Page 33
2. Enable Alarm if required.
3. Set weather to save the scene image (Panoramic Picture) or the object image (Target
Cutout)
4. Set the alerting objects and detection sensitivity (Objects not marked will be ignored)
5. Set the Alarm response as follows and click "Save" to confirm:
Alarm Out
Trigger Snap
Trigger SD Recording
Trigger Email
Trigger FTP
6. Set the "Reset Count" if needed – The counter will be reset automatically at the end of the
defined period.
7. You can manually reset the counter by clicking on the "Reset" button.
8. Now you will have to set entrance mark line. Click on the "Area" tab to get to the interface
shown below.
IP CAMERA USER MANUAL
Alarm Triggers:
triggers the alarm out relay
takes a snapshot (SD card must be available)
Initiates video recording over the SD card (SD card
must be available)
sends an email as configured in the Email section.
send a snapshot as configured in the FTP section
