8 .4 Analogue outputs

The analogue outputs are physically isolated from each other and from the electronic
control unit FC01-Ex .
Pin selection for analogue outputs V1, V2 and C1
Analogue output 1 - ANA OUT FLOW (flow output)
Analogue output 2 - ANA OUT TEMP. (temperature output)
* Shield ungrounded - apply one side only .
Insulation voltage:

8 .4 . 1 Voltage output V1 - 5 V FS

Signal voltage range:
Max. signal ripple:
Min. admissible load resistance:
Max. admissible load capacity:
Max. admissible load inductance:
Short-circuit proof:

8 .4 .2 Voltage output V2 - 10 V FS

Signal voltage range:
Max. signal ripple:
Min. admissible load resistance:
Max. admissible load capacity:
Max. admissible load inductance:
Short-circuit proof:
68
TECHNICAL DATA
Signal name
NC
Analogue output 1 - flow
Reference ground 1
Shield for analogue output 1 *
Shield for analogue output 2 *
Analogue output 2 - temperature
Reference ground 2
NC
NC - not used
analogue output - analogue output 500 V
analogue output - central electronic unit 500 V
shield potential - supply voltage of analogue
output ≤ 48 V DC
U = 0 V to 5 V ± 2% FS
S
dU = 5% FS
S
R = 1 kΩ
l
C = 1 nF
l
L = 100 nH
l
yes (XAO - between all terminals)
U = 0 V to 10 V ± 2% FS
S
dU = 5% FS
S
R = 2 kΩ
l
C = 1 nF
l
L = 100 nH
l
yes (XAO - between all terminals)
Pin XAO
1
2
3
4
5
6
7
8
