Bender ISOMETER iso1685DP-425 Manual page 77

Technical data
12.1.4 Inverter < 10 Hz
For systems involving extremely low-frequency control in the range of up to 0.1...460 Hz and very
slow and continuously changing extraneous DC voltages due to dynamic load conditions in an IT
system, continuous insulation monitoring can be optimised using this profile.
Power frequency
DC, 0.1...460 Hz
Diagram „Inverter > 10 Hz"
100
10
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
System leakage
capacitance
0...150 μF
Z
1
0,1 1
Measuring Response value range
voltage
±50 V iso1685DP: 200 Ω...1 MΩ
isoHV1685: 200 Ω...1 MΩ
isoLR1685DP: 20 Ω...100 kΩ
(p o : / , )
10
Response value Ran [k ]
/
Ce 1μF
Ce 10μF
Ce 100μF
100 1000
77
