Summary of Contents for Innova CanOBD2&1

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION WHAT IS OBD? ....................... YOU CAN DO IT! ....................... SAFETY PRECAUTIONS SAFETY FIRST! ...................... ABOUT THE CANOBD2&1 SCAN TOOL BATTERY INSTALLATION / REPLACEMENT ............ADJUSTMENTS/SETTINGS AND DTC LIBRARY ..........CANOBD2&1 SCAN TOOL CONTROLS CONTROLS AND INDICATORS ................DISPLAY FUNCTIONS ...................

  • Page 3: Introduction

    Introduction WHAT IS OBD? WHAT IS OBD? The Enhanced CanOBD2&1 Scan Tool is designed to work on most Chrysler, Ford, GM and Toyota OBD1 systems and all OBD2 compliant vehicles. One of the most exciting improvements in the automobile industry was the addition of on- board diagnostics (OBD) on vehicles, or in more basic terms, the computer that activates the vehicle’s “CHECK ENGINE”...

  • Page 4: You Can Do It

    You Can Do It! EASY TO USE – EASY TO VIEW – EASY TO DEFINE Easy To Use ..Connect the CanOBD2&1 Scan Tool to the vehicle’s test connector. Turn the ignition key "On.” Press the POWER/LINK button.

  • Page 5: Safety Precautions

    Safety Precautions SAFETY FIRST! SAFETY FIRST! To avoid personal injury, instrument damage and/or damage to your vehicle; do not use the CanOBD2&1 Scan Tool before reading this manual. This manual describes common test procedures used by experienced service technicians. Many test procedures require precautions to avoid accidents that can result in personal injury, and/or damage to your vehicle or test equipment.
  • Page 6 Safety Precautions SAFETY FIRST! To prevent damage to the on-board computer when taking vehicle electrical measurements, always use a digital multimeter with at least 10 MegOhms of impedance. Fuel and battery vapors are highly flammable. To prevent an explosion, keep all sparks, heated items and open flames away from the battery and fuel / fuel vapors.

  • Page 7: About The Canobd2&1 Scan Tool

    About the CanOBD2&1 Scan Tool BATTERY INSTALL/REPLACEMENT - ADJUSTMENTS/SETTINGS & DTC LIBRARY BATTERY INSTALLATION / REPLACEMENT Replace batteries when the battery symbol is visible on display and/or the 3 LEDS are all lit and no other data is visible on screen. 1.
  • Page 8 About the CanOBD2&1 Scan Tool ADJUSTMENTS/SETTINGS AND DTC LIBRARY Adjustments and settings can be made only when the CanOBD2&1 Scan Tool is NOT connected to a vehicle. To enter the MENU Mode: 1. With the CanOBD2&1 Scan Tool OFF, press and hold the UP button, then press and release the POWER/LINK button.
  • Page 9 About the CanOBD2&1 Scan Tool ADJUSTMENTS/SETTINGS AND DTC LIBRARY 2. Press the UP or DOWN button, as necessary, to select the desired backlight mode, either ON or OFF. 3. When the desired backlight mode is selected, press the ENTER/LD button to save your changes. The display returns to the MENU, and the backlight turns “on”...
  • Page 10 About the CanOBD2&1 Scan Tool ADJUSTMENTS/SETTINGS AND DTC LIBRARY - The “Select Manufacturer” screen displays. - Use the UP and DOWN buttons, necessary, highlight appropriate manufacturer, then press the ENTER/LD button to display the correct DTC for your vehicle. If a definition for the DTC you entered available, advisory message shows on the...
  • Page 11 About the CanOBD2&1 Scan Tool ADJUSTMENTS/SETTINGS AND DTC LIBRARY 2. Press the UP or DOWN button, as necessary, to highlight the desired Unit of Measure. 3. When the desired Unit of Measure value is selected, press the ENTER/LD button to save your changes and return to the Setup Menu.

  • Page 12: Canobd2&1 Scan Tool Controls

    CanOBD2&1 Scan Tool Controls CONTROLS AND INDICATORS CONTROLS AND INDICATORS Figure 1. Controls and Indicators See Figure 1 for the locations of items 1 through 16, below. ERASE button - Erases Diagnostic Trouble Codes (DTCs), and “Freeze Frame” data from your vehicle’s computer, and resets Monitor status.
  • Page 13 CanOBD2&1 Scan Tool Controls CONTROLS AND INDICATORS ENTER/LIVE DATA button - When in MENU mode, confirms the selected option or value. When linked to a vehicle, places the CanOBD2&1 Scan Tool in "Live Data" mode. DOWN button - When in MENU mode, scrolls DOWN through the menu and submenu selection options.

  • Page 14: Display Functions

    CanOBD2&1 Scan Tool Controls DISPLAY FUNCTIONS DISPLAY FUNCTIONS 11 12 13 Figure 2. Display Functions See Figure 2 for the locations of items 1 through 16, following. 1. I/M MONITOR STATUS field - Identifies the I/M Monitor status area. (This function is applicable to OBD2 systems only.) 2.

  • Page 15: Viewing Dtcs In The Canobd2&1 Scan Tool'smemory

    CanOBD2&1 Scan Tool Controls VIEWING DTCs IN THE CANOBD2&1 SCAN TOOL’S MEMORY 7. DTC Display Area - Displays the Diagnostic Trouble Code (DTC) number. Each fault is assigned a code number that is specific to that fault. 8. Test Data Display Area - Displays DTC definitions, Freeze Frame data, and other pertinent test information messages.
  • Page 16 CanOBD2&1 Scan Tool Controls VIEWING DTCs IN THE CANOBD2&1 SCAN TOOL’S MEMORY 2. Press the ENTER/LD button. The “Select OBD System” screen displays. 3. Use the keys to highlight and select your vehicle’s OBD system (OBD1 or OBD2). Press the ENTER/LD button to continue.

  • Page 17: Preparation For Testing

    Preparation for Testing PRELIMINARY VEHICLE DIAGNOSTIC WORKSHEET PRELIMINARY VEHICLE DIAGNOSTIC WORKSHEET The purpose of this form is to help you gather preliminary information on your vehicle before you retrieve codes. By having a complete account of your vehicle's current problem(s), you will be able to systematically pinpoint the problem(s) by comparing your answers to the fault codes you retrieve.
  • Page 18 Preparation for Testing PRELIMINARY VEHICLE DIAGNOSTIC WORKSHEET WHEN DID YOU FIRST NOTICE THE PROBLEM: Just Started Started Last Week Started Last Month Other: LIST ANY REPAIRS DONE IN THE PAST SIX MONTHS: PROBLEMS STARTING No symptoms Cranks, but will not start Will not crank Starts, but takes a long time...
  • Page 19 Preparation for Testing PRELIMINARY VEHICLE DIAGNOSTIC WORKSHEET AUTOMATIC TRANSMISSION PROBLEMS (if applicable) No symptoms Vehicle does not move when in gear Shifts too early or too late Jerks or bucks Changes gear incorrectly PROBLEM OCCURS Morning Afternoon Anytime ENGINE TEMPERATURE WHEN PROBLEM OCCURS Cold Warm DRIVING CONDITIONS WHEN PROBLEM OCCURS...

  • Page 20: Before You Begin

    Preparation for Testing BEFORE YOU BEGIN BEFORE YOU BEGIN The Enhanced CanOBD2&1 Scan Tool aids in monitoring electronic- and emissions-related faults in your vehicle and retrieving fault codes related to malfunctions in these systems. Mechanical prob- lems such as low oil level or damaged hoses, wiring or electrical connectors can cause poor engine performance and may also cause a fault code to set.

  • Page 21: Vehicle Service Manuals

    Preparation for Testing VEHICLE SERVICE MANUALS VEHICLE SERVICE MANUALS Always refer to the manufacturer’s service manual for your vehicle before performing any test or repair procedures. Contact your local car dealership, auto parts store or bookstore for availability of these manuals.

  • Page 22: General Code Retrieval Procedures

    General Code Retrieval Procedures OBD1 SYSTEMS / OBD2 SYSTEMS Procedures for Retrieving Diagnostic Trouble Codes from OBD1 systems are vehicle manufacturer specific. Each manufacturer uses their own procedure. Procedures for retrieving Diagnostic Trouble Codes from OBD2 systems are generic, and apply to all vehicles equipped with OBD2 systems. From the following list, select the procedure that applies to your vehicle’s OBD system, and proceed to appropriate section for detailed code retrieval procedures.

  • Page 23: Vehicles Covered

    OBD2 Systems VEHICLES COVERED VEHICLES COVERED The Enhanced CanOBD2&1 Scan Tool is designed to work on all OBD2 compliant vehicles. All 1996 and newer vehicles (cars and light trucks) sold in the United States are OBD2 compliant. Federal law requires that all 1996 and newer cars and light trucks sold in the United States must be OBD2 compliant;...

  • Page 24: Diagnostic Trouble Codes (Dtcs)

    OBD2 Systems DIAGNOSTIC TROUBLE CODES (DTCs) On some Asian and European vehicles the DLC is located behind the “ashtray” (the ashtray must be removed to access it) or on the far left corner of the dash. If the DLC cannot be located, consult the vehicle’s service manual for the location.
  • Page 25 OBD2 Systems DIAGNOSTIC TROUBLE CODES (DTCs) OBD2 DTC EXAMPLE P0201 - Injector Circuit Malfunction, Cylinder 1 P 0 2 0 1 Body Chassis Powertrain Network Generic Manufacturer Specific Generic Includes both Generic and Manufacturer Specific Codes Identifies the system where the problem is located: Fuel and Air Metering Fuel and Air Metering (injector circuit...

  • Page 26: Code Retrieval Procedure

    OBD2 Systems CODE RETRIEVAL PROCEDURE CODE RETRIEVAL PROCEDURE Retrieving and using Diagnostic Trouble Codes (DTCs) for troubleshooting vehicle operation is only one part of an overall diagnostic strategy. Never replace a part based only on the DTC definition. Each DTC has a set of testing procedures, instructions and flow charts that must be followed to confirm the location of the problem.
  • Page 27 OBD2 Systems CODE RETRIEVAL PROCEDURE If the unit does not power on automatically when connected to the vehicle’s DLC connector, it usually indicates there is no power present at the vehicle’s DLC connector. Check your fuse panel and replace any burned-out fuses. If replacing the fuse(s) does not correct the problem, consult your vehicle’s repair manual to identify the proper computer (PCM) fuse/circuit, and perform any necessary repairs before...
  • Page 28 OBD2 Systems CODE RETRIEVAL PROCEDURE The CanOBD2&1 Scan Tool will automatically re-link to the vehicle’s computer every 30 seconds to refresh the data being retrieved. When data is being refreshed, the message “One moment Auto – link in progress” is shown on the display. This action repeats as long as the CanOBD2&1 Scan...
  • Page 29 OBD2 Systems CODE RETRIEVAL PROCEDURE In the case of long code definitions, or when viewing Freeze Frame data, a small arrow is shown in the upper/lower right-hand corner of the code display area to indicate the presence of additional information. Use buttons, as necessary, to view the additional information.
  • Page 30 OBD2 Systems CODE RETRIEVAL PROCEDURE Red LED – Indicates there is a problem with one or more of the vehicle’s systems. The red LED is also used to indicate that DTC(s) present (displayed CanOBD2&1 Scan Tool’s screen). this case, Malfunction Indicator (Check Engine) lamp on the vehicle’s instrument panel will be illuminated.
  • Page 31 OBD2 Systems CODE RETRIEVAL PROCEDURE Each time the DTC SCROLL button is pressed and released, the CanOBD2&1 Scan Tool will scroll and display the next DTC in sequence until all DTCs in its memory have displayed. Freeze Frame Data (if available) will display after DTC #1. Whenever the Scroll function is used to view additional codes, the CanOBD2&1 Scan Tool’s communication link with the vehicle’s computer disconnects.

  • Page 32: Viewing Enhanced Dtcs

    OBD2 Systems VIEWING ENHANCED DTCs 12. Determine engine system(s) condition by viewing the CanOBD2&1 Scan Tool’s display for any retrieved Diagnostic Trouble Codes, code definitions, Freeze Frame data and interpreting the green, yellow and red LEDs. If DTC’s were retrieved and you are going to perform the repairs yourself, proceed by consulting the Vehicle’s Service Repair Manual for testing instructions, testing procedures, and flow charts related to retrieved code(s).
  • Page 33 OBD2 Systems VIEWING ENHANCED DTCs If a Manufacturer specific DTC was retrieved, and the manufacturer selected for the code was Chrysler, Jeep, Ford, Mazda, General Motors, Isuzu, Honda, Acura, Toyota or Lexus, a confirmation message displays. Press the ENTER/LD button to display the Enhanced menu selected vehicle...
  • Page 34 OBD2 Systems VIEWING ENHANCED DTCs A visible icon indicates that the CanOBD2&1 Scan Tool is being powered through the vehicle’s DLC connector. A visible icon indicates that the CanOBD2&1 Scan Tool is linked to (communicating with) the vehicle’s computer. The upper right hand corner of the display shows the number of the code currently being displayed, the total number of codes retrieved.
  • Page 35 OBD2 Systems VIEWING ENHANCED DTCs Ford/Mazda Enhanced DTCs Mazda Enhanced DTCs are available for Mazda-branded Ford vehicles only. When Ford/Mazda is selected from the Enhanced DTCs Main menu, the Ford/Mazda Enhanced menu displays. You may view DTCs for either the “Continuous Memory Test”, “KOEO (Key On Engine Off) Test” or “KOER (Key On Engine Running) Test.”...
  • Page 36 OBD2 Systems VIEWING ENHANCED DTCs I/M MONITOR STATUS icons are not displayed when viewing enhanced DTCs. In the case of long code definitions, or when viewing Freeze Frame data, a small arrow is shown in the upper/lower right-hand corner of the code display area to indicate the presence of additional information.
  • Page 37 OBD2 Systems VIEWING ENHANCED DTCs If the CanOBD2&1 Scan Tool fails to link to the vehicle’s computer, a “Linking Failed” message shows on the CanOBD2&1 Scan Tool’s display. - Verify the ignition is ON, then press the ENTER/LD button to continue. 2.
  • Page 38 OBD2 Systems VIEWING ENHANCED DTCs 4. When the last retrieved DTC has been displayed and the DTC SCROLL button is pressed, the CanOBD2&1 Scan Tool returns to the GM/Isuzu Enhanced menu. To view additional enhanced DTCs, repeat steps 1 through 4, above.
  • Page 39 OBD2 Systems VIEWING ENHANCED DTCs The Diagnostic Trouble Code (DTC) and related code definition are shown in the lower section of the LCD display. MONITOR STATUS icons are not displayed when viewing enhanced DTCs. In the case of long code definitions, or when viewing Freeze Frame data, a small arrow is shown in the upper/lower right-hand corner of the code display area to indicate the presence of additional information.
  • Page 40 OBD2 Systems VIEWING ENHANCED DTCs Current DTCs or History DTCs Current DTCs, Historical DTCs or Readiness DTCs 1. Use the UP and DOWN buttons, as necessary, to highlight the desired option, then press the ENTER/LD button. A “One moment please” message displays, while Scan...

  • Page 41: Erasing Diagnostic Trouble Codes (Dtcs)

    OBD2 Systems ERASING DIAGNOSTIC TROUBLE CODES (DTCs) The Scan Tool will display a code only if codes are present in the vehicle’s computer memory. If no codes are present, a “No Enhanced DTC’s are presently stored in the vehicle’s computer” is displayed. Press the ENTER/LD button to return...
  • Page 42 OBD2 Systems ERASING DIAGNOSTIC TROUBLE CODES (DTCs) The CanOBD2&1 Scan Tool must be connected to the vehicle’s DLC to erase the codes from the computer’s memory. If you press the ERASE button when the CanOBD2&1 Scan Tool is not connected to the vehicle’s DLC, the erase instruction screen displays.

  • Page 43: I/M Readiness Testing

    OBD2 Systems I/M READINESS TESTING Erasing DTCs does not fix the problem(s) that caused the code(s) to be set. If proper repairs to correct the problem that caused the code(s) to be set are not made, the code(s) will appear again (and the check engine light will illuminate) as soon as the vehicle is driven long enough for its Monitors to complete their testing.
  • Page 44 OBD2 Systems I/M READINESS TESTING Catalytic Converter, EGR Valve, Fuel System, etc.) to ensure their proper operation. Currently, there are a maximum of eleven Monitors available for use. Each Monitor has a specific function to test and diagnose only its designated emissions-related component or system.
  • Page 45 OBD2 Systems I/M READINESS TESTING 1. In most areas, one of the requirements that must be met before a vehicle is allowed to be Emissions Tested (Smog Checked) is that the vehicle does not have any Diagnostic Trouble Codes present (with the exception of PENDING Diagnostic Trouble Codes).
  • Page 46 OBD2 Systems I/M READINESS TESTING If the illumination of the Yellow LED is being caused by monitors that “have not run” their diagnostic testing, then the issue of the vehicle being ready for an Emissions Test (Smog Check) depends on the emissions regulations and laws of your local area.
  • Page 47 OBD2 Systems I/M READINESS TESTING 1. Using retrieved Diagnostic Trouble Codes (DTCs) and code definitions as a guide, and following manufacturer's repair procedures, repair the fault or faults as instructed. 2. After the fault or faults have been repaired, connect the CanOBD2&1 Scan Tool to the vehicle's DLC and erase the code or codes from the vehicle's computer memory.
  • Page 48 OBD2 Systems I/M READINESS TESTING system status information (open loop, closed loop, fuel system status, etc.) generated by the various vehicle sensors, switches and actuators. In effect the CanOBD2&1 Scan Tool lets you view, in "real time", the same signal values generated by the sensors, actuators, switches and/or vehicle system status information used by the vehicle's computer when calculating and conducting system adjustments and corrections.

  • Page 49: Obd2 Live Data Mode

    OBD2 Live Data Mode VIEWING LIVE DATA VIEWING LIVE DATA 1. Follow steps 1 through 7 of the CODE RETRIEVAL PROCEDURE (page 24) to place the CanOBD2&1 Scan Tool in "Code Retrieval" mode. 2. Press and release the ENTER/LD button to place the CanOBD2&1 Scan Tool in "Live Data"...

  • Page 50: Customizing Live Data (Pids)

    OBD2 Live Data Mode CUSTOMIZING LIVE DATA (PIDs) CUSTOMIZING LIVE DATA (PIDs) This feature lets you customize the CanOBD2&1 Scan Tool display to show only those PIDs that are of interest at the current time. You can customize the Live Data display by placing the CanOBD2&1 Scan Tool in "Custom Live Data"...

  • Page 51: Recording (Capturing) Live Data

    OBD2 Live Data Mode RECORDING (CAPTURING) LIVE DATA RECORDING (CAPTURING) LIVE DATA You can record and save several frames of Live Data information for each PID supported by the vehicle in the CanOBD2&1 Scan Tool's memory. Recorded Live Data can serve as valuable information to help you in the troubleshooting of vehicle problems.
  • Page 52 OBD2 Live Data Mode RECORDING (CAPTURING) LIVE DATA The CanOBD2&1 Scan Tool is capable of recording approximately 20 frames of Live Data. Record by DTC trigger lets you select the point in time at which you wish the CanOBD2&1 Scan Tool to begin recording Live Data. You can set the trigger point to record the 20 frames of data before an event (when the DTC sets), after the event, or in the middle (10 frames before and 10 frames after the...
  • Page 53 OBD2 Live Data Mode RECORDING (CAPTURING) LIVE DATA If Yes is selected, the CanOBD2&1 Scan Tool enters "Playback" mode from which you can view a frame-by-frame playback of recorded Live Data (see LIVE DATA PLAYBACK on page 53 for details). If No is selected, the display returns to the "Live Data View"...
  • Page 54 OBD2 Live Data Mode RECORDING (CAPTURING) LIVE DATA The CanOBD2&1 Scan Tool is capable of recording approximately 20 frames of Live Data. Record by DTC trigger lets you select the point in time at which you wish the CanOBD2&1 Scan Tool to begin recording Live Data. You can set the trigger point to record the 20 frames of data before an event (when the DTC was set), after the event, or in the middle (10 frames before and 10 frames after the event.

  • Page 55: Live Data Playback

    OBD2 Live Data Mode LIVE DATA PLAYBACK 9. You can exit the "Record Live Data Mode" at any time by pressing and holding the ENTER/LD button until the "Mode Selection Menu" displays. If desired, you can transfer the recorded Live Data information to a personal computer using the optional PC-LINK program (see instructions included with PC-Link for more information).
  • Page 56 OBD2 Live Data Mode LIVE DATA PLAYBACK 2. If the Code Reader is not connected to a vehicle: With the CanOBD2&1 Scan Tool not connected to a vehicle, press the POWER/LINK button. The “To Link” screen shows CanOBD2&1 Scan Tool’s display. Press the DOWN button for instructions...
  • Page 57 OBD2 Live Data Mode LIVE DATA PLAYBACK When recorded Live Data is played back, all available PIDs are shown, even if you have custom- ized the Live Data selections. If there is no Live Data currently stored in the CanOBD2&1 Scan Tool's memory, advisory...

  • Page 58: Generic (Global) Obd2 Pid List

    Generic (Global) OBD2 PID List The following is a list of Generic (Global) PIDs and their descriptions. Tool Display Unit Value PID Description ACC Pedal D XXX.X Accelerator Pedal Position D ACC Pedal E XXX.X Accelerator Pedal Position E ACC Pedal F XXX.X Accelerator Pedal Position F Air Status...
  • Page 59 Generic (Global) OBD2 PID List Tool Display Unit Value PID Description EQ Ratio 13 X.XXX Bank 1 - Sensor 3 Equivalence Ratio EQ Ratio 14 X.XXX Bank 1 - Sensor 4 Equivalence Ratio EQ Ratio 21 X.XXX Bank 2 - Sensor 1 Equivalence Ratio EQ Ratio 22 X.XXX...
  • Page 60 Generic (Global) OBD2 PID List Tool Display Unit Value PID Description XXX / Intake Manifold Absolute Pressure /PSI XX.X MIL On Time hrs, XXXX, XX Engine Run Time while MIL ON Monitor Status ICONS on Monitor Status this Driving Cycle Display O2S B1 S1 X.XXX...
  • Page 61 Generic (Global) OBD2 PID List Tool Display Unit Value PID Description O2S Location O2S14 Oxygen Sensor, Bank 1, Sensor 4 O2S Location O2S21 Oxygen Sensor, Bank 2, Sensor 1 O2S Location O2S22 Oxygen Sensor, Bank 2, Sensor 1 O2S Location O2S23 Oxygen Sensor, Bank 2, Sensor 3 O2S Location...
  • Page 62 Generic (Global) OBD2 PID List Tool Display Unit Value PID Description STFT B1 S2 XXX.X Bank 1 - Sensor 2 STFT B1 S3 XXX.X Bank 1 - Sensor 3 STFT B1 S4 XXX.X Bank 1 - Sensor 4 STFT B2 XXX.X Short Term Fuel Trim-Bank 2 STFT B2 S1...

  • Page 63: Additional Obd2 Tests

    Additional OBD2 Tests O2 SENSOR TEST In addition to retrieving Diagnostic Trouble Code (DTC) and viewing Live Data, you can use the Enhanced CanOBD2&1 Scan Tool to perform additional diagnostic tests, and to view diagnostic and vehicle information stored in your vehicle's on-board computer. Additional tests are accessed through the "Mode Selection Menu."...
  • Page 64 Additional OBD2 Tests O2 SENSOR TEST X or XX - These characters identify the location of the O2 sensor in relation to a cylinder bank. An O2 sensor for cylinder bank 1 is identified by the designation “1” or "B1"; a sensor for cylinder bank 2 is identified as “2”...

  • Page 65: Non-Continuous Test

    Additional OBD2 Tests NON-CONTINUOUS TEST 5. When you have finished viewing the retrieved test data, scroll to the end of the display to select Exit, then press the ENTER/LD button to return to the "Select Test" screen. NON-CONTINUOUS TEST The Non-Continuous Test function retrieves and displays test results for emission-related powertrain components and systems that are not continuously monitored.

  • Page 66: System Test

    Additional OBD2 Tests SYSTEM TEST Test ID number Module ID number Component ID number Min or Max test limit Only one test limit, either Min or Max, is shown for any given test. Test Value and status Status is calculated by the CanOBD2&1 Scan Tool by comparing the Test Value against the displayed test limit (either Min or Max).

  • Page 67: Vehicle Id

    Additional OBD2 Tests VEHICLE ID Some vehicle manufacturers do not allow CanOBD2&1 Scan Tools or other external devices to control vehicle systems. If the EVAP Leak Test is not supported by the vehicle under test, an advisory message shows on the CanOBD2&1 Scan Tool's display.
  • Page 68 Additional OBD2 Tests VEHICLE ID If the Vehicle ID function is not supported by the vehicle under test, an advisory message shows on the CanOBD2&1 Scan Tool's display. Press the ENTER/LD button to return to the Mode Selection menu. 2. Use the UP and DOWN buttons, as necessary, to highlight Vehicle ID,...
  • Page 69 Additional OBD2 Tests VEHICLE ID 2. Use the UP and DOWN buttons, as necessary, to highlight Available Modules, then press the ENTER/LD button. 3. A "One moment please..." message displays while the requested information is retrieved from the vehicle's computer. 4.

  • Page 70: Chrysler/Jeep Obd1 Systems

    Chrysler/Jeep OBD1 Systems CHRYSLER/JEEP OBD1 SYSTEMS CHRYSLER/JEEP OBD1 SYSTEMS Chrysler Motors On-Board Computer Systems Chrysler Motors introduced its first electronic fuel injected vehicle in late 1983. The on-board computer management systems used on Chrysler vehicles have evolved over the years, and their names have changed accordingly.

  • Page 71: Vehicles Covered

    Chrysler/Jeep OBD1 Systems VEHICLES COVERED / PANEL INDICATOR LIGHTS /DLC VEHICLES COVERED This section covers Chrysler fuel injected vehicles from 1983-1995. Model Type Year Model Passenger 1983-1995 Chrysler, Dodge and Plymouth Fuel Cars Injected Models Only (Excluding Laser/Talon 1.8L, 2.0L (ALL YEARS), 1990 Monaco/Premier, 1993-1995 Intrepid, LHS, Concorde and Vision, 1995 Avenger, Stealth (ALL YEARS) and Cirrus 2.5L (ALL...

  • Page 72: Code Retrieval Procedure

    Chrysler/Jeep OBD1 Systems CODE RETRIEVAL PROCEDURE CODE RETRIEVAL PROCEDURE Retrieving and using Diagnostic Trouble Codes (DTCs) for troubleshooting vehicle operation is only one part of an overall diagnostic strategy. Never replace a part based only on the DTC definition. Each DTC has a set of testing procedures, instructions and flow charts that must be followed to confirm the location of the problem.
  • Page 73 Chrysler/Jeep OBD1 Systems CODE RETRIEVAL PROCEDURE To retrieve DTCs from the vehicle selection currently in the CanOBD2&1 Scan Tool’s memory: - From “Current Selection/ Select Vehicle” screen, highlight Current Selection and press the ENTER/LD button. - Proceed to step 5 to continue. To retrieve DTCs from a new vehicle: - From...
  • Page 74 Chrysler/Jeep OBD1 Systems CODE RETRIEVAL PROCEDURE If the CanOBD2&1 Scan Tool fails to link to the vehicle’s computer, a “Vehicle is not responding” message shows on the CanOBD2&1 Scan Tool’s display. Do the following: - Verify the ignition is ON. - Check the cable connections at the CanOBD2&1 Scan Tool and at the vehicle’s DLC.
  • Page 75 Chrysler/Jeep OBD1 Systems CODE RETRIEVAL PROCEDURE 11. Follow the testing and repair procedures outlined in the vehicle's service repair manual to correct "hard" DTCs. Codes should be addressed and eliminated in the order they were received, erasing (see ERASING DTCs (OBD I SYSTEMS) on page 112) and retesting after each repair is made to be sure the fault was eliminated.

  • Page 76: Ford Obd1 Systems

    Ford OBD1 Systems FORD COMPUTER SYSTEM OVERVIEW - VEHICLES COVERED FORD COMPUTER SYSTEM OVERVIEW The Enhanced CanOBD2&1 Scan Tool is compatible only with EEC-IV Computer Control systems. IMPORTANT: When the computer is in Self-Test mode (is testing the sensors or actuators for proper operation), it relies on voltage signals that is sends to and / or receives from the sensors or actuators to determine whether or not these components are operating properly.
  • Page 77 Ford OBD1 Systems VEHICLES COVERED - CARS Fuel Systems 8th VIN (Carburetor Computer Engine Digit** Model) Application/Special Notes System 1984-1986 (Cont) 5.0L V-8 F, M CFI, SEFI Capri, Continental, Colony EEC-IV Park, Cougar, Country Squire, Crown Victoria, Grand Marquis, LTD, Mark VII, Marquis, Mustang, T-Bird, Town Car 1987-1993 1.9L I-4...
  • Page 78 Ford OBD1 Systems VEHICLES COVERED - TRUCKS Fuel Systems 8th VIN (Carburetor Computer Engine Digit** Model) Application/Special Notes System 1995 (Cont) 4.6L V8 Mark VIII EEC-IV DOHC 5.0L V-8 HO Mustang 5.0L V-8 SHP NOTES * Carburetor Model. Carburetor model numbers are usually stamped on top of the carburetor, or on a metal tab attached to the carburetor.

  • Page 79: Test Connectors

    Ford OBD1 Systems TEST CONNECTORS Fuel Systems 8th VIN (Carburetor Computer Engine Digit** Model) Application/Special Notes System 1991-1994 (Cont) 3.0L V-6 EFI, SEFI, SFI Aerostar, Ranger EEC-IV 4.0L V-6 EFI, MFI Aerostar, Explorer, Ranger 4.9L I-6 Y, H EFI, MFI, SFI Bronco, E and F Series Trucks/Vans (8500 lb.

  • Page 80: Connecting The Canobd2&1 Scan Tool

    Ford OBD1 Systems CONNECTING THE CANOBD2&1 SCAN TOOL - DIAGNOSTIC TROUBLE CODES Near the front corner (right or left). Near the fender well (right or left). Near the fire wall (right or left). CONNECTING THE CANOBD2&1 SCAN TOOL The CanOBD2&1 Scan Tool's Ford Connector Cable Adaptor is designed to match the vehicle's computer DLC.

  • Page 81: Code Retrieval Procedures

    Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - OVERVIEW - KOEO TEST Intermittent/History DTCs Intermittent/History DTCs are stored in the computer's memory for problems that occur intermittently, or for problems that happened in the past but are not currently present. Intermittent DTCs may cause the Malfunction Indicator light to flicker or stay on until the intermittent malfunction goes away.
  • Page 82 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - KOEO TEST The first group of codes retrieved by the CanOBD2&1 Scan Tool are called "KOEO codes". A "KOEO" icon will show in the upper right corner of the display to indicate that the code retrieved is a "KOEO" code.
  • Page 83 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - KOEO TEST For 7.3L diesel engines: Press and hold accelerator until all codes are sent (steps 7 through 9). For 2.3L turbo engines with octane switch: Put switch in premium position. 7. Press the ENTER/LD button to continue.
  • Page 84 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - KOEO TEST If no Continuous Memory codes are present in the vehicle's computer memory, the CanOBD2&1 Scan Tool will display a "PASS" code (code 11 or 111). Most Ford EEC-IV vehicle com- puters up to 1991 use a two-digit code system.
  • Page 85 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - ENGINE TIMING CHECK Do not proceed to the ignition timing check procedure or the KOER test until a PASS code (code 11 or 111) for KOEO test is obtained. Engine Timing Check Before performing the KOER Self-Test, the vehicle's Ignition Base Timing and the computer's ability to electronically control timing advance must be checked for proper operation.
  • Page 86 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - ENGINE TIMING CHECK The Ford EEC-IV System menu displays. Use the buttons, as necessary, make menu selections. 3. From the Ford EEC-IV System menu, highlight Timing Check, then press the ENTER/LD button. The Timing Check menu displays. 4.
  • Page 87 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - KOER TEST The vehicle's computer is pro- grammed to advance ignition timing 20° (±3°) above the vehicle's "base timing" value, and to freeze this setting for two minutes from the time the "Perform Timing Check within 2 minutes"...
  • Page 88 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - KOER TEST The vehicle must pass the Engine Timing Check (page 83) before performing this test. 1. Locate the vehicle's Data Link Connector (DLC). See Data Link Connector (DLC) on page 77 for connector location. Some DLCs have a plastic cover that must be removed before connecting the CanOBD2&1 Scan Tool cable connector.
  • Page 89 Ford OBD1 Systems CODE RETRIEVAL PROCEDURES - KOER TEST 8. Perform the following procedures when prompted by the message on the CanOBD2&1 Scan Tool's display. Turn the steering wheel 1/2 turn to right, hold for four seconds and release. Press the brake pedal to the floor and then release it. Cycle the Overdrive Switch (if equipped).

  • Page 90: Additional Tests For Eec-Iv Systems

    Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - CYLINDER BALANCE TEST See VIEWING DTCs IN THE CANOBD2&1 SCAN TOOL’S MEMORY on page 13 to view DTCs stored in the CanOBD2&1 Scan Tool's memory. All retrieved DTCs will remain in the CanOBD2&1 Scan Tool's memory.
  • Page 91 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - CYLINDER BALANCE TEST and at every engine revolution. On other systems the injectors fire in groups and/or at every other engine revolution. What distinguishes Sequential Electronic Fuel Injection systems from other multi-port fuel injection systems is that each injector is independently energized and fires sequentially one after the other in the proper firing order.
  • Page 92 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - CYLINDER BALANCE TEST 5. Turn off all vehicle accessories, then turn ignition key OFF and wait for the on screen prompt. If you wish to exit the Cylinder Balance test at this time, press the ENTER/LD button.
  • Page 93 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - RELAY AND SOLENOID TEST If the computer detects a problem with a cylinder(s) when performing the initial Cylinder Balance Test, it needs to repeat the test two more times to properly determine which cylinder or cylinders are malfunctioning.
  • Page 94 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - RELAY AND SOLENOID TEST 2. Connect the CanOBD2&1 Scan Tool cable (with the Ford Connector Cable Adaptor attached) to the CanOBD2&1 Scan Tool, then connect the adaptor to vehicle's DLC. Press POWER/LINK button to turn the CanOBD2&1 Scan Tool ON, then press...
  • Page 95 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - RELAY AND SOLENOID TEST If the CanOBD2&1 Scan Tool fails to link to the vehicle's computer, a "Vehicle is not responding" message shows on the CanOBD2&1 Scan Tool's display. Do the following: - Verify the ignition is ON.
  • Page 96 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - WIGGLE TEST Wiggle Test Since any DTC’s from Wiggle Test results are saved in Continuous Memory, it is suggested that you clear any DTC’s in Continuous Memory before performing Wiggle Test (see ERASING DTCs (OBD I SYSTEMS) on page 112 for proce- dures).
  • Page 97 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - WIGGLE TEST 6. Select the desired Wiggle Test from the menu displayed. To perform the KOEO Wiggle Test: - Highlight KOEO Wiggle Test. - Turn ignition ON. DO NOT start the engine. - Press the ENTER/LD button to continue.
  • Page 98 Ford OBD1 Systems ADDITIONAL TESTS FOR EEC-IV SYSTEMS - WIGGLE TEST If no faults are detected when per- forming the Wiggle Test, a "System Pass" message displays. If a fault is detected when per- forming the Wiggle Test, a "Circuit Fault detected"...

  • Page 99: Gm Obd1 Systems

    GM OBD1 Systems YOUR VEHICLE’S COMPUTER SYSTEM - VEHICLES COVERED YOUR VEHICLE'S COMPUTER SYSTEM Today's vehicles are equipped with computer self-testing abilities that can locate problems in your vehicle and store them as Diagnostic Trouble Codes (DTC's) in the vehicle's onboard computer. The Enhanced CanOBD2&1 Scan Tool allows you access to the computer's memory and retrieves the DTC's.

  • Page 100: About The Canobd2&1 Scan Tool

    GM OBD1 Systems ABOUT THE CANOBD2&1 SCAN TOOL - DLC – MIL - DTCs Model Year Make Model 1995 Chevrolet Caprice 4.3 liter Trucks and All one ton capacity or less with gas engines Vans (EXCEPT S/T Series vehicles) In addition to the above list, the CanOBD2&1 Scan Tool IS ALSO COMPATIBLE with OBD1 GM models that are equipped with "Climate Control Computers".

  • Page 101: Code Retrieval Procedure

    GM OBD1 Systems CODE RETRIEVAL PROCEDURE "Hard" Diagnostic Trouble Codes "Hard" DTCs represent problems that are occurring now and cause the instrument panel Malfunction Indicator Lamp (MIL) or Check Engine light to illuminate and remain on until the failure is repaired. A DTC is stored in the vehicle's computer memory for each fault detected.
  • Page 102 GM OBD1 Systems CODE RETRIEVAL PROCEDURE 3. Select the model year of the vehicle from which you wish to retrieve codes: If a previous vehicle selection is currently saved in the CanOBD2&1 Scan Tool's memory, "Current Selection/Select New Vehicle" menu displays. If no previous vehicle selection is stored in the CanOBD2&1 Scan Tool's memory, "Select Vehicle Year"...
  • Page 103 GM OBD1 Systems CODE RETRIEVAL PROCEDURE If the year shown is not correct, highlight Select New Vehicle and press the ENTER/LD button to return to the “Select Vehicle Year” menu to make your corrections. 4. When the CanOBD2&1 Scan Tool is in the process of retrieving codes, a "One moment please..."...
  • Page 104 GM OBD1 Systems CODE RETRIEVAL PROCEDURE 7. Disconnect the CanOBD2&1 Scan Tool from the vehicle and turn the ignition key OFF. 8. To prolong battery life, the CanOBD2&1 Scan Tool automatically shuts "Off" after approximately three minutes with no button activity. The DTCs retrieved will remain in the CanOBD2&1 Scan Tool's memory, and may be viewed at any time.

  • Page 105: Toyota/Lexus Obd1 Systems

    Toyota/Lexus OBD1 Systems ON-BOARD VEHICLE DIAGNOSTICS (OBD1) - VEHICLES COVERED ON-BOARD VEHICLE DIAGNOSTICS (OBD1) Beginning in 1988, California's Air Resources Board (CARB), and later, the Federal Government's Environmental Protection Agency (EPA), required vehicle manufacturers to include a self diagnostic program capable of identifying an emissions-related fault via the vehicles On-Board Computers (some manufacturers used OBD before it was required).
  • Page 106 Toyota/Lexus OBD1 Systems VEHICLES COVERED Eng. Eng. DOHC/ Year Model Size Code SOHC Other Type 1992 Celica 2.2L 5S-FE DOHC Convertible 1992 Celica Coupe 1.6L 4A-FE DOHC 1992 Celica Coupe 2.2L 5S-FE DOHC 1993 Celica Coupe 1.6L 4A-FE DOHC 1995 Celica Coupe 1.8L 7A-FE...
  • Page 107 Toyota/Lexus OBD1 Systems VEHICLES COVERED DOHC/ Eng. Eng. Year Model Size Code SOHC Other Type 1993 Supra 3.0L 2JZ-GTE DOHC Turbo 1993 Supra 3.0L 2JZ-GE DOHC 1994 Camry 3.0L 3VZ-FE DOHC 1994 Supra 3.0L 2JZ-GTE DOHC Turbo 1994 Supra 3.0L 2JZ-GE DOHC 1995...

  • Page 108: Data Link Connector (Dlc)

    Toyota/Lexus OBD1 Systems DATA LINK CONNECTOR (DLC) / MIL DATA LINK CONNECTOR (DLC) Toyota vehicles are equipped with special Test Connectors that make it possible to connect specialized testing equipment that communicates with the vehicle's onboard computer. The CanOBD2&1 Scan Tool is designed for use with two types of Toyota DLC connectors;...

  • Page 109: Diagnostic Trouble Codes

    Toyota/Lexus OBD1 Systems DIAGNOSTIC TROUBLE CODES / CODE RETRIEVAL PROCEDURE If your instrument panel indicator lights do not come on when you turn on the ignition, please refer to your vehicle's service manual. You may have problems in the car's circuitry. It is recommended that you fix these problems before retrieving DTCs from your vehicle’s computer.
  • Page 110 Toyota/Lexus OBD1 Systems CODE RETRIEVAL PROCEDURE 1. Locate the vehicle's Data Link Connector (DLC). See Data Link Connector (DLC) on page 106 for connection location. Some DLCs have a plastic cover that must be removed before connecting the CanOBD2&1 Scan Tool's cable connector. 2.
  • Page 111 Toyota/Lexus OBD1 Systems CODE RETRIEVAL PROCEDURE 7. If the CanOBD2&1 Scan Tool was able to link to the vehicle successfully a "Code retrieval successful..." message shows temporarily on the CanOBD2&1 Scan Tool’s display followed by any retrieved DTCs. The CanOBD2&1 Scan Tool will display a code only if codes are present in the vehicle's computer memory.

  • Page 112: Servicing Dtcs

    Servicing DTCs OBD1 SYSTEMS SERVICING DTCs - OBD I Retrieving and using Diagnostic Trouble Codes (DTCs) for troubleshooting vehicle operation is only one part of an overall diagnostic strategy. Never replace a part based only on the DTC definition. Each DTC has a set of testing procedures, instructions and flow charts that must be followed to confirm the location of the problem.
  • Page 113 Servicing DTCs OBD1 SYSTEMS 4. Red LED - Indicates there is a problem with one or more of the vehicle's systems. The red LED is also used to indicate that DTC(s) present (displayed on the CanOBD2&1 Scan Tool's screen). In this case, the MIL or Check Engine light on the vehicle's instrument panel will be illuminated.

  • Page 114: Erasing Dtcs (Obd I Systems)

    Erasing DTCs OBD1 SYSTEMS ERASING DTCs (OBD I SYSTEMS) When the CanOBD2&1 Scan Tool's ERASE function is used to erase DTCs from the vehicle's on-board computer, manufacturer specific data (where applicable) is also erased. If you plan to take the vehicle to a service center for repair, DO NOT erase the codes from the vehicle's computer.
  • Page 115 Erasing DTCs OBD1 SYSTEMS If the erase was not successful, an advisory message shows on the CanOBD2&1 Scan Tool’s display. Verify that the CanOBD2&1 Scan Tool is properly connected to the vehicle's DLC and that the ignition is ON. If the erase process still does not complete, turn the ignition OFF, wait 10 seconds, then turn back ON and repeat steps 2 and 3.

  • Page 116: Glossary

    Glossary GLOSSARY OF TERMS AND ABBREVIATIONS GLOSSARY OF TERMS AND ABBREVIATIONS CARB – California Air Resources Board CCM – Central Control Module Computer Control System – An electronic control system, consisting of an on-board computer and related sensors, switches and actuators, used to ensure peak performance and fuel efficiency while reducing pollutants in the vehicle’s emissions.
  • Page 117 Glossary GLOSSARY OF TERMS AND ABBREVIATIONS OBD2 – On-Board Diagnostics Version 2 (also referred to as “OBD II”) On-Board Computer – The central processing unit in the vehicle’s computer control system. PCM – Powertrain Control Module Pending Code – A code recorded on the “first trip” for a “two-trip” code. If the fault that caused the code to be set is not detected on the second trip, the code is automatically erased.
  • Page 118 Notes CanOBD2&1...

  • Page 119: Warranty And Servicing

    UPDATES and OPTIONAL ACCESSORIES, please contact your local store, distributor or the Service Center. USA & Canada: (800) 544-4124 (6:00 AM-6:00 PM, 7 days a week PST) All others: (714) 241-6802 (6:00 AM-6:00 PM, 7 days a week PST) FAX: (714) 432-3979 (24 hr.) Web: www.innova.com CanOBD2&1...
