1. Select a bright area. Avoid constantly moving objects such as trees and scenes with many
lighting changes.
2. The detection area should be well lighted and bright.
3. Install the camera at a height of 2.8 meters and more from the ground.
4. Install the camera at an angle of about 45 degrees from the ground.
5. The smallest detected object size shall not be smaller than 1 percent of the total scene.
6. The largest detected object size shall not be larger than 1/8 of the total scene.
7. Make sure that the object is displayed for at least two seconds for precise identification .
General Remarks:
1. Up to 4 lines can be set. Each line can be set with different configuration.
Inapplicable Scenes
1. Low Light Scenes.
2. Area with a lot of movements.
3. Area with frequently changing or uneven lights.
4. Low installation angle.
Low Light Scene – Inapplicable
– Low Light
Low Angle Installation – Inapplicable

6.5 People Intrusion and Sterile Area

This function is designed to use indoors. It is mainly used to detect motion in a protected
area.
The alarm will be triggered within 3 up to 5 sec if someone enters into the detected area.
IP CAMERA USER MANUAL
A
B
Inapplicable – Many moving object
A
B
Area with many movements – Inapplicable
Correct Installation
