Flow Meter | FC100-CA

4 .3 .2 Limit switches

The next menu item shows the limit switches which are assigned to the physical quantity/quantities.
F means the limit switch (LS) is assigned to flow velocity, T means the limit switch is assigned to medium
temperature.
An inverse representation of T or F indicates that the limit switch is in switch-on condition.

4 .3 .3 Configuration

The submenu CONFIGURATION is described in chapter 5.

4 .3 .4 Information

The submenu INFORMATION shows the device type, the version of the firmware and the selected type
of the monitoring head.
40
OPERATION AND MAIN MENU
submenu
INFORMATION
INFORMATION
... -CA-U1T4C1-000
M
INFORMATION
VERS.=1.00000
M
INFORMATION
CST11AM1
M
back to
MAIN MENU
fig. 28
