Settings
8.2 (1.1.4) Start Alarm (for isoHR1685D-925)
•Start Alarm ON
•Start Alarm OFF
8.2

(1.2) Profile

Adapt the area of application of the ISOMETER® to your system profile. For a description of the
profiles, refer to "Device profiles" on page
The following can be selected:
•Power circuits
•High capacitance
•Inverter >10 Hz
•Inverter <10 Hz
1)
•Fast 2000 μF
1) not for isoHR1685D-925
8.2

(1.3) Device

Set the ISOMETER® insulation resistance measurement function to active or inactive:
•Active
•Inactive
8.2

(1.4) Coupling monitoring (not for isoHR1685D-925)

The ISOMETER® continuously monitors the coupling of energised systems. The coupling of de-
energised systems is monitored at 24-hour intervals. This monitoring function can be activa-
ted or deactivated.
•on
•off
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
Device start with alarm message and a measured value of 0 k
Device start without alarm message and a measured value of
Suitable for most IT systems.
Suitable for systems with high leakage capacitances.
Limit of the measuring range: 200 kΩ
1)
Suitable for systems with dynamic frequency control by inverters
in the range of 10...460 Hz.
Suitable for systems with extremely low frequency control in the
range of 1...460 Hz.
Suitable for systems with very high leakage capacitances, e.g. in
large-scale photovoltaic systems. Limit of the measuring range:
50 kΩ
The device is active.
The device DOES NOT measure the insulation resistance and is discon-
nected from the system to be monitored (system disconnection, not
for isoHR1685D-925). The IT system is NOT being monitored!
The message
The ALARM 1 and ALARM 2 LEDs light up.
Coupling monitoring is activated.
Coupling monitoring is deactivated.
Coupling monitoring in single-pole operation
Coupling monitoring must be deactivated in single-pole operation. (see 8.2
(1.6) "„Single-pole operation" - isoHV1685D only" on page 46
75.
Device inactive
appears on the display.
