12.3 Factory settings
Parameter
Response values/alarms
Measurement profile
Response value R
an1
Response value R
an2
Fault memory
Coupling monitoring
Switching elements
Relay 1 (11, 12, 14)
Relay 2 (21, 22, 24)
Relay 3 (31, 32, 34)
Insulation fault location
(isoxx1685DP only)
EDS mode
PGH current
BMS
BMS address
BMS termination
Digital inputs
Digital input 1
Digital input 2
Other
Standby mode (disconnection from the
mains)
Permissible system leakage capacitance
Buzzer
Menu language
Password query
Password
80
(ALARM 1)
(ALARM 2)
Value
Power circuits
40 kΩ
4 kΩ for isoLR1685DP-325
10 kΩ
1 kΩ for isoLR1685DP-325
off
on
Operating mode: N/C operation
Function: Insulation measurement
Operating mode: N/C operation
Function: Insulation measurement
Operating mode: N/C operation
Function: Insulation measurement
auto
25 mA
2
ON
Operating mode: active high
Function: TEST
Operating mode: active high
Function: STANDBY
for isoHR1685D-925: "Initial measurement"
off
depending on the set measurement profile
off
Deutsch
off
0000
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
