AMI Codes-II O3
Program List and Explanations
5.3.2.44
5.3.2.54
5.3.2.6
5.3.2.7
5.3.2.24
5.3.2.342
5.3.2.342.1
5.3.2.342.2
5.3.2.342.8
5.3.2.44
5.3.2.54
5.3.2.6
5.3.2.7
5.3.2.1
5.3.3.1
5.3.4
5.3.4.1
A-96.250.881 / 070622
Run Time: see Interval
Delay: see Interval
Signal Outputs: see Interval
Output/Control: see Interval
weekly
The relay contact can be activated at one or several days, of a week.
The daily starting time is valid for all days.
Calendar:
Start time: The programmed start time is valid for each of the pro-
grammed days. To set the start time see
Range: 00:00:00–23:59:59
Monday: Possible settings, on or off
to
Sunday: Possible settings, on or off
Run Time: see Interval
Delay: see Interval
Signal Outputs: see Interval
Output/Control: see Interval
Function = Fieldbus:
The relay will be switched via the Profibus input. No further parame-
ters are needed.
Function = End of Batch
This function is only available on relay 2. It is used to communicate
with canal switching instruments from third-party suppliers. The relay
closes for 1 sec. after each valid measurement. If End of Batch is
selected, no further selection is possible.
Input: The functions of the relays and signal outputs can be defined
depending on the position of the input contact, i.e. no function,
closed or open.
Active: Define when the input should be active:
Input is never active.
No:
Input is active if the input relay is closed
When closed
Input is active if the input relay is open
When open:
5.3.2.341, p. 80.
