Last+Off
Sense Set the sense function state.
Off
On
ListTrig Source Set the trigger method for the List files running.
Immediate Trigger immediately
Manual
Bus
External
DLogTrig Source Set the trigger method for the data logging.
Immediate Trigger immediately
Manual
Bus
Voltage
Current
External
I/O Set the communication information between instrument and PC.
USB
When the instrument is powered on, the instrument will re-
main the same settings as last time you turned off the in-
strument, but the [On/Off] is OFF state.
Turn the sense function off.
Turn the sense function on.
Manual trigger
Bus trigger
External trigger
Manual trigger
Bus trigger
Voltage trigger
Current trigger
External trigger
USB communication interface
USB-TMC protocol
TMC
Virtual serial port
VCP
Display as the following format:
baud rate_data bit_parity bit_stop bit.
•
•
•
•
Virtual LAN communication. After selecting
this option, you also need to set the commu-
nication parameters of the LAN, and the
LAN
menu items are the same as those in the
LAN menu (see below).
Copyright © Itech Electronic Co., Ltd.
Select the baud rate from the following
options: 4800, 9600, 19200, 38400,
57600, 115200
Select the data bit from the following op-
tions: 5, 6, 7, 8
Select the parity bit from the following
options: N, O, E
Select the stop bit from the following op-
tions: 1, 2
