Commissioning
6.5 Commissioning EDS (isoxx1685DP only)
Proceed as follows to put into operation an EDS after commissioning the ISOMETER®:
1. Set the mode for the insulation fault location to manual, automatic or 1 cycle. For a
description of the different modes, refer to
Mode
o Manual
• Auto
o 1 cycle
2. Test if the maximum locating current matches the EDS and adjust if necessary (refer to
6.3.7 "Setting the EDS current (isoxx1685DP only)" on page
Menu path: Menu/EDS/General/Current
Current
o 1mA
• 2.5mA
o 5mA
o10mA
o25mA
In addition to this chapter, the commissioning of the ISOMETER® in combination with an EDS
is described in the chapter
page
30.
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
x.x.x
x.x.x
6.2 "Commissioning flow chart with insulation fault location" on
"Mode" on page 50
33).
.
35
