7 .5 Metrological data

7 .5 . 1 Flow rate measurement

Measuring is possible up to the flow rates indicated in the display range. However, the indi cated
accuracy is no longer guaranteed.
The repeatability value remains valid .
Medium: air

7 .5 . 1 . 1 Monitoring head CSP with sensor adapter type TP-...

Flow measurement ranges:

Sensor adapter
type
TP01
TP02
TP03
TP04
TP05
TP06
Response delay:
1)
Accuracy :
Repeatability:
(5 % MBE to 100 % MBE)
Temperature drift:
of final value
* MBE -
measured value
** MW -
1)
Please enquire for higher accuracy.
FC100-CA | Flow Meter
TECHNICAL DATA
Measuring range
in Nm 3 /h
0 ... 50
0 ... 77
0 ... 120
0 ... 197
0 ... 308
0 ... 480
3 s
± 3% MW ** / ±0.1 % MBE *
± 1% MW / ±0.5 % MBE
± 0.05 %/K/MBE
Display range
in Nm 3 /h
70
109
170
280
439
685
