2. Enable the alarm to activate it and see the configuration parameters:
Parameter
Sensor ID (Applicable
for Z6 model only)
Alarm Type
Alarm Holding Time
Sensor Name
Alarm Out
Trigger Snap
Trigger SD recording
Trigger Email
Trigger FTP
3. After the setting is complete, click "Save".
4. Next, you will need to set the alarm schedule. Click on the "Schedule" tab to get the
following interface:
IP CAMERA USER MANUAL
Meaning
Choose the Sensor you wish to set
You can set it to "NO" (Normally open) which means
that the once the line is closed the alarm will be active,
or "NC" (Normally Closed") which means that once the
line is open the alarm will be active.
The holding time means that the alarm signal will stay
active and no additional alarms will be generated
during that time.
You can set a unique name for easy identification.
Alarm Triggers:
triggers the alarm out relay
takes a snapshot (SD card must be available)
Initiates video recording over the SD card (SD card
must be available)
sends an email as configured in the Email section.
send a snapshot as configured in the FTP section
