AMI Codes-II O3
Product Description
2.1.
Power Supply
Transmitter
specifications
Sample
requirements
On-site
requirements
Ozone
measurement
A-96.250.881 / 070622

Instrument Specification

AC variant:
DC variant
Power consumption:
Housing:
Ambient temperature:
Storage and transport:
Humidity:
Display:
Flow rate:
Temperature:
Inlet pressure:
Outlet pressure:
Note: No oil, no grease, no sand.
The analyzer site must permit connections to:
Sample inlet:
Sample outlet:
Measuring range:
0–500 ppb
Limit of detection:
Cycle time:
100–240 VAC (± 10%)
50/60 Hz (± 5%)
10–36 VDC
max. 35 VA
aluminum, with a protection degree of
IP 66 / NEMA 4X
−10 to +50 °C
−30 to +85 °C
10–90% rel., non condensing
backlit LCD, 75 x 45 mm
min. 10 l/h
5–50 °C
0.15–2 bar
pressure free
Serto PVDF 6 mm (1/4" thread)
Tube 6x4 mm
1/2" hose nozzle for flexible tube
diam. 20x15 mm
Accuracy:
±1 ppb or 5%, whichever is greater
1 ppb
5–10 min
