WARNING
Safety Regulations
To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
To avoid injuries, always disconnect power, discharge circuits,
and remove external voltage sources before touching
components.
KEEP AWAY FROM LIVE CIRCUITS.
We cannot accept responsibility for any direct or indirect
financial damage or loss of profit that might occur when using
the power supply.
The instrument chassis and cover must be connected to an
electrical ground.
Certification
We certify that this product met its published specifications at
time of shipment from the factory.
Notice
The information contained in this document is subject to change
without notice.
Warranty
This hardware product is warranted against defects in material
and workmanship for a period of ONE year from date of delivery.
IT6720 power supply for use with a hardware product and when
properly installed on that hardware product, is warranted not to
fail to execute their programming instructions due to defects in
material and workmanship for a period of 90 days from date of
delivery. During the warranty period our company will either
repair or replace products which prove to be defective. Our
company does not warranty that the operation for the software
firmware or hardware shall be uninterrupted or error free. For
warranty service, with the exception of warranty options, this
product must be returned to a service facility designated by our
company. Customer shall prepay shipping charges (and shall
pay all duty and taxes) for products returned to our place for
warranty service. Our company shall pay for return of products
to Customer.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT6720 and is the answer not in the manual?

Questions and answers

Summary of Contents for ITech IT6720

  • Page 1 This hardware product is warranted against defects in material and workmanship for a period of ONE year from date of delivery. IT6720 power supply for use with a hardware product and when properly installed on that hardware product, is warranted not to...
  • Page 2: Limitation Of Warranty

    Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) The ITECH product you have purchased is subject to Directive 2002/96/EC of the European Parliament and the Council of the European Union on waste electrical and...
  • Page 3 About IT6720 Compared with other power supplies, IT6720 has the widest range of voltage and current. The max output voltage is 60V, the max current is 5A, and the max power is 100W. You can set multi-groups voltage and current value as long as the max range allowed.
  • Page 4: Panel Layout

    Panel Layout Voltage setup Indicator CC mode Indicator CV mode Indicator Voltage Value OCP Indicator Step B + Memory B OVP Indicator Step A + Memory A Step C + Memory C Memory mode Indicator Step D + Memory D Keyboard Lock Indicator Current Value Shift Indicator...
  • Page 5: Quick Start

    Make sure the AC input voltage of power supply accord with the standards of your country or area. If the 2 terms above are right, please turn on the power supply. Preset Voltage Voltage Set IT6720 60V/5A/100W Press key to make the preset ITECH D V/A Auto Range DC Power Supply voltage light “V”...
  • Page 6 (Lock) key, the light will bright, that Lock means the keys have been locked. Repeat above operation, key lock function will be disabled. OVP Function IT6720 60V/5A/100W ITECH Auto Range DC Power Supply D V/A Press first, then press Shift (Setup) key for 3 seconds, LED will display OVP.
  • Page 7 Store Group Setting After setting the OCP value, press IT6720 60V/5A/100W ITECH Auto Range DC Power Supply key into GRP setting, use key and knob to select store group. There are 100 groups to be selected, each group can be stored 4 current or voltage values.
  • Page 8: Specification

    Specification Specs Specifications IT6720 Output Rating Voltage 0~60V Current 0~5A Power 100W <0.01%+3mV Voltage Load Regulation Current <0.01%+3mA Voltage <0.01%+3mV Line Regulation Current <0.1%+3mA Programming Accuracy Voltage <0.05%+10mV Current <0.2%+2mA Read back Accuracy <0.05%+10mV Voltage Current <0.1%+2mA Ripple <2.0mV rms...
