2 . 1 .2 .5 Push-in monitoring head CSF-11AM1/CSF-11AM2
Application:
Style:
Material of the area exposed to medium:
All dimensions in mm
FC100-CA | Flow Meter
INSTALLATION
general industry and installation
recommend for inside pipe diameter >60 mm
push-in monitoring head
stainless steel 1.4571/AISI 316 Ti
nickel-based alloy (Hastelloy C4 2.4610)
SW20
ø18
circular connector
fig. 7
17
