Flow Meter | FC100-CA

5 . 1 3 Quitting the configuration menu

To quit the configuration menu, the controller will check the data entered for plausibility.
"CONFIG. OK!" is indicated when the data are correct. The menu may than be quitted by pressing
M MODE.
Errors found during the plausibility check are indicated in the following sequence of priority.
Priority of entry errors in the CONFIGURATION menu:
ERR. A-OUT FLOW
OUT OF RANGE
ERR. A-OUT FLOW
ZERO ≥ FS
ERR. A-OUT TEMP.
OUT OF RANGE
ERR. A-OUT TEMP.
ZERO ≥ FS
ERROR LS1
ON = OFF
ERROR LS2
ON = OFF
The menu can only be quitted after correction of the error(s). To do this, return to the beginning
of the configuration menu by pressing ▲ UP or ▼ DOWN and select the menu option with the
incorrect entry for correction.
58
CONFIGURATION
analogue output – flow velocity
flow analogue output outside measuring range
analogue output – flow velocity
initial value ≥ final value
analogue output – medium temperature
temperature analogue output outside measuring
range
analogue output – medium temperature
initial value ≥ final value
switch-on value for limit switch 1 equals switch-off
value for limit switch 1
switch-on value for limit switch 2 equals switch-off
value for limit switch 2
