4.6.1.1 ARB Function
This series of instruments comes standard with ARB (arbitrary waveform) func-
tion, which allows the output of user-defined arbitrary complex voltage or current
waveforms. It can be operated in the following ways:
•
Import via U disk
The instrument supports importing the edited .csv format file (the template
can be obtained by contacting ITECH personnel) through the USB interface
on the front panel, and generating voltage or current values after parsing,
and then outputting complex voltage or current waveforms according to the
time width specified by the user. The user can edit a .csv file containing up
to 10 million voltage or current points and import it into the instrument for
running to realize arbitrary waveform output or working condition simulation.
The instrument has the ability to quickly parse data. A .csv file of dozens of
megabytes can be imported and parsed within 5S, making testing more con-
venient and efficient.
This instrument supports importing the .csv files corresponding to the follow-
ing waveforms:
– CDWELL: Constant dwell arbitrary waveform
The fields included in the .csv template file are explained as follows:
Model
Firmware
Version
Serial Number
File Type
Waveform Type
Value Unit
Offset Unit
Time Unit
Mode
Copyright © Itech Electronic Co., Ltd.
Device model, keep the default settings without
modification.
Firmware version number, keep the default settings
without modification.
Device serial number, keep the default settings with-
out modification.
File type, keep the default settings without
modification.
Waveform type, keep the default settings without
modification.
The CV priority is set to V, and the CC priority is set to
A.
Offset value unit, CV priority is set to V, CC priority is
set to A.
Time unit, fixed to S.
Indicates the power supply working mode. The CV
priority is set to CV, and the CC priority is set to CC.
