G Switch does not contribute to or provide an equivalent of OM group DS1CARR.
Page 332: Aggregate Index C7Rtperf
6-218 6-218 SPMS MTCEPERF index descriptions 6-218 Aggregate index C7RTPERF Section TERMNALS Description CCS7 route performance Definition C7RTPERF provides information on route availablity, route grade of service, routeset availability, and routeset congestion. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 333: Aggregate Index C7Route
6-219 SPMS MTCEPERF index descriptions 6-219 6-219 Aggregate index C7ROUTE Section TERMNALS Description CCS7 route Definition C7ROUTE provides information on the route grade of service and on the availability of the route. Diagnostics None DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 334: Basic Index C7Rtdegr
6-220 6-220 SPMS MTCEPERF index descriptions 6-220 Basic index C7RTDEGR Section TERMNALS Description CCS7 degraded route service Definition C7RTDEGR measures the number of messages that the CCS7 network cannot deliver to the destination through this route. Measurement list C7RTDEGR is the C7ROUTE measurement C7FRCRER and its extension register C72FRCRE.
Page 335: Basic Index C7Rtout
6-221 SPMS MTCEPERF index descriptions 6-221 6-221 Basic index C7RTOUT Section TERMNALS Description CCS7 route outage Definition C7RTOUT monitors the availability of the CCS7 route. The system-busy and manual-busy route states are considered unavailable. Measurement list C7RTOUT uses measurement C7RTUNAU from OM group C7ROUTE and measurement C7RTUNU from OM group C7ROUTE2.
Page 336: Aggregate Index C7Rtset
6-222 6-222 SPMS MTCEPERF index descriptions 6-222 Aggregate index C7RTSET Section TERMNALS Description CCS7 routeset Definition C7RTSET monitors the performance of the CCS7 routeset. This index provides information on the availability and congestion level of the routeset. Diagnostics None 297-1001-330 Standard 11.04 June 1998...
Page 337: Basic Index C7Rtstco
6-223 SPMS MTCEPERF index descriptions 6-223 6-223 Basic index C7RTSTCO Section TERMNALS Description CCS7 routeset congestion Definition C7RTSTCO measures routeset congestion. Only partial traffic capability is measured because only messages of certain priority can be routed. Measurement list C7RTSTCO uses measurement C7RSCNGU of OM group C7RTESET. Normalizer C7RTSTCO is normalized by the number of working CCS7 routes per unit time.
Page 338: Basic Index C7Rtstou
6-224 6-224 SPMS MTCEPERF index descriptions 6-224 Basic index C7RTSTOU Section TERMNALS Description CCS7 routeset outage Definition C7RTSTOU monitors the availability (the system or manual busy) states of the CCS7 routeset. Measurement list C7RTSTOU uses measurement C7RSUNAU of OM group C7RTESET. Normalizer C7RTSTOU is normalized by the number of working CCS7 routes per unit time.
Page 339: Spms Provres Index Descriptions
SPMS PROVRES index descriptions The following chapter provides index descriptions for the PROVRES branch of SPMS. The provisionable resources index (PROVRES) summarizes the performance of traffic provisionable resources for both hardware and software within the switch. The high level PROVRES index has five main branches, the call processing resources index (CPRES), the feature software register utilization index (FTRQRES), the extension blocks index (EXTBLKS), the service circuit resources index (SRVCTRES), and the...
Page 340 7-2 SPMS PROVRES index descriptions description definition diagnostics The information under these headings explains: the section below the PROVRES branch to which the index belongs the expansion of the index name the function and purpose of the index the steps required to locate the switch problem The following headings appear in each description of a basic index: section description...
Page 341: Aggregate Provres
SPMS PROVRES index description Aggregate PROVRES Section The provisional resources (PROVRES) index is a top level office performance (OFCPERF) index. The provisionable resources index derives data from the call processing resources (CPRES), feature software register utilization (FTRQRES), extension blocks (EXTBLKS), service circuit resources (SRVCTRES), and speech link status (CHANRES) indices.
Page 342: Aggregate Index Cpres
SPMS PROVRES index descriptions Aggregate index CPRES Section CPRES Description Call processing resources Definition The summary of the level of utilization of the CC and of key call processing software registers: call condense blocks (CCBOVFL), call processing letters (CPLOVFL), outgoing buffers (OUTBOVFL), multiblocks (MULTBOVF), wake-up blocks (WAKEOVFL), and call processes themselves (CPMAXBSY).
Page 343: Basic Index Ccoccup
SPMS PROVRES index descriptions Basic index CCOCCUP Section CPRES Description Call process real-time use Definition The proportion of time during which call processing is using all of the real time available to it. Measurement list CCOCCUP uses measurement CP2 CPWORKU. Normalizer CCOCCUP is normalized per unit time.
Page 344: Basic Index Ccbovfl
SPMS PROVRES index descriptions Basic index CCBOVFL Section CPRES Description Call condense blocks overflow Definition The overflow rate of call condense blocks. Measurement list CCBOVFL uses measurement CP CCBOVFL. Normalizer CCBOVFL is normalized by the sum of CP CCBSZ (with extension register CCBSZ2) and CCBOVFL.
Page 345: Basic Index Cpmaxbsy
SPMS PROVRES index descriptions Basic index CPMAXBSY Section CPRES Description Call process maximum busy Definition The proportion of calls forcibly released during processing because all call processes are busy. DMS-100G Switch does not contribute to or provide an equivalent of: OM group CP, measurement WAITDENY OM group OFZ, measurements NIN, and NIN2 Measurement list...
Page 346: Basic Index Cplovfl
SPMS PROVRES index descriptions Basic index CPLOVFL Section CPRES Description Call process letter overflow Definition The overflow rate of call process letters. DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Measurement list CPLOVFL uses the sum of CP measurements CPLOOVFL and CPLPOVFL.
Page 347: Basic Index Outbovfl
SPMS PROVRES index descriptions Basic index OUTBOVFL Section CPRES Description Outgoing buffers overflow DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of outgoing buffers. Measurement list OUTBOVFL uses measurement CP OUTBOVFL. CP2 OUTBHI is observed over the reporting period.
Page 348: Basic Index Multbovf
7-10 7-10 SPMS PROVRES index descriptions 7-10 Basic index MULTBOVF Section CPRES Description Multi-block overflow Definition The overflow rate of multi-blocks. DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Measurement list MULTBOVF uses measurement CP MULTOVFL. Normalizer MULTBOVFL is normalized by the sum of CP MULTSZ plus MULTOVFL.
Page 349: Basic Index Wakeovfl
7-11 SPMS PROVRES index descriptions 7-11 7-11 Basic index WAKEOVFL Section CPRES Description Wake-up block overflow DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of wake-up blocks. Measurement list WAKEOVFL uses measurement CP WAKEOVFL.
Page 350: Basic Index Eccbovfl
7-12 7-12 SPMS PROVRES index descriptions 7-12 Basic index ECCBOVFL Section CPRES Description Extended call condense block overflow DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of extended call condense blocks. Measurement list ECCBOVFL uses measurement CP2 ECCBOVFL.
Page 351: Aggregate Index Firqres
7-13 SPMS PROVRES index descriptions 7-13 7-13 Aggregate index FIRQRES Section FTRQRES Description Feature software register utilization Definition The summary of the level of utilization of various types of software registers associated with feature processing. Overflows of these registers may result in failure to serve attempts on features such as call forwarding and three-way calling.
Page 352: Basic Index Fqagovfl
7-14 7-14 SPMS PROVRES index descriptions 7-14 Basic index FQAGOVFL Section FTRQRES Description Feature queue agent overflow DMS-100G Switch dose not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of feature queue agent blocks. Measurement list FQAGOVFL uses the measurementin OM group FTRQ, field FTRQOVFL, key 0.
Page 353: Basic Index Fq0Wovfl
7-15 SPMS PROVRES index descriptions 7-15 7-15 Basic index FQ0WOVFL Section FTRQRES Description Feature queue zero-word overflow Definition The overflow rate of feature queue zero-word area blocks. Note that as of BCS21, call processing makes no use of this block type. DMS-100G Switch does not impact this basic index due to the different call processing infrastructure.
Page 354: Basic Index Fq2Wovfl
7-16 7-16 SPMS PROVRES index descriptions 7-16 Basic index FQ2WOVFL Section FTRQRES Description Feature queue two-word overflow DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of feature queue two-word area blocks. Measurement list FQ2WOVFL uses the measurement in OM group FTRQ, field FTRQOVFL, keys 2 and 8.
Page 355: Basic Index Fq4Wovfl
7-17 SPMS PROVRES index descriptions 7-17 7-17 Basic index FQ4WOVFL Section FTRQRES Description Feature queue four-word overflow DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of feature queue four-word area blocks. Measurement list FQ4WOVFL uses the measurement in OM group FTRQ, field FTRQOVFL, keys 3 and 9.
Page 356: Basic Index Fq8Wovfl
7-18 7-18 SPMS PROVRES index descriptions 7-18 Basic index FQ8WOVFL Section FTRQRES Description Feature queue eight-word overflow DMS-100G Switch does not impact this basic index due to the different call processing infrastructure. Definition The overflow rate of feature queue eight-word area blocks. Measurement list FQ8WOVFL uses the measurement in OM group FTRQ, field FTRQOVFL, keys 4 and 10.
Page 357: Basic Index Fq16Wovfl
7-19 SPMS PROVRES index descriptions 7-19 7-19 Basic index FQ16WOVFL Section FTRQRES Description Feature queue 16-word overflow Definition The overflow rate of feature queue 16-word area blocks. DMS-100G Switch does not impact this basic index due to the different call processing infrastructure.
Page 358: Basic Index Fq32Wovfl
7-20 7-20 SPMS PROVRES index descriptions 7-20 Basic index FQ32WOVFL Section FTRQRES Description Feature queue 32-word overflow Definition The overflow rate of feature queue 32-word area blocks. DMS-100G Switch does not impact this basic index due to the different call processing infrastructure.
Page 359: Aggregate Index Extblks
7-21 SPMS PROVRES index descriptions 7-21 7-21 Aggregate index EXTBLKS Section FTRQRES Description Extension blocks Definition The summary of the traffic status of extension blocks. EXTBLKS has been broken out into two groupings: extension blocks associated with feature-related call processing (FTREXT), and extension blocks associated with billing and call detail recording (BILLEXT).
Page 360: Aggregate Index Ftrext
7-22 7-22 SPMS PROVRES index descriptions 7-22 Aggregate index FTREXT Section EXTBLKS Description Feature extension Definition The summary of the level of utilization of extension block types associated with feature processing. The basic indices contributing to FTREXT monitor overflow rate of extension blocks that carry data required by various call processing features.
Page 361 SPMS PROVRES index descriptions 7-23 Aggregate index FTREXT (continued) FTREXT contributors (continued) Extension block format Basic index Office parameters codes LTDXOVFL LTD_EXT_DATA fixed at 20 KSHUNTXO KEY_SHORT_HUNT_EXT KSHUNT_EXT_BLOCKS NSCXOVFL NSC_EXT_BLOCK #_OF_NCS_EXT_BLK DCRXOVFL DCR_EXT_FC NO_DCR_EXT_BLKS REGNSEMO REGNSEMA NUM_REGNSEMA_EXT_BLOCKS IBNIXOVF IBN_INTL_XLA_EXT_BLOCK NUM_IBN_IXLA_EXT_BLOCKS LCOXOVFL LCO_EXTENSION_BLOCK NO_LOCAL_COIN_EXT_BLKS...
Page 362 7-24 SPMS PROVRES index descriptions Aggregate index FTREXT Aggregate index FTREXT (end) (continued) FTREXT contributors (continued) Extension block format Basic index Office parameters codes TCAPMXOV TC_AP_MEDIUM_EXT_BLK NO_OF_MEDIUM_EXT_BLKS PVNTRMXO PVN_TERM_EXT_BLK NO_OF_PVN_TERM_EXTBLK DMS250BO DMS250_BBF_EXT_BLK NO_OF_DMS250_BBF_EXT_BLK TPBXXOVF TPBX_EXTENSION NUM_TPBX_EXT_BLKS SCSXOVFL SCS_EXTENSION NUM_OF_SCS_EXTBLKS —end— All of the office parameters in this list are found in table OFCENG.
Page 363: Aggregate Index Billext
7-25 SPMS PROVRES index descriptions 7-25 7-25 Aggregate index BILLEXT Section EXTBLKS Description Billing extension Definition The summary of the level of utilization of extension block types used to contain billing data for various types of billing system. Diagnostics Review provisioning of the block types responsible for unfavorable results. The basic indices contributing to BILLEXT monitor peak usage of extension blocks used to carry data required by various billing or call detail recording systems.
Page 364 7-26 SPMS PROVRES index descriptions Aggregate index BILLEXT Aggregate index BILLEXT (end) (continued) BILLEXT contributors (continued) Extension block format Basic index Office parameters codes OCCROVFL OOCRU OOC_NUM_RU ICAMAROV ICAMA_RECORDING_UNIT NUM_ICAMMA_RECORDING_UNITS SORUOVFL SO_RECORD_UNIT KSAMA_NO_OFRU_FOR_SO ITOPSROV ITOPSRU TOPS_NUM_RU DMS250EX EOPS_RECORDING_UNIT NUM_OF_EOPS_REC_UNITS CDRMTXOV MTX_RECORDING_UNIT MTX_CDR_RU_COUNT RU250XOV...
Page 365: Aggregate Index Srvctres
7-27 SPMS PROVRES index descriptions 7-27 7-27 Aggregate index SRVCTRES Section SRVCTRES Description Service circuit resources Definition The summary of the traffic status of service circuits. Diagnostics Review provisioning of the circuits responsible for unfavorable results. Consult the underlying OM group for more precise location of the source of the overflows.
Page 366: Basic Index Annovfl
7-28 7-28 SPMS PROVRES index descriptions 7-28 Basic index ANNOVFL Section SRVCTRES Description Announcements overflow Definition The number of failed attempts to connect to announcements, because the maximum permitted number of calls are already connected. Measurement list ANNOVFL uses measurement ANN ANNOVFL, summed over all announcement types.
Page 367: Basic Index Stnovfl
7-29 SPMS PROVRES index descriptions 7-29 7-29 Basic index STNOVFL Section SRVCTRES Description Special tones overflow Definition The number of failed attempts to connect to special tones, because the maximum permitted number of calls are already connected. DMS-100G Switch does not contribute to or provide an equivalent of OM group STN.
Page 368: Basic Index Utrovfl
7-30 7-30 SPMS PROVRES index descriptions 7-30 Basic index UTROVFL Section SRVCTRES Description Universal tone receiver overflow Definition The number of failed attempts to connect to UTRs, either because the UTR queue is full in a given PM, or because the call abandons while waiting for service.
Page 369: Basic Index Esupovfl
7-31 SPMS PROVRES index descriptions 7-31 7-31 Basic index ESUPOVFL Section SRVCTRES Description Echo suppression overflow Definition The number of failed attempts to connect to digital echo suppressors, because no idle circuit was available. DMS-100G Switch does not contribute to or provide an equivalent of OM group ESUP.
Page 370: Basic Index Spsvovfl
7-32 7-32 SPMS PROVRES index descriptions 7-32 Basic index SPSVOVFL Section SRVCTRES Description Special service overflow Definition The number of failed attempts to connect to DTMF senders, MFC R2 inter-register signaling circuits, and service observing circuits because no idle circuit was available. DMS-100G Switch does not contribute to or provide an equivalent of OM group SVCT.
Page 371: Aggregate Index Confres
7-33 SPMS PROVRES index descriptions 7-33 7-33 Aggregate index CONFRES Section SRVCTRES Description Conference resources Definition The summary of the traffic status of three- and six-port conference circuits. Diagnostics Review provisioning of the circuits responsible for unfavorable results. DMS-100 Family Switch Performance Monitoring System Application Guide BASE09 and up...
Page 372: Basic Index Conf3Ovf
7-34 7-34 SPMS PROVRES index descriptions 7-34 Basic index CONF3OVF Section SRVCTRES Description Three-port conference circuit overflow Definition The rate of overflow of requests for three-port conference circuits. Measurement list CONF3OVF uses measurement CF3P CNFOVFL. In TOPS offices, it uses the sum of CF3P measurements CNFOVFLT and TOPSOVFL.
Page 373: Basic Index Conf6Ovf
7-35 SPMS PROVRES index descriptions 7-35 7-35 Basic index CONF6OVF Section SRVCTRES Description Six-port conference circuit overflow Definition The rate of overflow of requests for six-port conference circuits. Measurement list CONF6OVF uses the sum of CF6P measurement CF6OVFL. Normalizer CONF6OVF is normalized by the sum of this measurement plus CF6SZRS. Diagnostics Review provisioning of six-port conference circuits.
Page 374: Aggregate Index Rcvres
7-36 7-36 SPMS PROVRES index descriptions 7-36 Aggregate index RCVRES Section SRVCTRES Description Receiver resources Definition The summary of the traffic status of all types of receivers. Aggregate index RCVRES is not applicable to DMS-100G switches. Diagnostics Review provisioning of the circuits responsible for unfavorable results. RCVMFOV, RCVRDGOV, RCVRATDO, RCVRCNOV, RCVRMCSO, RCVRCDCO, MF300OVF, and DGT300OV monitor those requests for MF, Digitone, audio tone detector, coin tone detector, mechanized calling card...
Page 375 7-37 SPMS MTCEPERF index descroptions 7-37 7-37 Basic index RVCRMFOV Basic index RVCRMFOV (continued) (continued) Section RCVRES Description MF receivers overflows Definition The number of overflow attempts to connect a MF receiver. Measurement RVCRMFOV uses measurement RCVR RCVOVFL for RCVRMF Normalizer RCVRMFOV is normalized by the the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVRSZRS, and RCVSZ2.
Page 376 7-38 7-38 SPMS MTCEPERF index descroptions 7-38 Basic index RCVRDGOV Basic index RCVRDGOV (continued) (continued) Section RCVRES Description Digitone receiver overflows Definition The number of overflow attempts to connect Digitone revivers. Measurement RCVRDGOV uses measurement RCVR RCVOVFL for RCVRDGT. Normalizer RCVRDGOV is normalized by the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVSZRS, and RCVSZ2.
Page 377 7-39 SPMS MTCEPERF index descroptions 7-39 7-39 Basic index RCVRATDO Basic index RCVRATDO (continued) (continued) Section RCVERS Description Automatic tone detector overflows Definition The number of overflow attempts to connect automatic tone detectors. Measurement RCVRATDO uses measurement RCVR RCVROVFL for RCVRATD. Normalizer RCVRATDO is normalized by the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVRSZRS, and RCVSZ2.
Page 378 7-40 7-40 SPMS MTCEPERF index descriptions 7-40 Basic index RCVRMCSO Basic index RCVRMCSO (continued) (continued) Section RCVRES Description MCCS receiver overflows Definition The number of attempts to connect MCCS receivers. Measurement RCVRMCSO uses measurement RCVR RCVOVFL for RCVRMCCS. Normalizer RCVRMCSO is normalized by the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVSZRS, and RCVSZ2.
Page 379 7-41 SPMS MTCEPERF index descriptions 7-41 7-41 Basic index DGT300OV Basic index DGT300OV (continued) (continued) Section RCVRES Description DMS Digitone receiver overflows Definition The number of overflow attempts to connect DMS-300 Digitone receivers. Measurement DGT300OV uses measurement RCVR RCVOVFL for DGT300. Normalizer DGT300OV is normalized by the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVSZRS, and RCVSZ2.
Page 380 7-42 7-42 SPMS MTCEPERF index descriptions 7-42 Basic index MF300OVF Basic index MF300OVF (continued) (continued) Section RCVRES Description DMS-300 MF receiver overflows Definition The number of overflow attempts to connect DMS-300 MF receivers. Measurement DGT300OVF uses measurement RCVR RCVOVFL for MF300. Normalizer DGT300OVF is normalized by the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVSZRS, and RCVSZ2.
Page 381 7-43 SPMS MTCEPERF index descriptions 7-43 7-43 Basic index RCVRCDCO Basic index RCVRCDCO (continued) (continued) Section RCVRES Description CDC tone receiver overflows Definition The number of overflow attempts to connect CDC tone receivers. Measurement RCVRCDCO uses measurement RCVR RCVOVFL for RCVRCDC. Normalizer RCVRCDCO is normalized by the sum of measurements RCVR RCVRQOVFL, RCVRAQBN, RCVSZRS, and RCVSZ2.
Page 382: Aggregate Index Chanres
7-44 7-44 SPMS PROVRES index descriptions 7-44 Aggregate index CHANRES Section CHANRES Description Speech link status Definition The summary of the traffic status of speech links within the switch. Diagnostics Examine the basic indices to locate the source of unfavorable results. Review the MTCEPERF indices under NMLNKPF and PMLNKPF to determine if blocking was associated with maintenance problems.
Page 383: Basic Index Netchovf
7-45 SPMS PROVRES index descriptions 7-45 7-45 Basic index NETCHOVF Section CHANRES Description Network path overflow Definition The proportion of blocked attempts to connect a network path to a line or trunk. For DMS-100G Switch basic index NETCHOVF reflects line traffic only. Measurement list NETCHOVF uses OFZ measurements OUTMFL and OUTRMFL plus TRMMFL less PM channel blockages TRMBLK.
Page 384: Basic Index Lpmchan
7-46 7-46 SPMS PROVRES index descriptions 7-46 Basic index LPMCHAN Section CHANRES Description Line/peripheral module connect attempts Definition The proportion of attempts to connect a PM speech path to or from a line that is blocked. This index is a sort of average of the blocking rates measured by TRAFFIC indices ORGPMBLK and TRMPMBLK.
Page 385: The Relationships Of Oms To Spms
The relationships of OMs to SPMS Multiple tuple OM groups used in SPMS Table 8-1 contains OM groups that are used to generate SPMS indices. Because they have multiple tuples, which can provide more detailed information than SPMS, their contents should be saved for reference for at least 18 hours, and preferably longer, when SPMS reveals a problem.
Page 386 8-2 The relationsheps of OMs to SPMS Table 8-1 OM group usage (multiple tuples) (continued) OM group Registers C7LINK1 C7LKFAIL, C7LKUNAU, C7NETCON, C7SLTFL, C7STALFL, C7TLALFL C7LINK2 C7MSUDC1, C7MSUDC2, C7MSUDC3, C7MSUDSC C7LKSET C7SUNAU C7ROUTE C7FRCRER, C7RTUNAU C7RTESET C7RSCNGU, C7RSUNAU CMC or MS DS1CARR or PCMCARR DTSR...
Page 387: Other Om Groups Used In Spms
The relationsheps of OMs to SPMS 8-3 Other OM groups used in SPMS Table 8-2 contains OM groups that have just a single tuple. They offer little more detail than SPMS itself. It may still be worth retaining them in the same OM classes as the groups listed in table 8-1, to provide the additional perspective of absolute counts.
Page 388 8-4 The relationsheps of OMs to SPMS Table 8- OM group usage (single tuple) (continued) OM group Registers ISUPCONN ISCONCOT, ISCONUCA, ISCONUCC, ISCONUCE, ISCONUCF LOGS MTRPERF OFZ or OTS All (Failure counts especially. Call counts for base.) OFZ2 or SOTS ONISBU, ONIMBU SYSPERF TOPSMTCE...
Page 389: How Spms Index Values Are Calculated
How SPMS index values are calculated SPMS calculates switch performance by using two kinds of index: basic and aggregate. Basic indices A basic index consists of an operational measurement (OM) and a weighting factor. The factor is a calculation that uses constants derived from field results for a broad sample of offices so that index results are relative to this sample.
Page 390 9-2 How SPMS index values are calculated The value R is converted into an index with the help of a curve defined by five points. The curve consists of straight line segments joining these points. The points are as follows in table 9-1 and the curve in figure 9-1. Note: The SPMS R95 and R80 values may be changed at any BCS to represent the correct network performance as seen in the field.
Page 391: Calculating Aggregate Indices
How SPMS index values are calculated 9-3 Figure 9-1xxx Curve of R values SPMS index corresponding to R 2xR80 4xR80 Scaled Normalized Ratio Calculating aggregate indices Aggregate indices are summaries of their component basic indices. SPMS output gives the relative weight that is applied to each basic index under the heading WT.
Page 392 9-4 How SPMS index values are calculated The weighted average is a fraction. The top of the fraction is equal to the sum of the basic index values multiplied by their weights. The bottom of the fraction is simply the sum of the weights alone. In calculating an aggregate index, any basic index is ignored if it displays an NA instead of a numerical value.
Page 393: List Of Terms
10-1 List of terms AOSS See auxiliary operator services system. auxiliary operator services system (AOSS) A service-related system in which operators provide subscribers with such services as directory assistance (local and long distance) and call intercept. CCS7 See Common Channel Signaling No. 7. Common Channel Signaling No.
Page 394 10-2 List of terms failure rate The rate per working unit per unit time at which persistent malfunctions of equipment occur. Failure rate is the reciprocal of mean time between failures (MTBF). integrated services line module (ISLM) A line concentrating module that supports ISDN line cards. The ISLM works in association with the ISDN access controller.
Page 395 List of terms 10-3 link peripheral processor (LPP) The DMS SuperNode equipment frame for DMS-STP that contains two types of peripheral modules: a LIM and an LIU. For DMS-STP applications, CCS7 link interface units 7 (LIU7) are used in the LPP. See link interface unit.
Page 396 10-4 List of terms signaling connection control part (SCCP) A level of CCS7 layered protocol. It supports advanced services such as E800/SSP service and the Automatic Calling Card Service feature. The main functions of the SCCP include the transfer of signaling units with or without the use of a logical signaling connection and the provisioning of flexible global title translations for different applications.
Page 397 List of terms 10-5 total incoming attempts The total number of call attempts on the office incoming from trunks or operator positions, from the point of view of the central controller (CC). This is the sum of: OFZ NIN (with NIN2) TOPSTRAF TOPSNIN (with TOPSNIN2) minus TOPSCAN in TOPS offices...
Page 399 11-1 Index C7ROUTE 6-219 C7RTDEGR 6-220 ACCSTXOV 7-23 C7RTOUT 6-221 AMADEVFL 6-109 C7RTPERF 6-218 ANNOVFL 7-28 C7RTSET 6-222 ANNSTNPF 6-175 C7RTSTCO 6-223 AOPSPERF 6-191 C7RTSTOU 6-224 AOSSPERF 6-185 C7SCCPMP 5-29 AOSSPFLT 6-186 C7TRKCFL 6-212 AOSSPOUT 6-187 CARRERR 6-214 AOSSRUOV 7-25 CARRFLT 6-215 APMPF 6-57 CARRMOUT 6-217...
Page 400 11-2 Index CMCLNKPF 6-111 CMCPERF 6-9 E800TCXO 7-23 CMCUMOUT 6-13 ECCBOVFL 7-12 CMCUSOUT 6-12 EIOCERR 6-20 CMERRINT 6-30 EIOCFLT 6-21 CMFLT 6-31 EIOCPERF 6-19 CMNOSYNC 6-32 EIOCUMOU 6-23 CMPERF 6-29 EIOCUSOU 6-22 CNF3PERF 6-173 ENETERR 6-44 CNF6PERF 6-174 ENETFLT 6-45 CONF3OVF 7-34 ENETMOUT 6-47 CONF6OVF 7-35...
Page 401 Index 11-3 ICTFRMXO 7-23 MF300OVF 7-42 ICWTOVFL 5-41 MISCBLK 5-35 IFDLOVFL 5-42 MISCDNY 5-34 INSIGFL 5-10 MISCFL 5-13 INTEGFL 5-26 MSCDERR 6-39 INTFEATR 5-39 MSCDFLT 6-40 INTLCCMO 7-26 MSCDMOUT 6-42 INTLROVF 7-25 MSCDPERF 6-38 INTRKMOU 6-209 MSCDSOUT 6-41 INTRKSOU 6-208 MSERR 6-34 IOCERR 6-15 MSFLT 6-35...
Page 402 11-4 Index NMLNKPF 6-124 NMMSGLER 6-126 RCVRATDO 7-39 NMMSGLFL 6-127 RCVRCDCO 7-43 NMMSGLPF 6-125 RCVRDGOV 7-38 NMPTMOUT 6-132 RCVRES 7-36 NMPTSOUT 6-131 RCVRMCSO 7-40 NMSPCHER 6-129 RCVRPERF 6-177 NMSPCHFL 6-130 RDBXFMTO 7-23 NMSPCHPF 6-128 REGNSEMO 7-23 NONCPTRP 6-101 RNGFL 5-21 NSCXOVFL 7-23 ROTLPXOV 7-22 NSGRUOVF 7-25...
Page 403 Index 11-5 TMUSOUT 6-69 TOPSPERF 6-180 VIRTCFL 6-183 TOPSRUOV 7-25 VPSCFLT 6-194 TPBXXOVF 7-24 VSNFLT 6-192 TPOSFLT 6-181 VSNLKFLT 6-193 TPOSOUT 6-182 TRAPS 6-100 TRKFLT 6-207 TRKPERF 6-206 WADEOVFL 7-11 TRKPROV 5-36 TRMPMBLK 5-18 TWCXOVFL 7-22 XPMERR 6-77 XPMFLT 6-78 XPMPERF 6-76 UTROVFL 7-30 XPMUMOUT 6-80...
Page 406 DMS-100 Family Switch Performance Monitoring System Application Guide Product Documentation—Dept 3423 Northern Telecom P.O. Box 13010 RTP, NC 27709–3010 1–800–684–2273 (1–800–NTI–CARE) 1989, 1990, 1991, 1992, 1993, 1995, 1996, 1997, 1998 Northern Telecom All rights reserved NORTHERN TELECOM CONFIDENTIAL: information contained in this document is the property of Northern Telecom.

Nortel DMS-100 Series Application Manual

Quick Links

Related Manuals for Nortel DMS-100 Series

Summary of Contents for Nortel DMS-100 Series
