ISOMETER® isoHR685W-x-I-B
Werkseinstellungen
Ansprechwerte
Ansprechwert R (Alarm 1) ................................................................100 kΩ
an1
Ansprechwert R (Alarm 2) ..................................................................20 kΩ
an2
Fehlerspeicher............................................................................................aus
Ankoppelüberwachung .............................................................................. ein
Geräteprofil ..........................................................................„Leistungskreise"
Art des zu überwachenden Netzes
Netzform ...................................................................................................3AC
Zeitverhalten
Anlaufverzögerung T ............................................................................0 s
Anlauf
Schaltglieder
Relais 1
Arbeitsweise .....................................................................Arbeitsstrom (N/O)
Funktion 1 .................................................................................... Iso. Alarm 1
Funktion 2 ................................................................................... Gerätefehler
Funktion 3 .............................................................................. Anschlussfehler
Relais 2
Arbeitsweise .....................................................................Arbeitsstrom (N/O)
Funktion 1 .................................................................................... Iso. Alarm 2
Funktion 2 ................................................................................... Gerätefehler
Funktion 3 .............................................................................. Anschlussfehler
Schnittstellen
IP-Adresse ...................................................................... manuell 192.168.0.5
Netzmaske ............................................................................... 255.255.255.0
Geräteadresse BS-Bus ................................................................................... 1
Sonstiges
Sprache .............................................................................................. Deutsch
Inbetriebnahmeassistent ............................................................................ an
10 isoHR685W-x-I-B_D00261_06_Q_DEEN/03.2024

Factory settings

Response values
Response value R (Alarm 1) ..............................................................100 kΩ
an1
Response value R (Alarm 2) ................................................................20 kΩ
an2
Fault memory .............................................................................................off
Coupling monitoring ...................................................................................on
Device profile .........................................................................„Power circuits"
Type of system to be monitored
System type ..............................................................................................3AC
Time response
Start-up delay T ....................................................................................0 s
Anlauf
Switching elements
Relay 1
Operating principle ...................................................................N/O operation
Function 1 .................................................................................... Ins. Alarm 1
Function 2 .................................................................................... Device fault
Function 3 .............................................................................Connection fault
Relay 2
Operating principle ...................................................................N/O operation
Function 1 .................................................................................... Ins. Alarm 1
Function 2 .................................................................................... Device fault
Function 3 .............................................................................Connection fault
Interfaces
IP adress.......................................................................... manual 192.168.0.5
Network mask .......................................................................... 255.255.255.0
Adress BS bus ................................................................................................ 1
Other
Language ............................................................................................German
Commissioning wizard ................................................................................on
