8.2

(1.7) Outputs

The ISOMETER® provides a total of 3 alarm relays.
The following parameters can be set for relay 1 and relay 2:
8.2 (1.7.1) Relay 1
The following parameters can be set for the relay:
8.2 (1.7.1.1) TEST
The functional test of the relay can be activated or deactivated. This only applies to the manual
test and not to the cyclic device self test:
•on
•off
8.2 (1.7.1.2) Relay mode
The relay mode can be adapted to the application:
•N/C
•N/O
8.2 (1.7.2) Relay 2
See chapter 8.2 (1.7.1) "Relay
8.2 (1.7.3) Relay 3:
8.2 (1.7.4) Buzzer
The following parameters can be set for the buzzer:
8.2 (1.7.4.1) TEST
The functional test of the buzzer can be activated or deactivated. This only applies to
the manual test and not to the cyclic device self test:
•on
•off
48
The manual test checks the switching function of the relay
The manual test does not check the switching function of the relay
Normally closed - N/C operation contacts 11-12-14/21-22-24 (The
alarm relay is energised during normal operation).
Normally open - N/O operation contacts 11-12-14/21-22-24 (The alarm
relay is de-energised during normal operation).
1".
Relay 3 does not appear in the device menu. The operating mode is set to N/C
operation and the parameters cannot be adjusted.
The manual test activates the buzzer sound.
The manual test does not activate the buzzer sound.
