IP CAMERA USER MANUAL
In the next tab we have "Audio" settings as shown below:
The audio input / built-in microphone is disabled by default. Enable it if you need audio input from the camera..
Set the encoding profile as desired and the type of audio input. If LIN (Line) is selected, it means that the audio
input is already amplified and the input volume will be set to "low". If MIC (Microphone) will be selected, it
means that the audio signal is not amplified and the input volume will be set to "high".
*Z4 models do not support Audio

4.2.3 OSD Configuration

Go to "Video Config" → "OSD" menu to display the interface as shown below.
You may set the device name, time stamp and custom OSDs here. Drag the time stamp and
custom OSD over the image on the left side to set their position. Then press the "Save"
button to save the settings.
