The display parameters are as follows:
Parameter
Config file*
Brightness
WDR
Saturation
Sharpness
Noise reduction
Defog
BLC
Antiflicker
White Balance
Frequency
Day/Night Mode*
Sensitivity
Infra-Red Mode
Smart IR
Exposure Mode
Image Mirror
Image Flip
Focus Limit
Zoom Display
Zoom Speed
Scan Speed
Lens Initialization
Set North
*If you set the day/night mode to schedule or you wish to differentiate between the daytime
and night-time image settings, you will need to set the schedule accordingly.
Click on the "Schedule" tab and set the schedule as you wish.
IP CAMERA USER MANUAL
You can set an individual configuration for Day and night. Common
is used for both
Set the image brightness
Set the Digital WDR value
Set the image saturation
Enable/Disable the sharpness and set its level
Enable/Disable the 3D-DNR and set its level
Enable/Disable the defog and set its level
Set HLC/BLC to deal with advanced light conditions.
When set to BLC, you can adjust the BLC location
When set to HLC, you can set the HLC schedule
Set the antiflicker
Set the white balance of the camera
Set the frequency to 50/60Hz
Set the day/night mode (Auto/Day/Night/Schedule)
The light sensor sensitivity
Set the IR status
Set the smart IR. Smart IR makes sure that the image will not be
overexposed due to the IR light.
Set the exposure to auto or set it manually
Mirror the image horizontally
Flip the image vertically
Set the minimum distance for focusing. The shorter the range, the
longer it might take the camera to focus. (Since it needs to search
for the focus point in a longer range)
Choose if the show the zoom ratio as part of the OSD
Set the zoom speed
Ser the scan speed (For auto scan tasks)
Initialize the lens
Set the north (Useful for installations where the North direction is
important)
Meaning
