2 .2 . 1 .2 Surface mounted version FC100-CA-FH-U1 . . . (see fig. 16)
• Remove the cover of the housing.
• Install the housing in place using the 4 screws M4.
• Replace the cover and tighten the retaining screws.
FC100-CA-FH (surface mounted version)
ø4,5
mounting holes
All dimensions in mm
FC100-CA | Flow Meter
INSTALLATION
140
103
M16
M
M
FC100-CA
Flow Controller
M16
ø5 to ø8
71
fig. 16
25
