Flow Meter | FC100-CA

7 .4 .2 Transistor outputs (DC)

Pin selection:
Voltage level
Low level - active:
High level - passive:
Reverse polarity protection:
Short circuit protection:
Resistive load
Max. admissible switching capacity:
Max. admissible switching current:
Max. admissible switching voltage:
Inductive load - L < 100 mH
(DC voltage - without external safety circuit)
Max. admissible switching capacity:
Max. admissible switching current:
Max. admissible switching voltage:
Capacitive load - C < 20 µF
Max. admissible switching capacity:
Max. admissible switching current:
Max. admissible switching voltage:
Insulation voltage:
66
TECHNICAL DATA
Signal name
/ ERROR emitter
/ ERROR collector
/ BUSY / PULSE emitter
/ BUSY / PULSE collector
Limit Switch 2 emitter
Limit Switch 2 collector
Limit Switch 1 emitter
Limit Switch 1 collector
U < 0.8 V at I < 10 mA
ce C
U < 1 V at I < 100 mA
ce C
U < 48 V
ce
U = 60 V
ce max
max. leakage current ≤ 25 µA
yes
yes
1.5 W
150 mA
36 V
1.5 VA
40 mA
36 V
1.5 VA
1.5 A
36 V
signal contact - central electronic unit DC 500 V
signal contact - signal contact DC 500 V
Pin XAH Polarity
1 -
2 +
3 -
4 +
5 -
6 +
7 -
8 +
