Strong Digital I/O Function: In addition to general digital signal I/O functions,
it can also be customized by supporting the wiring through different pins to
meet different special needs through different pin wirings;
•
Select CC loop priority or CV loop priority. If voltage and current parameters
are to be changed frequently during test, the user can directly set related pa-
rameters through [V-set] and [I-set] on the front panel, which is very
convenient;
•
High visible vacuum fluorescent display (VFD)
•
Support optical fiber communication, which is applicable for loop control be-
tween units under parallel mode.
•
Built-in USB/CAN/LAN communication interface
•
Optional GPIB/RS–232 communication interface
•
Optional external analog interface, and share an interface position with RS-
232.
•
Strong trigger system;
•
When the Sense function is turned on, it can ensure that the DUT is safe in
case of reverse connection or open circuit of the Sense line.
The IT6000D series was designed to allow paralleling of multiple units to cre-
ate larger power systems. Expandable in master and slave parallel Up to
1152kW. All program is performed from the master unit front panel or remote
control interfaces. Consolidated current and power measurements are re-
ported on the master unit. The function and operation of the instrument are
the same as that of the single instrument. For detailed specifications, please
contact ITECH service.
The models included in the IT6000D series are as follows:
Voltage Model
Level
IT6005D-80-150
IT6010D-80-300
80V
IT6015D-80-450
IT6015D-80-450S
IT6006D-300-75
300V IT6012D-300-150
IT6018D-300-225
IT6006D-500-40
500V
IT6012D-500-80
Copyright © Itech Electronic Co., Ltd.
Quick Reference
Current Power
150A 5KW
300A 10KW
450A 15KW
450A 15KW
75A 6kW
150A 12kW
225A 18kW
40A 6KW
80A 12KW
