1 .2 System description

The system comprises the following hardware functional modules:
1 Input voltage:
2 User interfaces:
3 Keyboard and display:
4 Sensor interface:
5 Microcontroller system:
1 Input voltage:
2.1 User interface 1:
2.2 User interface 2:
2.3 User interface 3:
2.4 User interface 4:
3 Keyboard/Display:
4 Sensor interface:
5 Controller system :
FC100-CA | Flow Meter
DESCRIPTION
DC supply (terminal XV)
2.1 signal outputs, 2-way or 4-way signal outputs (terminal XAH)
2.2 analogue outputs (terminal XAO)
2.3 RS232 interface (terminal XSE)
2.4 external totalizer reset (terminal XRE)
keypads
liquid crystal display
calorimetric monitoring head type CSx _ (terminal XSK)
signal processing, communication and monitoring
Power supply DC/DC
1
4
Sensor
Microcontroller
interface
system
calorimetric
monitoring
5
head CSx
Keyboard and display
3
DC 10 ... 40 V
relay outputs: 2 limit values
transistor outputs: 2 limit values + 1 error indication +
1 busy signal or pulse output (software selected)
analogue outputs: temperature and flow
current or voltage
RS232 interface
totalizer reset: edge controlled
potential free, normally open contact or voltage pulse DC10 ... 40 V
keypads
LC display
2 x 16 digits
backlight (can be switched off)
calorimetric monitoring head type CSx
signal processing
I/O - controlling
monitoring
parameter memory
communication
2.1
User
interface 1
2.2
User
interface 2
2.3
User
interface 3
2.4
User
interface 4
fig. 2
