8.2

(2.2) Scanning channels

For a successful insulation fault location, all active measuring channels must be determined.
Indicate if you would like to start the search for EDS measuring channels.
•Cancel
•Start
Also refer to "Commissioning EDS (isoxx1685DP only)" on page
8.2

(2.3) Activating channels

During initial commissioning all channels are inactive. Before configuring the channels, they
must be activated in this menu. Navigate to the required selection point using the
buttons. Confirm selection by pressing "OK". Select the measuring channels to be activated
with the button.. Multiple selection is possible here.
•Select all
•No selection
•Invert selection
•Channel 1 (BS 2/1)
...
•Channel 12 (BS 2/12)
8.2

(2.4) Group settings

Use group settings to adjust the settings for several EDS or EDS channels simultaneously or to
read out settings.
If you would like to make settings for each EDS or each EDS channel individually, please refer
to the menus from
52
Aborts the scan process.
Starts the scan process (search) for EDS channels.
If one bus device fails, the ISOMETER® asks whether it should search for measu-
ring channels and then automatically determines all channels again. Also refer
to "Alarm messages" from page
All channels are selected.
No channel is selected.
The current selection is inverted.
A single channel is selected.
chapter 8.2 (2.5) "Channel"
The values indicated in the group settings are not the values of the indivi-
dual EDS but the factory settings or the last adjusted values in the ISOME-
TER®. To see the values of the individual EDS devices, please navigate to the
menus from chapter 8.2 (2.5) "Channel"
35.
74.
to chapter 8.2 (2.8)
to chapter 8.2 (2.8)
