1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].
The interface is displayed as follows:
FUNCTION BATTERY
Run Edit
3. Press the Left/Right key to select Edit and press [Enter].
4. Set the charging voltage (Charge V), charging current (Charge I) and the
other parameters, and then press [Enter] to confirm.
After the parameter setting is completed, the interface returns to the Battery
function main interface and displays as follows:
FUNCTION BATTERY
Run Edit
5. Press the Left/Right key to select Run and press [Enter].
The instrument will enter the battery test mode and wait for the battery test
to be triggered.
6. Turn on the [On/Off].
This product supports Sense anti-reverse function. If you reverse the
Sense cables, the VFD will display a negative voltage value, and you can-
not turn on the output at this time. It can only be turned on after the cables
are properly connected.
7. Based on the selected trigger method, perform the trigger operation.
The trigger method of the battery test is consistent with the trigger method
of the List function, that is, the List trigger source is also effective for the
Battery function.
Copyright © Itech Electronic Co., Ltd.
Charge Time
Cut Off Voltage
Cut Off Current
Cut Off Capacity
Power Supply Function
Set the battery charging time.
Battery test cut-off voltage
Battery test cut-off current
Battery test cut-off capacity
