8. Settings

8.1 Device menu structure

1. Alarm settings
2. EDS (see 8.1.1)
only for following devices:
- iso1685DP
- isoLR1685DP
3. Data meas. Values
4. Control
5. History
6. Device settings
1) The numbering of the menu items differs for the models isoHV1685D-425 and isoHR1685D-925 from
menu item 3 (Data meas. values).
42
1. Insulation alarm 1. Alarm 1
2. Alarm 2
3. Memory
4. Start alarm
2. Profile
3. Device
4. Coupling monitor
5. System frequency
6. Single pole operation -> isoHV1685DP-425 only
6. Inputs 1. Digital 1
7. Inputs (isoHV1685...)
2. Digital 2
7. Outputs 1. Relay 1
8. Outputs (isoHV1685...)
2. Relay 2
3. Buzzer
-> see footnote 1)
1. TEST
2. RESET
3. EDS
1. History
2. Delete
1. Language
2. Clock 1. Time
2. Format
3. Summer time
4. Date
5. Format
3. Interface 1. Mode:
2. BMS
3. Modbus/RTU
4. Display 1. Brightness
5. Password 1. Password
2. Status
6. Commissioning
7. Factory setting
8. Service
1. Mode
2. t(on)
3. t(off)
4. Function
1. Mode
2. t(on)
3. t(off)
4. Function
1. TEST
2. Relay mode
1. TEST
2. Relay mode
1. TEST
2. Function 1
3. Function 2
4. Function 3
1. Address
1. Address
2. Baudrate
3. Parity
4. Stoppbits
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
