4.6.2 Battery Charging Test Function

The IT6000D series power supply provides the battery charging test function.
Suitable for charging tests on all types of portable batteries.
•
•
•
•
BATTERY
For detailed function usage, please refer to IT9000–PV6000 User Manual.
When connecting the DUT (battery/capacitor), do not short-circuit
the battery/capacitor.
It is recommended that for battery testing, a fuse must be con-
nected in series between the power supply and the battery to pre-
vent short circuits caused by any problems.
When connecting the DUT (including but not limited to battery/ca-
pacitor), it is recommended that you purchase the IT-E165A anti-re-
verse connection and anti-spark module to prevent the battery/
capacitor reverse connection that may cause damage to the instru-
ment and spark during the battery/capacitor wiring; When there is
no external auxiliary equipment connected to prevent reverse con-
nection and anti-spark function, please pay attention to the safety
of the wiring, and be careful not to reverse the battery/capacitor
connection, reverse connection will cause damage to the instru-
ment, even if it is not powered on.
Before performing the battery test, you need to connect the Sense
cables to both ends of the battery. If the Sense cables are not con-
nected, the instrument cannot detect the Sense voltage and prompt
"Wait Power Link", which will prevent the battery test from
continuing.
Battery charging test function
Run
Edit
Copyright © Itech Electronic Co., Ltd.
Indicates that the battery test mode is entered and
waits to trigger the running of the currently edited bat-
tery test file.
Edit the battery charging test file.
Charge V
Charge I
Power Supply Function
Set the voltage value of the bat-
tery charging test.
Set the current value of the bat-
tery charging test.
