Flow Meter | FC100-CA

7 .3 . 1 Voltage output V1 - 5 V FS

Signal voltage range:
Accuracy:
Resolution:
Min. admissible load resistance:
Max. admissible load capacity:
Max. admissible load inductance:
Short circuit proof:

7 .3 .2 Voltage output V2 - 10 V FS

Signal voltage range:
Accuracy:
Resolution:
Min. admissible load resistance:
Max. admissible load capacity:
Max. admissible load inductance:
Short circuit proof:

7 .3 .3 Current output C1 - 20 mA FS

Signal current range:
Accuracy:
Resolution:
Min. admissible load resistance:
Max. admissible load resistance:
64
TECHNICAL DATA
U = 0 V (1 V) to 5 V
S
± 0,75 % FS
10 Bit (5 mV)
R = 1 kΩ
l
C = 1 nF
l
L = 100 nH
l
yes (XAO - between all terminals)
U = 0 V (2 V) to 10 V
S
± 0,75 % FS
10 Bit (10 mV)
R = 2 kΩ
l
C = 1 nF
l
L = 100 nH
l
yes (XAO - between all terminals)
I = 0 mA (4 mA) to 20 mA
S
± 0,75 % FS
10 Bit (20 µA)
= 0 Ω
R
l
= 300 Ω
R
l
