Swan Analytical Instruments AMI Codes-II O3 Operator's Manual page 83

AMI Codes-II O3
Program List and Explanations
5.4.4
5.4.4.1
5.4.4.1.3
5.4.4.2
5.4.4.2.1
5.4.4.2.2
5.4.4.3
5.4.4.4
5.4.4.5
A-96.250.881 / 070622
Access: Select a password to prevent unauthorized access to the
menus <Messages>, <Diagnostics>, <Maintenance>, <Operation>
and <Installation>.
Note: The password protection becomes active under the
following conditions:
• Enter an administrator password different from <0000>.
• After defining the administrator password, users 1–4 are also
automatically activated. The default password for all users is
<1234>. If necessary, change the passwords.
Administrator: The administrator owns all rights and has access to
all menus. Only an administrator can assign user rights for the users
1 to 4.
Name: Admin
Function: Administrator
Password: The password is set to <0000> by default. If an adminis-
trator password different from <0000> is set, it is not longer possible
to enter a menu without entering the password.
If you have forgotten the administrator password, contact your near-
est SWAN representative or the manufacturer.
User 1
Name: Enter the name of the user.
Function:
Function
Administrator
Service
Operator
Administrator: All rights
Service: Access to all menus except menu <Installation>
Operator: Access to the menus <Messages> and <Diagnostic>
User 2
see User 1
User 3
see User 1
User 4
see User 1
predefined, not changeable
predefined, not changeable
